Features
Secondary display
Test frequency
Primary display
Measurement mode
(component type)
For more detailed information, please
refer to the LCR Metre Elite1 User
Manual on LCR Research website
(www.lcrresearch.com).
Second Edition, April 2015
© LCR Research Ltd. 2015
USB charging
interface
Circuit Mode
Battery
Status
Navigation button
(single, double, triple
click and hold)
LCR Meter Elite1
Quick Start Guide
WARNING
To avoid electrical hazards and
possible damage to your LCR metre
or to the equipment under test,
always discharge the capacitor to be
tested before measuring. For in-circuit
measurement, always disconnect
circuit power and discharge all
high-voltage capacitors before testing.
This device complies with the Class A of FCC Part
15, Subpart B and IC ICES-003.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.
Advertisement
Table of Contents
Summary of Contents for LRC Research Elite1
- Page 1 For in-circuit For more detailed information, please measurement, always disconnect refer to the LCR Metre Elite1 User circuit power and discharge all Manual on LCR Research website high-voltage capacitors before testing.
- Page 2 Selecting the Selecting the Series/Parallel Measurement Mode Circuit Mode Single click the “navigation” button to Triple click the “navigation” button select the measurement mode. Four to select the circuit mode for the measurement modes can be selected secondary display. Three circuit as displayed in the ow chart below.
