Insignia NS-42D510NA15 Quick Setup Manual

QUICK
SETUP GUIDE
42" LED TV
NS-42D510NA15
Thank you
for purchasing this state-of-the-art
Insignia television. We hope you enjoy
the quality and reliability of this
television for years to come.
Roku Ready®
Your TV is certi ed to work with the
Roku Streaming Stick™.
Instantly stream 1000+ entertainment
channels, including Net ix, Hulu Plus,
Pandora, and more. Connect the
Streaming Stick (not included) to the
purple MHL port on your TV and enjoy.
Included accessories
FIND YOUR
USER GUIDE ONLINE!
We are going green so a copy of your
User Guide is not provided in the box
but is available online.
Go to www.insigniaproducts.com,
then click Support & Service. Enter your
model number in the box under Manual,
Firmware, Drivers & Product Information,
then click .
START HERE
How do I attach the stands to my TV?
(not for wall mounting)
You'll need: Phillips screwdriver and a soft surface to lay the TV on.
A Carefully place your TV face-down on a cushioned, clean surface to protect the
screen from damages and scratches
B Find the front of the left and right stands. Secure the TV stands to your TV using the
two provided M4 × 12 mm screws.
- OR -
How do I prepare my TV for wall mounting
(not for use with a TV stand)
A Carefully place your TV face-down on a cushioned, clean surface to
protect the screen from damages and scratches
B See the instructions that came with your wall mount for more
information about how to correctly mount your TV.
Which cables do you have?
Your TV has several di erent jacks for connecting devices.
STOP!
For the best video quality, use the best available
connection. Use the cables that came with your devices.
Do not plug your
power cord in until
VIDEO QUALITY
all other devices have
been connected.
BEST
BETTER
Component video and analog audio
GOOD
Composite video and analog audio (AV)
GOOD
Note: You can also connect a DVI device to your TV. See your online User Guide for connection
instructions.
Features
Front view
Remote control
and two AAA
batteries
TV stand
(left)
Back view
TV stand
(right)
M4 screws
(12 mm length)
(2 pcs.)
Images do not necessarily represent the exact design of your television.
Before using your new product, please read these instructions to prevent any damage.
A
A
MAKING CONNECTIONS
How do I watch TV (cable or satellite receiver) or connect a device such as a DVD or
Blu-ray Disc player, game console, Roku Streaming Stick™, or MHL-enabled device?
JACK TYPE CABLE CONNECTOR
Using an HDMI cable
(BEST)
HDMI video/audio
Coaxial video/audio
Using component cables (BETTER)
- OR -
Using an AV cable (GOOD)
Power indicator
Remote control sensor
How do I connect my TV to an antenna or cable wall jack?
B
M4 (12 mm)
Component cable option
AUDIO/VIDEO OUT
AV cable option
AUDIO/VIDEO
OUT
Note: Connect the yellow video cable connector
to the green Y/VIDEO jack on the back of your TV.
CABLE
M4 (12 mm)
Multi-purpose jacks: You can plug any
device that uses HDMI into the HDMI
ARC, MHL, or DVI jack. However, certain
devices must be connected to the ARC,
MHL, or DVI jack. See the instructions
that came with your ARC, MHL-enabled
device, or Roku Streaming Stick™ for
more information.
Note: The component and AV jacks
are shared. This means you can
connect only one component or AV
device at a time. We suggest using
HDMI if your device supports it.
OVER
