akira LCT-37KX1DSTP Service Manual

Lcd tv
Hide thumbs

Advertisement

Quick Links

Download this manual
LCD TV

Service Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the LCT-37KX1DSTP and is the answer not in the manual?

Questions and answers

Related Manuals for akira LCT-37KX1DSTP

Summary of Contents for akira LCT-37KX1DSTP

  • Page 1: Service Manual

    LCD TV Service Manual...
  • Page 2 -2 - MODEL: LCT-37KX1DSTP Model No.: LCT-32KX1DSTP.doc Version: 1.0...
  • Page 3 -3 - CONTENTS SAFETY PRECAUTION ......................4 SPECIFICATION ........................5 APPEARANCE OF REMOTE CONTROL................10 EXPLODED VIEW AND PART NAME..................11 CIRCUIT DIAGRAM .........................14 REPLACEMENT PARTS ......................46 INSTALLATION GUIDE ......................59 TROUBLESHOOTING ......................63 Model No.: LCT-32KX1DSTP.doc Version: 1.0...
  • Page 4 -4 - IMPORTANT SAFETY PRECAUTION Model No.: LCT-32KX1DSTP.doc Version: 1.0...
  • Page 5 -5 - SPECIFICATION Category Dimension Type LCD Panel / AU Aspect Ratio 16:9 Refresh Rate 50Hz, 60Hz Supported Pixel Rate 1366 x 768 Interface LVDS PAL / Sound System :B/G, D/K, I Analog SECAM SECAM Sound System :B/G, D/K, L/L’ Component 1 480i / 576i, 480p / 576p, 720p, 1080i CVBS;...
  • Page 6 -6 - Category Dimension AV / S-VIDEO Sharing Audio-In SCART 1 Full SCART Type (RGB IN, CVBS IN, TV OUT, Stereo In / Out ) SCART 2 Full SCART Type (RGB IN, CVBS IN, CVBS OUT, Stereo In / Out) TV Antenna Antenna In ( 75 ohm ) AV2 / S-Video2 /...
  • Page 7 -7 - 5 Picture Modes (User / Dynamic / Standard / Mild / Game ) 7 Aspect Ratio Modes (16:9, 14:9, 4:3, Full, Zoom, Original, Spectacle) Sound Volume / Balance Band Equalizer Mono / Stereo / MTS Auto Volume 5 Sound Standard (User, Flat, Music, Movie, Special) PC Function Auto Adjustment...
  • Page 8 -8 - 3) PIP & PBP Support Table Component Component SUB MAIN SCART1 SCART2 HDMI S-VIDEO SCART1 SCART2 AV/ S-VIDEO Component Component HDMI AV/S-VIDEO SOMETIMES CAN’T PIP 4) PC compatibility chart To reduce the need for adjustment for diferent modes ,the TV has default setting modes that are most commonly used ,These are shown in the table below .For optimum adjustment ,the user is suggested to perform the Auto Setup is Windows "Full Screen"pattern.
  • Page 9 -9 - 1024*768 78.75 1152*864 67.5 1280*720 1280*960 1280*1024 63.981 1366*768 47.7 85.5 (recommended resolution is 1024*768@60Hz) Model No.: LCT-32KX1DSTP.doc Version: 1.0...
  • Page 10 -10 - Appearance Remote Control Model No.: LCT-32KX1DSTP.doc Version: 1.0...

  • Page 11: Exploded View And Part List

    -12 - Exploded View and Part List Model No.: LCT-32KX1DSTP.doc Version: 1.0...

