Philips HR2305/55 Service Manual

Philips Consumer Lifestyle
Service Manual
PRODUCT INFORMATION
General
Cooling disc/container is to be kept in a 3 or 4-star
freezer or freezing compartment of the refrigerator.
The stirrer should actually be functioning when the bowl
is being fi lled otherwise the ingredients will immediately
freeze onto the cooling disc.
Safety shut-off
The ice-cream maker is equipped with a safety shut-off.
This device automatically switches off the appliance after
120 minutes of operation, or if overloading occurs.
Cooling down time: approx. 55 min.
Safety
This product meets the requirements regarding interference
suppression on radio and TV.
After the product has been repaired, it should function
properly and has to meet the safety requirements as
offi cially laid down at this moment.
Ice-cream selector switch
When the "soft ice" switch is pressed, the stirrer will
start rotating at a relatively high speed (approx. 70 rpm,
gradually decreasing to approx. 50 rpm., depending upon
the mixture).
After approx. 20 minutes, the green pilote light will start
to blink. Up to 10 minutes after switching on, you can
switch from making "Compact ice" to making "Soft ice"
(or the other way round).
Published by Philips Consumer Lifestyle
08/04
If "Soft ice" has been selected and the ice-cream maker is
not been switched off after 30 minutes, the appliance will
reduce stirrer speed to keep the "Soft ice" longer in optimum
condition.
When the "Compact ice" switch is pressed, the stirrer will
start rotating at a relatively low speed (approx. 21 rpm).
After approx. 40 minutes, the green pilot light will start to
blink.
The blinking pilot light means that the minimum processing
time for a standard quantity of the selected type of ice cream
has elapsed.
TECHNICAL INFORMATION
- Power consumption motor
- Voltage
- Length of mains cord
- Freezing time of cooling disc
- Weight of product
- Dimensions product l x w x h
- Type no. cooling disc
- Speeds
Printed in the Netherlands
Ice-cream Maker
HR2305/55
: 30 W
: 220/230 V, 50-60 Hz
: 140 cm
: 18 hrs
: 3.4 kg
: 23 x 25 x 27 (cm)
: HR 2968
: 2
© Copyright reserved Subject to modification
