For Your Safety Exmobaby has been created to give parents the piece of mind and increased security knowing they can confidently check on their baby and monitor it in real time even when they are away and not in the same room as their child.
Page 3
The pajama garment itself should be regularly cleaned and washed in water. When washing, make sure the sensors and electronics are not exposed to water. Exmobaby sensors and electronics are not water- proof. Only the pajama garment should be washed or submersed in water.
Contents • About your device................Page 1 • Network service................Page 2 • Items in packaging....………………………………………..Page 3 • Keys and parts................Page 4 • Getting started................Page 7 • How to use the product..............Page 10 • Something you need to know............Page 15 • Battery information................Page 17 •...
SIM card. The right SIM card will operate on GSM/EDGE 850, 900, 1800 and 1900 MHz networks. To use Exmobaby, your SIM card must come with service from a wireless provider. Many of the features require special network features. Some networks may require that you make specific arrangements with your service provider before you can use the network services.
Items Inside The Box After opening the package, Please check the following components, if found which is incomplete or damaged, please contact your Exmobaby dealer or retailer. 4 garments in 4 different sizes Heart rate belt Power adapter ...
System Parts 1. Exmobaby Pajama Groove (for the temperature sensor hole) The temperature sensor hole The heart rate sensor holes Belt Velcro Snap-fastener flap www.exmovere.com...
Page 9
Description of the product 2. Transmission Base & Controller Menu Power indicator Communication Settings status indicator Control Charging indicator button Baby's button status Reset button Sensor Antenna Back to menu ON/OFF button SIM card slot Power button www.exmovere.com...
Getting Started 1. Setting up the Exmobaby Base Station 1. Obtain a standard prepaid SIM card from your local carrier. Pull out the slot from the front of the base. Place the SIM card into the slot and then simply slide the slot back into the base with the SIM card already embedded in the slot.
Getting Started 2. Placing the Heart Shaped Sensor on the Pajama 1. To attach the Heart Rate Belt, pull the pajama inside out. Next, attach the belt. There are Velcro ends on both sides. Simply attach the Velcro ends of the garment to the corresponding Velcro end of the belt.
Page 12
Getting Started 3. Using the Display Controller Control Key Description 1. Key “^”: The left shift or selection key. On the main menu, press the button once to enter the next menu. On the submenu, press the button once to shift left, press the button continuously to confirm the current selection, 2.
Page 13
Getting Started 4. Using the Exmobaby Android App You can use your android phone to download. With this App, you can set up Exmobaby on your cell phone which will be synchronized automatically with Exmobaby Display in a couple of minutes.
7 seconds until the bright red LED flashes once indicates the sensor is turned off. 2. Turn on/Turn off Exmobaby base station To turn on the station, press the "POWER" button continuously until the blue status light for power is on and the green status light for network signal starts to blink.
Page 15
2. SOS Alert Transmission Press the "SOS" button until the back light for it is activated. The SOS button sends alerts to parent's cell phone and also activates beeps and a pop-up window featured in the Exmobaby Android App. www.exmovere.com...
Page 16
How to use the product 3. Charging 1. Sensors Remove the sensor from the belt. Snap the Heart Shaped Sensor on the Exmobaby Base Station, so that it can charge. 2. Exmobaby Base Station Connect the base station to a wall outlet via USB cable and adapter, as provided.
Page 17
1. Mom can directly read the current infant heart rate and body temperature data on the date status bar of the display. 2. Open Android phone Exmobaby App. Now parents can read baby heart rate and body temperature data. The temperature data can be set in either Celsius or Fahrenheit.
Page 18
3. The Display Controller will show a “BABY DATA SENDING" message. 4. Display Controller will then show “PLS PUT BACK” to remind the user to put the device back in the Exmobaby Base Station, to enable GSM Network Access. 5. After the Exmobaby Base Station has successfully sent the data, the Display Controller will show an "OK"...
1. Charging your Exmobaby system: the Display Controller and Heart Shaped Sensor will automatically shut down once the battery runs out. When the Exmobaby is out of power, the bright red light on the base station will flash. The Exmobaby Base Station, Display Controller and Heart Shaped Sensor can be charged simultaneously.
Page 20
You may use neutral warm water to hand wash. After washing, use a paper tower to dry it or air-dry it in a secure place, protected from rain. You may machine wash the Exmobaby pajama, as long as the Heart Rate Belt is not left inside of it.
Wireless communication 3G module:Huawei MU509 Do not throw your Heart Shaped Sensor, Display Controller or Exmobaby Base Station into a fire as they contain elements that could become dangerous.
You may machine wash the garment itself. ● Do not use or store the Exmobaby system in dusty, dirty areas. It’s moving parts and electronic components can be infiltrated by dirt particles and damaged.
Page 23
● Use chargers indoors only. Only use Exmobaby for the Permitted Use herein. Do not use the Product diagnosis of infant health conditions. In the case of illness immediately seek professional medical advise.
Page 24
Care and Maintenance Disposal The crossed-out wheeled-bin symbol on your product, literature, or packaging reminds you that in the European Union all electrical and electronic products, batteries, and accumulators must be taken to separate collection at the end of their working life. Do not dispose of these products as unsorted municipal waste.
Certification Information Hereby, Exmovere declares that this Exmobaby product is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This...
Technical Specifications ① Heart shaped sensor Operating voltage:2.8~5.0V Battery level :80mAh Quiescent current:200~300μA Wireless frequency: 433.92MHz High frequency wireless transmission power:1.5±0.5 dBm Operating temperature range:﹣20~﹢55℃ ② The remote monitor Operating voltage :3.0~5.0V Battery level :600mAh Standby operating current:≤15mA Wireless frequency : 433.92MHz Wireless receiving sensitivity:overmatch﹣105 dBm Operating temperature range :﹣20~﹢55℃...
Page 27
-Increase the separation between theequipment and receiver. -Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. -Consult the dealer or an experienced radio/TV technician for help. Exmovere Wireless, LLC +1(703)227-7194 www.exmovere.com info@exmovere.com...