  • Page 12: Parts List

    -13 - PARTS LIST PART CODE DESCRIPTION 305T370109010 DECORATING NET 101T370102010 FRONT CABINET 110E270104000 LENS 101T370102030 FUNCTION BUTTON 7516T37010010 FUNCTION KEY 6020BTW030080 SELF TAPPING BT3 x 8 (BLACK) 305E270103003 LOUDSPEAKER 6020BTB040100 SELF TAPPING BT4 x 10 (BLACK) 305T370102010 BRACKET SUPPORT FOR USE (UP) 305T370102020 BRACKET SUPPORT FOR USB (DOWN) 6020BMW030060...
  • Page 13 -14 - PART CODE DESCRIPTION 7536T3202003A MAIN PCB SUB-ASSEMBLY 305T37010403A TERMINAL BRACKET (MAIN 305T370101020 MAIN SHIELD COVER 305T370106010 REAR BRACKET 6020KMB040080 MACHINE SCREW KM4 x 8 101T370102020 BACK COVER 305T300100130 FIXED FERRULE 6020BMZ050160 MACHINE SCREW BM5 X 16 6060T37010020 RUBBER 305T370110010 BASE GLASS 6020BMB050100...
  • Page 14 -15 - ELECTRICAL DIAGRAMS PRINT LAY-OUT Model No.: LCT-32KX1DSTP.doc Version: 1.0...
  • Page 15 LCD702C: SVP-EX52(256) +M16C+ HDMI+SIL9011- Block Diagram LVDS 4Mx32 SVP_EX52 SCART1 SCART2 SAA7117A 8bit SCART3 PIP Decode 24bit KEY_IN M16C MSP3410 RS232 Sil9011 PipTV 5V330 MainTV Y Pb Pr RS232 S/PDIF HDMI PC/RGB Y2/C2 Y1/C1 phone PC_AUDIO INPUT MENU POWER Title Size Number Revision...
  • Page 16 FB31 VCC_ SS6085-ADJ 2.2uH FB28 TO-252 3.3V Powerfor PVDD C257 C258 C260 C250 C249 VDDMQ Power for DDR IO PADS C259 0.1uF HCB3216K-122T10 AMS_1117/2.5V 22uF/16V 0.1uF 22uF/16V 22uF/16V 0.1uF FB30 Linear equation:Vout=1.25v*(1+R105/R106) C255 C256 HCB3216K-122T10 C253 C254 Linear condition: 100ohm < (R105) <200ohm 0.1uF 22uF/16V VD3_3...
  • Page 17 DIN[0..23] CON2 RN32 33x4 DIN0 CLK_2EX DIN1 DIN2 DIN3 RN33 33x4 DIN4 DIN5 DIN6 DIN7 DIN8 CON10 Digital InputConnector CN 8 LVDS-CON FEMALE Label "LVDS" in silk screen. PVDD PVDD could be 12V,3.3V ,5V. R317 R318 4.7K MOSFET P TXOUT0- TXOUT0- TXOUT0+ TXCLK-...
  • Page 18 AD[0..7] When use W27E040,use R398 andR399;R400 and R404 are Option. TP43 TP32 TP33 TP34 TP35 TP36 TP37 TP38 When use W29C040,use R404 andR400;R398 and R399 are Option. 5V-1_CPU A[0..7] R826 R827 R828 RN26 33x4 4.7K 4.7K 4.7K R829 Detect_VGA RN30 33x4 RN27 33x4...
  • Page 19 MPUGPIO0 MPUGPIO0 VDDMQ VDDMQ MPUGPIO1 MPUGPIO4 MD[0..31] MPUGPIO4 Test pads for DDR P_17 P_17 P_17 FLD/IO MCLK0 SDA_EX 3V_SDA TP_T_C30 SCL_EX 3V_SCL RN24 33x4 DQS2 MD10 MD10 A_D7 TP_T_C30 MD11 MD11 A_D6 68pF 68pF MD12 MD12 A_D5 DQM0 MD13 MD13 A_D4 TP_T_C30 RN25...
  • Page 20 CVBS1 Y_G1 Y_G2 CVBS1 TV_MAIN Y_IN VGA_G VGA_GIN DIN[0..23] 0.1uF 0.1uF 0.1uF 75_DNS 75_DNS DIN23 DIN23 DIN22 DIN22 AGND DIN21 DIN21 0_DNS Place 75 ohmresistors close toSVP-EX DIN20 DIN20 DE_2EX AGND AGND DVS_2EX MLF1 CVBS2 PB_B1 PB_B2 MLF1 MLF1 DHS_2EX CVBS2 CVBS_2 PB_IN...
  • Page 21 C365 22nF R481 AI11 AI11 S1_Y C366 22nF R482 AI21 AI21 S1_R/C C367 22nF R483 AI31 AI31 S1_G R568 R537 C368 22nF R485 AI41 3V_SCL AI41 S1_B 4.7K R538 3V_SDA R487 CVBS_OUTP AI33 CVBS_OUTP INT_A AI33 S1_AV R488 AI34 AI34 S1_FSW C371 22nF...
