Snell Advanced Media IQEDGE-25-6B User Manual

Iqedge series 3g/hd/sd-sdi multi-channel ip processing system 25/40gbe

Advertisement

User Manual
IQEDGE
3G/HD/SD-SDI Multi-channel IP Processing System 25/40GbE
www.s-a-m.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IQEDGE-25-6B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Snell Advanced Media IQEDGE-25-6B

  • Page 1 User Manual IQEDGE 3G/HD/SD-SDI Multi-channel IP Processing System 25/40GbE www.s-a-m.com...
  • Page 2: Information And Notices

    IQEDGE Information and Notices Information and Notices Copyright and Disclaimer Copyright protection claimed includes all forms and matters of copyrightable material and information now allowed by statutory or judicial law or hereinafter granted, including without limitation, material generated from the software programs which are displayed on the screen such as icons, screen display looks etc.
  • Page 3: Safety Information

    IQEDGE Safety Information Safety Information Explanation of Safety Symbols Erklärung der Sicherheitssymbole This symbol refers the user to important information contained in Dieses Symbol weist den Benutzer auf wichtige Informationen the accompanying literature. Refer to manual. hin, die in der begleitenden Dokumentation enthalten sind. Dieses Symbol zeigt an, dass gefährliche Spannung vorhanden ist.
  • Page 4 IQEDGE Safety Information Simboli di sicurezza: Forklaring på sikkerhedssymboler Questo simbolo indica l'informazione importante contenuta nei Dette symbol gør brugeren opmærksom på vigtig information manuali appartenenti all'apparecchiatura. Consultare il manuale. i den medfølgende manual. Questo simbolo indica che all'interno dell'apparato sono presenti Dette symbol indikerer farlig spænding inden i apparatet.
  • Page 5: Safety Standards

    IQEDGE Safety Information Símbolos de Segurança O símbolo triangular adverte para a necessidade de consultar o manual antes de utilizar o equipamento ou efectuar qualquer ajuste. Este símbolo indica a presença de voltagens perigosas no interior do equipamento. As peças ou partes existentes no interior do equipamento não necessitam de intervenção, manutenção ou manuseamento por parte do utilizador.
  • Page 6 IQEDGE Safety Information EMC Standards This equipment conforms to the following standards: EN 55103-1: 1996 (Environment E4) Electromagnetic Compatibility, Product family standard for audio, video, audio-visual and entertainment lighting control apparatus for professional use. Part 1. Emission. EN 55103-2: 1996 (Environment E2) Electromagnetic Compatibility, Product family standard for audio, video, audio-visual and entertainment lighting control apparatus for professional use.
  • Page 7: Table Of Contents

    IQEDGE Contents Contents Information and Notices ..........2 Safety Information .
  • Page 8 IQEDGE Contents 5.24.2 RollTrack Index ..........49 5.24.3 RollTrack Source.
  • Page 9: Introduction

    IQEDGE Introduction 1. Introduction 1.1 Description The IQEDGE is a 3RU/4RU enclosure containing an IQMIX IP transceiver module and a customer-defined selection of audio/video processing modules; 3RU models are also equipped with a cooling fan. Signals are received over IP, converted into SDI, processed, then converted back to IP for onward transmission.
  • Page 10: Application Notes

    IQEDGE Introduction • SMPTE-291M metadata support via IETF standard RTP Payload for Ancillary Data. • Timing and synchronization provided by IEEE-1588v2 (PTP), compliant with SMPTE-2059-2, or via the frame analog reference bus. • Up to 4 dual-channel IQ modules per IQEDGE rear panel, giving up to 8 processing channels, dual PSUs, cooling fans and control card as standard, plus full chassis monitoring for PSUs, temperature, fans and signal status.
  • Page 11: Block Diagrams

    IQEDGE Introduction 1.4 Block Diagrams 1.4.1 IQEDGE Processing Lanes In order to improve throughput, the IQEDGE provides two processing lanes. When used with dual-channel IQ modules, each module is able to process two jobs simultaneously. The processing lanes are independent of one another, and map directly to the processing channels of suitable IQ processing modules;...
  • Page 12: Order Codes

    1.5 Order Codes 1.5.1 Enclosure and IP Interface Options The following product order codes are covered by this manual: IQEDGE-25-6B IQEDGE 7-Slot 3RU IP processing system with dual 25GbE IP connections. Up to 4 card slots for processing available. Includes dual PSUs, dual fans, Ethernet/SNMP compatible RollNet Gateway and reference distribution.
  • Page 13: Rear Panel View

