Standard ESD environment and procedures should be followed when working with loose devices and the Smart Socket. 2. Features Each Smart Socket board is unique for a device family and package. Smart Socket boards have common features such Powered over simple USB cable ...
Some product families, such as MachX02, have parts with different core supply voltage requirements. The Smart Socket board jumper (J2) allows you to select between 1.2 V and 3.3 V core supply voltage. The selected core supply voltage is indicated by LEDs located next to the jumper on the board.
Smart Socket User Guide 4. Board Specifications The outline dimension is the same for all Smart Socket boards. The dimensions of the socket vary based on target device family and package. Board dimensions: Width: 4 inch Length: 6 inch ...
Smart Socket works with the Lattice Diamond Programmer using only a USB cable. Connect the cable from the Smart Socket to a PC, and use the cable search feature in Lattice Diamond Programmer to establish the programming link. The steps to program a device are described below.
Under Operation, PTM Bypass is indicated. The File Name field is greyed out (to prevent adding a new file) as shown in Figure 5.20. Figure 5.20. ASC Socket – Ready to Program Step 8. Program the ASC device through the MachXO2 device on the Smart Socket board by clicking the Program icon as shown in Figure 5.21.
Smart Socket User Guide Appendix A. Smart Socket Board Schematics The following are representative schematics of a Smart Socket board. The FTDI and voltage regulator portions are the same across various Smart Socket boards. +3.3V +3.3V +3.3V +3.3V Ferrite_bead 4.7uF...