  • Page 22 4.7K R805 R275 5V_SB R804 + C215 R280 R272 BKLT_CNTL BKLT_CNTL 47uF 4.7K 4.7K CON18A &CON18B MM3904 12V is reserveed for small panel invertor 5V_SB FROM POWER UNIT BRT_CNTL R264 R265 5_PIN_WATER_CONNECTOR BACKLIGHT CONNECTOR 5V_SB SB_PWR MMBT3904 R594 RED LED STANDBY: 0 YELLOW LED 4.7K...
  • Page 23 3V3S C126 C127 C128 C458 C459 C129 C130 C460 C461 C462 C463 C464 C465 5V_SB 10uF/16V 0.1uF 0.1uF 0.1uF 0.1uF 1000pF 1000pF 1000pF 1000pF 1000pF 1000pF 1000pF 1000pF RX_INT# R319 RX_HOTPLUG RX_HOTPLUG IN_5V SCDT 4148 R820 RST# DE_2EX CON3 C118 0.1uF RX3V_DDC_SDA RX3V_DDC_SDA...
  • Page 24 +5V_DAC AUDIO_R IIS_DATA SDIN AOUTR AUDIO_R IIS_SCK DEM/SCLK C356 C357 IIS_WS LRCK AUDIO_L MCLK MCLK AOUTL AUDIO_L 0.1uF 3.3uF/16V FILT+ C359 C360 C358 CS4344 10uF/16V AGND 3.3uF/16V 0.1uF AGND AGND C361 3.3uF/16V R473 +5V_DAC AUDIO_L AUDIO_L AOUT_L FB38 R474 R475 C362 150_Ohm_600mA 2700pF...
  • Page 25 15x4 MD[0..31] Test pads for DDR MCLK0 MCLK0 TP_T_C30 15x4 DDQS DDQS TP_T_C30 DQM0 DQM0 TP_T_C30 15x4 DQ23 TP10 DQ16 DQ23 TP_T_C30 DQ17 DQ10 MD10 /CAS CAS# /CAS CAS# CAS# DQ18 DQ11 MD11 /RAS RAS# /RAS RAS# TP11 DQ19 CAS# CS0# CS0# TP_T_C30...
  • Page 26 120 OHM@100MHz CVBS_2_IN CVBS_2 C194 C195 R843 330pF 330pF From SiI9011 CON9 CON7 RCA_Jack C413 R542 AGND AGND SPDIF 120 OHM@100MHz 120 OHM@100MHz C_IN1_IN L_IN1_IN 0.1uF C_IN1 L_IN1 R534 C196 C197 100K R844 C198 C199 R845 330pF 330pF 330pF 330pF AGND C211 0.01uF...
  • Page 27 3.3V_SB CON14 DB15 R547 DL4148 R229 R230 2.2K 2.2K R231 VGA_RIN FB23 R235 VGA_SDA_IN VGA_GIN 150_Ohm_600mA R236 VGA_HS VGA_BIN CVBS S1_Y S2_Y R549 VGA_VS TV_PIP FB26 R548 DL4148 S2_R/C VGA_SCL_IN S1_R/C CVBS_OUT DL4148 S1_FSW 150_Ohm_600mA S1_AV S2_G S1_G R239 R240 VGA_P9 S2_FSW S2_AV...
  • Page 28 C105 330nF Audio4_L Audio4_L C106 330nF Audio4_R Audio4_R YUV1_L C107 330nF YUV1_L YUV1_R C108 330nF YUV1_R Audio2_L C109 330nF Audio2_L C110 330nF Audio2_R Audio2_R C111 330nF 37/40 LCD TV Audio1_L Audio1_L E100 10uF/16V C112 330nF C115 100nF Audio1_R Audio1_R Vout U100 E109 10uf/16V...
  • Page 29 5VAA_2 Audio2 CVBS_M Audio4 R250 SW11 SW10 Audio4 SCART1 S1_Y YPbPr2 SVIDEO1 C200 SCART2 100nF + C248 E200 S2_Y AOUT 10uF/16V SVIDEO2 R258 R254 R256 R255 R257 R252 R253 R251 100uF/16V AV1+SVIDEO1 DIGITAL_TV AV2+SVIDEO2 DIGITAL_TV 100uF C237 TV_MAIN U203 100uF SVIDEO2_Y C238 NONE...
  • Page 30 RB312 22/DNS C305 E305 0.1uF/DNS U300 OFFSET NULL1 OFFSET NULL2 470uF/DNS INVERSE INPUT VCC+ E304 RB309 MAIN TUNER 1K/DNS R300 CVBS_S S1_CVBS_OUT CVBS_S NON-INVERSE INPUT OUTPUT S1_CVBS_OUT RB302 100uF/DNS RB307 75/DNS L305 5VAA_2 VCC- CN308 B300 10K/DNS RB310 DVBT_Y3 TSH31 1K/DNS U301 5VAA_2...
  • Page 31 C404 5VCC R414 B400 BEAD 5VAA_1 330pF C430 100nF E400 10uF/16V 120@100M L400 3.3uH L408 R402 S1_Y S1_FSW S1_Y S1_FSW C400 C401 R400 R401 R412 S1_AV S1_AV CVBS/Y 0.1uF 330pF / DNS 330pF / DNS R416 modify 1 SCART1_L_IN C406 3.9K SCART1_R_IN 5VCC...