    IQEDGE Introduction 1.6 Rear Panel View The following rear panel types are available: Figure 2 IQEDGE25-6B3 Figure 3 IQEDGE40-6B3 Issue 1 Rev 1 Page 13 © 2017 SAM...
  • Page 14: Technical Specification

    IQEDGE Technical Specification 2. Technical Specification Inputs/Outputs - EDGE backplane Ethernet Connector/Format 25GbE = SFP+ 40GbE = QSFP Conforms to RFC4175 RFC3190 SMPTE-291M/IETF RTP Payload for Ancillary Data VC-2 IEEE-1588v2/SMPTE-2059-2 VSF TR-03/TR-04 RTP (upgradeable to SMPTE 2110) or SMPTE 2022-6/7 AES67 For information on IQH3B and IQH4B enclosures, IQMIX IP transceiver modules and Note:...
  • Page 15: Connections

    IQEDGE Connections 3. Connections This section describes the physical input and output connections provided by the IQMIX IP transceiver modules. 3.1 25G Ethernet SFP SFP+ supporting 25G Ethernet. 3.2 40G Ethernet QSFP QSFP+ supporting 40G Ethernet. Issue 1 Rev 1 Page 15 ©...
  • Page 16: Card Edge Leds

    IQEDGE Card Edge LEDs 4. Card Edge LEDs The LEDs on the edge of the module indicate its operating status. Front Panel Description   BOARD   All primary power rails use an LED,   e.g. +7v5; other power rails used on the module, e.g.
  • Page 17: Rollcall Control Panel

    IQEDGE RollCall Control Panel 5. RollCall Control Panel This section contains information on using IQEDGE with RollCall. For help with general use of the RollCall application, open the user manual by clicking the button on the main RollCall toolbar. 5.1 Terminology The following terms are used in this document: Term Description...
  • Page 18: Setting Values

    IQEDGE RollCall Control Panel • Ethernet 1 and 2 RTP Receiver - See section 5.11. • Ethernet RTP Receiver Video Stats - See section 5.12. • Ethernet RTP Receiver Audio Stats - See section 5.13. • Ethernet RTP Receiver Meta Stats - See section 5.14. •...
  • Page 19: Configuration

    IQEDGE RollCall Control Panel 5.4 Configuration The Configuration page allows basic module parameters to be set. Figure 6 Configuration Page The following facilities are available from this page: Option Operation Where Am I Causes the front-edge LEDs to flash, allowing the module to be easily identified.
  • Page 20 IQEDGE RollCall Control Panel Option Operation Domain RollCall+ uses domains to partition a network. Only nodes on the same domain can communicate with one another. A domain is uniquely identified with a number and a friendly name/alias. Set an ID as required, then press Take to confirm the change.
  • Page 21: Edge Configuration

    IQEDGE RollCall Control Panel 5.5 Edge Configuration The Edge Configuration page allows the card slots controlled by the EDGE backplane to be monitored, and the modules to be used in a workflow specified. Figure 7 Edge Configuration Page The page consists of two sections, one for Lane 1 and one for Lane 2. These display slot maps, i.e.
  • Page 22: Loop Enable

    IQEDGE RollCall Control Panel 5.5.1 Loop Enable Enables the Loop function for the applicable slot. 5.5.1.1 About the Loop Function Loop Enable disables IP routing for a slot, and daisy chains it via SDI to the next higher slot number along. This has the effect of starting or continuing a daisy chain, and sending the signal along it to the next slot for further processing.
  • Page 23 IQEDGE RollCall Control Panel Example 3: Creating Two 3-slot Daisy Chains on Separate IQEDGE Lanes Lanes cannot be crossed with SDI looping, but can with IP addressing. In this case, each chain is created as usual, but the link between the two must be created over IP.
  • Page 24 IQEDGE RollCall Control Panel Figure 9 Spigot Page - IP Details • Enter the IP details noted in the step above, and click S to save. As Loop Enable has not been selected for Slots 3 and 6, IP routing remains in place and so the signal will be routed across lanes and onwards via IP.
  • Page 25: Time Sync Configuration

    IQEDGE RollCall Control Panel 5.6 Time Sync Configuration The Time Sync Configuration page allows selection of the source to be used for synchronizing flows, and any properties associated with the relevant source to be configured. Figure 10 Time Sync Configuration Page The following facilities are available from this page: Option Operation...
  • Page 26: Tpg (Test Pattern Generator)

    IQEDGE RollCall Control Panel 5.7 TPG (Test Pattern Generator) The TPG page allows test patterns to be applied on a spigot-by-spigot basis. Figure 11 TPG Page The following options are available for each spigot: Option Operation Select the test pattern to apply to the spigot from the drop-down list.
  • Page 27: Counters

