AMI Entertainment TAP TV Quick Install Manual

YOUR KIT INCLUDES:

A. (1) Tap-Lite unit
B. (1) wireless antenna
C. (1) power supply
D. (1) power cord
E. (1) HDMI cable
F. (1) remote control
G. (2) CR 2032 lithium batteries for remote control
H. (1) optional wall-mount bracket
I. (1) optional IR receiver
J. (1) velcro tape
1
2 3

Registering a new Tap-Lite device:

This step will only take a few minutes and requires a phone call to AMI Entertainment. Once complete,
this device will be manageable though the Operator Dashboard on amientertainment.net.
1. Call AMI Entertainment at 877-762-6765
a. Press 1 for Technical Support
b. Have the MAC address of your Tap-Lite ready
2. A Support Technician will register and assign the Tap-Lite unit to your shop location
A shop location/address will be created if you don't already have one. This location/address will also be visible inside the Tap TV app.
Tap-Lite devices assigned to your shop location will run in DEMO mode. DEMO mode devices do not participate in National rankings.
DEMO mode devices do not incur a monthly fee from AMI.

Qualifying a location for installation:

Before installing a Tap-Lite device, it is recommended that you test mobile 3G/4G coverage (for carriers common to your area) within the venue.
For best results, test from various places around the venue where Tap TV will be visible on television screens. In the event there is no 3G/4G coverage
or the signal is very poor, it is recommended that a WiFi connection be provided for patrons to use within the venue. In the absence of 3G/4G coverage
or a WiFi option, app users will not be able to interact with Tap TV.

Assigning a registered device to a location:

This step requires you to log in to the Operator Dashboard on amientertainment.net. All Tap-Lite devices require a subscription to operate. Devices assigned
to your shop operate under a free DEMO mode subscription. Devices assigned to a non-shop location, for example a bar or restaurant, require a paid subscrip-
tion. Once created, you can cancel this subscription at any time to stop AMI monthly sweeps. See your Master Agreement for additional details.
1. Log in to the Operator Dashboard on
2. Select the Tap TV tab and locate this device by the MAC address
3. Click on the device's name
4. Edit the device's location by choosing an existing location or creating a new one
5. If the selected location does not have a subscription to the Tap TV Channel you wish to provide, a new subscription must be added
This step should be completed prior to a new installation. Once complete, this new location will appear inside the Tap TV app.
All Tap TV operators are required to sign the 2013 Tap TV Master Operator Agreement. If you were
not presented with this Agreement at the point of sale, please contact AMI Inside Sales at
877-762-6765. This step must be completed before attempting to register a new Tap-Lite system.
Once registered, your Tap-Lite system will be easy to install using this guide and the on-screen
instructions. Support for Tap TV is available 24/7 by calling 877-762-6765. Your location is about
to get TAPPED IN to great entertainment!
A
F
4
FRONT VIEW:
1. Power switch
2. WiFi status indicator
3. IR receiver
4. USB 2.0 ports
amientertainment.net
TAP TV QUICK INSTALL GUIDE
B C
G H
1
2 3
D E
I J
5
REAR VIEW:
1. Power input (DC19V)
2. HDMI output
3. USB 3.0 ports
4. USB 2.0 ports
5. Ethernet port
6. WiFi antenna connector
4 6
Affix MAC address label here
»
Continued