  • Page 38 Multistandard video decoder with adaptive SAA7117(A)H/V2 comb filter and component video input SAA7117(A)E/V2...
  • Page 39 Multistandard video decoder with adaptive SAA7117(A)H/V2 comb filter and component video input SAA7117(A)E/V2 Analog Frontend 3.2.1 Analog Frontend of SAA7117A 3.2.1.1 Overview The SAA7117A offers sixteen analog signal inputs, which are fed to four analog main channels with source switches, clamp circuits, analog amplifiers, and 10-bit CMOS ADCs with decimation filters.
  • Page 40 SAA7117(A)H/V2 Multistandard video decoder with adaptive SAA7117(A)E/V2 comb filter and component video input DNC6 DNC12 AI41 DNC11 AGND DNC8 V SSA4 DNC7 AI42 DNC2 AI4D DNC1 AI43 V DDD9 V DDA4 HPD0 V DDA4A HPD1 AI44 HPD2 AI31 HPD3 V SSA3 HPD4 AI32 V SSD8...
  • Page 41 SAA7117(A)H/V2 Multistandard video decoder with adaptive SAA7117(A)E/V2 comb filter and component video input ORDERING INFORMATION PACKAGE TYPE NUMBER NAME DESCRIPTION VERSION plastic ball grid array package; 156 balls; body 15 × 15 × 1.15 mm SAA7117E/V2 BGA156 SOT472-3 SAA7117E/V2/G BGA156 leadfree version of SAA7117E/V2 SOT472-3 plastic ball grid array package;...
  • Page 42 SAA7117(A)H/V2 Multistandard video decoder with adaptive SAA7117(A)E/V2 comb filter and component video input SYMBOL TYPE DESCRIPTION QFP160 BGA156 AI11 analog input 11 ground for analog inputs AI1x SSA1 AI12 analog input 12 AI1D differential input for ADC channel 1 (pins AI14 to AI11) AI13 analog input 13 analog supply voltage for analog inputs AI1x (3.3 V)
  • Page 43 SAA7117(A)H/V2 Multistandard video decoder with adaptive SAA7117(A)E/V2 comb filter and component video input SYMBOL TYPE DESCRIPTION QFP160 BGA156 serial clock input (I C-bus) digital ground 4 (core; connects to substrate) SSD4 I/O/od serial data input/output (I C-bus) RTS0 real-time status or sync information, controlled by subaddresses 11h and 12h RTS1 real-time status or sync information, controlled by subaddresses...
  • Page 44 SAA7117(A)H/V2 Multistandard video decoder with adaptive SAA7117(A)E/V2 comb filter and component video input SYMBOL TYPE DESCRIPTION QFP160 BGA156 IPD1 MSB6 of image port data 1 output digital supply voltage 7 (core, 1.8 V) DDD7 IPD0 LSB of image port data 1 output HPD7 MSB0 of host port data I/O, extended C input for expansion port,...
  • Page 45 SAA7117(A)H/V2 Multistandard video decoder with adaptive SAA7117(A)E/V2 comb filter and component video input SYMBOL TYPE DESCRIPTION QFP160 BGA156 XPD4 MSB3 of expansion port data digital supply voltage 10 (core, 1.8 V) DDD10 digital ground 10 (core) SSD10 XPD3 MSB4 of expansion port data XPD2 MSB5 of expansion port data digital supply voltage 11 (peripheral cells, 3.3 V)