    IQEDGE RollCall Control Panel 5.8 Counters The Counters page allows the various counters provided to be cleared down. Figure 12 Counters Page Click Clear buttons as required. Issue 1 Rev 1 Page 27 © 2017 SAM...
  • Page 28: Ethernet 1-3

    IQEDGE RollCall Control Panel 5.9 Ethernet 1-3 The Ethernet pages show details and status for each network interface. The module defaults to use of DHCP, but this can be overridden and a static IP address defined if required. Figure 13 Ethernet N Page 5.9.1 The Ethernet Pane The Ethernet pane displays details of the currently selected network interface, and allows a...
  • Page 29: Ethernet 1 And 2 Rtp Sender

    IQEDGE RollCall Control Panel 5.10 Ethernet 1 and 2 RTP Sender The RTP Sender page displays the amount of data transmitted, on a spigot-by-spigot basis. Units are megabits per second. Click Enable Stats to display values. Figure 14 Ethernet 1 & 2 RTP Sender Page Issue 1 Rev 1 Page 29 ©...
  • Page 30: Ethernet 1 And 2 Rtp Receiver

    IQEDGE RollCall Control Panel 5.11 Ethernet 1 and 2 RTP Receiver The RTP Receiver page displays the amount of data received, plus details of packet loss, on a spigot-by-spigot basis. Units are megabits per second. Click Enable Stats to display the values. These can be reset using the Clear RTP Count and Clear Error Count buttons, as required.
  • Page 31: Ethernet Rtp Receiver Video Stats

    IQEDGE RollCall Control Panel 5.12 Ethernet RTP Receiver Video Stats The Ethernet RTP Receiver Video Stats page displays information on the rate at which video data is being received by each Ethernet port, along with an RTP discontinuity count. Units are megabits per second. Click Enable Stats to display the values.
  • Page 32: Ethernet Rtp Receiver Audio Stats

    IQEDGE RollCall Control Panel 5.13 Ethernet RTP Receiver Audio Stats The Ethernet RTP Receiver Audio Stats page displays information on the rate at which audio data is being received by each Ethernet port, along with an RTP discontinuity count. Units are megabits per second. Click Enable Stats to display the values.
  • Page 33: Ethernet Rtp Receiver Meta Stats

    IQEDGE RollCall Control Panel 5.14 Ethernet RTP Receiver Meta Stats The Ethernet RTP Receiver Meta Stats page displays information on the rate at which metadata is being received by each Ethernet port, along with an RTP discontinuity count. Units are megabits per second. Click Enable Stats to display the values.
  • Page 34: Link Control

    IQEDGE RollCall Control Panel 5.15 Link Control The Link Control page allows quad-link 4K inputs to be synchronized. Figure 19 Link Control Page To have the system synchronize quad-link inputs, enable the check box next to the set of inputs to synchronize. To use 4K SMPTE352 Insertion, enable the adjacent check box.
  • Page 35: Destination Timing

    IQEDGE RollCall Control Panel 5.16 Destination Timing The Destination Timing page allows genlock timing on each spigot to be adjusted, in order to synchronize the IP signal with the house reference. Figure 20 Destination Timing Page Make adjustments as required. Issue 1 Rev 1 Page 35 ©...
  • Page 36: Spigot 1-N

    IQEDGE RollCall Control Panel 5.17 Spigot 1-n A separate page is provided for each spigot. These pages are dynamically configured by the product, based on the capabilities of the software/firmware versions in use. Pages for output and input spigots are slightly different. 5.17.1 Output (Transmit) Spigots Figure 21 Output Spigot Page The following facilities are available from this page:...
  • Page 37: Input (Receive) Spigots

    IQEDGE RollCall Control Panel Option Operation Flow Panes (Primary and Allows multicast IP and port details to be defined for the Secondary) selected spigot. Stats for the spigot can also be enabled from here. To set multicast details: • Enter IP and port details as required. •...
  • Page 38 IQEDGE RollCall Control Panel Option Operation Spigot Pane Displays spigot direction, slot and lane of the associated BNC connector, and the overall module status. The following controls are also available: • Streaming - set redundancy options: • Dual - full redundancy, both Primary and Secondary available.
  • Page 39: Logging - Sdi Info

    IQEDGE RollCall Control Panel 5.18 Logging - SDI Info Information on various parameters can be made available to a logging device connected to the RollCall network. Each logging page comprises three columns: • Log Enable - Select the check boxes that correspond to the parameters for which log information should be collected.
  • Page 40: Logging - Misc

