Jaybo REULEAUX Quick Manual

Reuleaux Overview

Back cover

How to use

1. Lock/Unlock: Tap the fire button and the screen will
display "Locked, Click 5X". Press the fire button five times in
quick succession to lock and unlock the device.
2. Profiles setting: Reuleaux allows you to save and select between eight
groups of output settings. Each group of output settings is called a Profile. In
Power Locked mode, double click the up or down button to
cycle between profiles. To select the displayed profile, press
the fire button.
3. Stealth function: In locked mode, holding the fire and
down buttons simultaneously will switch to stealth mode. In
this mode the display is off. Switch back to normal display
mode in the same way.
4. Power locked function: Holding down both the up and
down buttons will place the device in Power Locked mode.
Exit Power Locked mode in the same way.
5. Resistance locked function: In locked mode, hold
both the fire and up buttons to enter Resistance Lock mode.
To disable resistance lock, repeat the procedure.
6. Reverse Polarity System for Batteries: If installed improperly, the
plastic hoop will prevent the battery touching the opposite contact head.
Top
200W
Quick Guide
510 spring connector
Fire button
Ventilation holes
OLED Screen
Up button
Down button
Charging port
LOCKED
CLICK 5X
PROFILE 1
STEALTH
MODE
NORMAL
MODE
POWER LOCKED
HOLD UP DOWN
200W
0.00
0.00V
450F
Bottom