  • Page 46: Replacement Parts List

    -46 - REPLACEMENT PARTS LIST PART CODE DESCRIPTION LOCATION CONTROL BOARD 405T320200110P 410A010300020 LEDφ3 RED / GREEN COLOUR 4121010116J40P CARBON RES. 1/6W-100Ω R900 4121010316J40P CARBON RES. 1/6W-10KΩ R901 4121015216J40 CARBON RES. 1/6W-1.5KΩ R903 905 4121033216J40 CARBON RES. 1/6W-3.3K R902 906 4121051216J40 CARBON RES.
  • Page 47 -47 - PART CODE DESCRIPTION LOCATION 4138223102K00 METAL MYLAR CAPA.. 1000V-0.022µF-K 4138224275M00 METAL MYLAR CAPA.. 275V-0.22µF-M C1,2 4138564451J00 METAL MYLAR CAPA.. 450V-0.56µF-J C21,22 414010216RM60P EL-CAP, 16V-1000uF M, [JICON][ROHS] C301,302 EL-CAP,105°High Frequency / Low 414022216RM03P C36,40 Impedance, [JICON][ROHS] EL-CAP,105°High Frequency / Low Impedance 414110116RM03P C114 C115 16V-100Uf-M(CRY-06)[ROHS]...
  • Page 48 -48 - PART CODE DESCRIPTION LOCATION L2，L101 4290235011000 INDUCTOR 3.5X1X10 120Ω, RN10 4290250R00040 INDUCTOR 50Ω (100MHz) FB105,106,107 4290301614000 INDUCTOR LCL-1614 42905703RJ000 INDUCTOR TB0624A0070 7uH L304 L305 42905TD1415A0 INDUCTOR TD1415A0100, 10uH L301 42905TT1206A2 INDUCTOR TT1206A2001 1.8mH L303 4320005001000 JUMPER 10mm 4320006000900 JUMPER 9mm 412700R01AJ60 CHIP RES 1/10W-0Ω-J 0805...
  • Page 49 -49 - PART CODE DESCRIPTION LOCATION 413510450RZ40 CHIP CAPA 50V-104 0805 Z C308 C12,13,14,15,17,106 413510550RZ50 CHIP CAPA 1206 50V-1uF-Z 413522250RK40 CHIP CAPA 0805, 50V-222 K C7,8 413533150RK40 CHIP CAPA 50V-330P 0805 K 413547250RK40 CHIP CAPA 50V-472 0805 K 413547350RK40 CHIP CAPA 0805, 50V-0.047uF-K C306 C23 415000SS14010 CHIP DIODE SS14 1A/40V...
  • Page 50 -50 - PART CODE DESCRIPTION LOCATION 413547150RK40 CHIP CAPA 50V-470P 0805 K C304 41600AOD40500P CHIP MOSFET AOD405 TO-252 Q103 412701531AF80 CHIP RES.1/10W-15KΩ 0603 F R202 4170MP1410010 IC MP1410 U201 413510325RK60 CHIP CAPA 0603, 25V-103-K C201 C202 42904223RM000 CHIP INDCUTOR KDRH104R-220 22uH L201 4152B340A1100 CHIP DIODE B340A-11...
  • Page 51 -51 - PART CODE DESCRIPTION LOCATION CRYSTAL OSILLATOR (49S)24.576MHZ 4240057662411 (20PF, +-20PPM） 4105010300060 LED 0805, A0805G1C-1A-01 412700R01AJ60 CHIP RES. 1/10W-0Ω-J 0805 R552 R6 231 235 236 250 251 254 266 267 317 408 413 415 421 481 482 483 485 412700R01AJ80 CHIP RES.1/10W-0Ω...
  • Page 52 -52 - PART CODE DESCRIPTION LOCATION 412704731AJ80 CHIP RES.1/10W-47KΩ 0603 J R237 238 246 247 417 4127047R1AJ80 CHIP RES.1/10W-47Ω 0603 J R446 491 495 501 503 412705111AJ80 CHIP RES.1/10W-510Ω 0603 J R21 158 412705131AJ80P CHIP RES.1/10W-51KΩ 0603 J R146 4127051R1AJ80 CHIP RES.1/10W-51Ω...
  • Page 53 -53 - PART CODE DESCRIPTION LOCATION C365-368 371-375 377 379 380 381 413522350RZ60 CHIP CAPA.50V-0.022µ 0603 Z 382 383 400 413527150RK60 CHIP CAPA.50V-270P 0603 K C388 391 394 397 413527250RK60 CHIP CAPA.50V-2700P 0603 K C35 42 362 364 393 396 399 413530R50RJ60 CHIP CAPA.50V-30P 0603 J NPO C471 384 385...