    IQEDGE RollCall Control Panel 5.19 Logging - Misc Information on various parameters can be made available to a logging device connected to the RollCall network. Each logging page comprises three columns: • Log Enable - Select the check boxes that correspond to the parameters for which log information should be collected.
  • Page 41 IQEDGE RollCall Control Panel Log Field Description OS_VERSION= Displays the operating system name and version. BUILD_NUMBER= Displays the build number. HARDWARE_VERSION= Displays the hardware version number. HARDWARE_MOD= Displays the hardware modification number. HARDWARE_BUILD= Displays the hardware build number. FEATUREBOARD_VERSION= Displays the featureboard version number. FEATUREBOARD_MOD= Displays the featureboard modification number.
  • Page 42 IQEDGE RollCall Control Panel Log Field Description REFERENCE_N_STATE= Displays reference state. Valid values are: • WARN:NO LOCK • OK:LOCKED • OK:NTP • OK:<Standard> - standard currently locked to • WARN:Freerun • FAIL:Loss • FAIL:No Sync Messages • FAIL:No Response Message TIMESYNC_N_MODE= Displays current time sync mode.
  • Page 43 IQEDGE RollCall Control Panel Log Field Description LAN_PORT_N_NAME= Displays the Ethernet port name. LAN_PORT_N_SPEED= Displays the Ethernet connection speed. Valid values are: • 10 Mbit/s Full Duplex • 10 Mbit/s Half Duplex • 100 Mbit/s Full Duplex • 100 Mbit/s Half Duplex •...
  • Page 44: Logging - Sfp

    IQEDGE RollCall Control Panel 5.20 Logging - SFP Information on various parameters can be made available to a logging device connected to the RollCall network. Each logging page comprises three columns: • Log Enable - Select the check boxes that correspond to the parameters for which log information should be collected.
  • Page 45 IQEDGE RollCall Control Panel Log Field Description SFP_N_SERIAL_NR= Displays the module serial number, which consists of an S followed by eight digits. SFP_N_REVISION= Displays manufacturer revision number. SFP_N_CONNECTOR= Displays connector type. TEMP_N_NAME= Displays temperature sensor name. TEMP_N_CELSIUS= Displays current temperature sensor reading. TEMP_N_STATE= Displays temperature sensor state.
  • Page 46: Logging - Fpga

    IQEDGE RollCall Control Panel 5.21 Logging - FPGA Information on various parameters can be made available to a logging device connected to the RollCall network. Each logging page comprises three columns: • Log Enable - Select the check boxes that correspond to the parameters for which log information should be collected.
  • Page 47: Logging - Spigot N

    IQEDGE RollCall Control Panel 5.22 Logging - Spigot n The Logging Spigot pages are used to select the fields to be logged for each available spigot. Depending on whether the spigot is an input or an output, the appropriate log fields are shown.
  • Page 48: Logging - Card Diagnostics

    IQEDGE RollCall Control Panel 5.23 Logging - Card Diagnostics Allows logging of various parameters useful when troubleshooting. Use the check boxes to activate logging as required. Figure 28 Logging - Card Diagnostics Page Log Field Description NVRAM_FS= Reports whether the installed file system is QNX6 PowerSafe or FAT32.
  • Page 49: Rolltrack

    IQEDGE RollCall Control Panel 5.24 RollTrack The RollTrack screen allows information to be sent, via the RollCall network, to other compatible units connected on the same network. The Source window lists the RollTrack sources: Figure 29 Source Pane 5.24.1 Disable All When checked, all RollTrack items are disabled.
  • Page 50: Rolltrack Command

    IQEDGE RollCall Control Panel • The fourth set, 99, is a user-definable number that is a unique identifier for the destination unit in a multi-unit system. This ensures that only the correct unit will respond to the command. If left at 00, an incorrectly fitted unit may respond inappropriately.
  • Page 51: Setup

    IQEDGE RollCall Control Panel 5.25 Setup The Setup page displays basic information about the module, such as the serial number and software version. Use the functions on the screen to restart the module or to return all settings to their factory or default settings. Figure 30 Setup The Product area displays technical information on the IQEDGE.
  • Page 52: Defaults

    IQEDGE RollCall Control Panel 5.25.2 Defaults Provides options to reset the module to its defaults. Option Operation Default settings All controls are reset to their default values, except for network configuration and IP addresses. Factory defaults All controls are reset to their default values, including network configuration and IP addresses.
  • Page 53: Ethernet Arcnet

    IQEDGE RollCall Control Panel 5.27 Ethernet Arcnet Not currently used. Figure 32 Ethernet Arcnet Page 5.28 Interop Page The Interop page allows the VC2 compression rate to be set. Select as required. Figure 33 Interop Page Issue 1 Rev 1 Page 53 ©...