  • Page 54 -54 - PART CODE DESCRIPTION LOCATION IC AMS1117-2.5V （TO-252） 417AMS1117250 IC（T0-252）AZ1084D-1.8TR 417AZ1084S1V8 IC（T0-263）AZ1084S-3.3V 417AZ1084S3V3 U27 43 417FSAV330M10 IC (SO16)P15V330/FSAV330M 417M30620SP10 IC M30620SPGP , LQFP100-P-1414-0.5 417SAA7117H00 IC SAA7117H QFP160 417SN74LVC140P IC SN74LVC14ADR SO14 420FT15013010 SOCKET, DF14-30S-1.25C 420HM32021910 HDMI SOCKET, HMR41-AK5200 CON3 42815R0082010 CHIP RES.15Ω*4 0603 RN1-8...
  • Page 55 -55 - PART CODE DESCRIPTION LOCATION 414122R16RM00 EL-CAPA. 5*11, CD110-16V-22uF-M C154 414147116RM00P EL-CAPA. 8*12, CD110-16V-470uF-M[ROHS] E107 C424 425 414147125RM00 EL-CAPA.25V-470uF M≤φ8*15 C143-146 152 414147R16RM00 EL CAPA16V-47uF Mφ5*7 E110 111 C157 236 237 417000078L080 DIODE ZENER 78L08 U100 417TDA8947J10P IC TDA8947J/N3 SOT243-1[ROHS] U103 4202T32020010 RCA SOCKET AV2-8.4-13...
  • Page 56 -56 - PART CODE DESCRIPTION LOCATION 412705121AJ80P CHIP RES.1/10W-5.1KΩ 0603 J[ROHS] R415 416 412705621AJ80P CHIP RES.1/10W-5.6KΩ 0603 J[ROHS] R450 452 4127075R1AJ80P CHIP RES.1/10W-75Ω 0603 J[ROHS] R302 R400-411 413510150RJ60P CHIP CAPA.50V-100P 0603 J NPO[ROHS] C100 101 413510250RK60 CHIP CAPA.50V-102-K 0603 C126 127 129 130 426-429 C114-117 147 148 150 151 200-202 413510425RZ60 CHIP CAPA.25V-104 0603 Z...
  • Page 57 -57 - PART CODE DESCRIPTION LOCATION C166 229 230 231 232 234 245-248 414110116RM00 EL-CAP 16V-100uF M φ6*7 488 490 491 E118 180 300-303 414110R16RM00P EL-CAP 16V-10uF-M[ROHS] E100-107 C237 238 240 241 242 E110 111 E200 201 202 203 306 400 414147R16RM00 EL-CAP 16V-47uF Mφ5*7 401 CEK01...
  • Page 58 -58 - PART CODE DESCRIPTION LOACTION C126 127 129 130 142 143 146-149 413510250RK60 CHIP CAPA.50V-102-K 0603 426 427 428 429 C114-117 144 145 163 167 200 413510450RZ60P CHIP CAPA.50V-104 0603 Z[ROHS] 300-304 406 407 430 431 201 202 244 164 C152156 413510510RZ60P CHIP CAPA.10V-1µ...

  • Page 59: Installation Instruction

    -59 - INSTALLATION INSTRUCTION HANG ON THE WALL Step 1 : Disassemble the pedestal. Step 2 : Install part A on the wall. Step 3 : Hang the TV on the wall Note : 1. Installtion of the display unit on the wall should be carried out by qualified serviceman.
  • Page 60 -60 - FRONT BACK Model No.: LCT-32KX1DSTP.doc Version: 1.0...
  • Page 61 -61 - Model No.: LCT-32KX1DSTP.doc Version: 1.0...
  • Page 62 -62 - ANTENNA Model No.: LCT-32KX1DSTP.doc Version: 1.0...

  • Page 63: Troubleshooting Guide

    -63 - TROUBLESHOOTING GUIDE Model No.: LCT-32KX1DSTP.doc Version: 1.0...
  • Page 64 -64 - Model No.: LCT-32KX1DSTP.doc Version: 1.0...
