Vortex SoundStation VTX 1000 Quick Installation Manual

Installation Instructions Cont.
5. Connect your microphone, other input audio sources, and output equipment to your Vortex
device. Refer to the Vortex User Guide for more information.
6. Configure your Vortex system using Conference Composer
to the Vortex User Guide for more information). You will need to select the SoundStation VTX
1000 in Instant Designer. As
you complete the setup
process in Instant Designer,
verify the inputs and outputs
you have chosen match
those that Instant Designer
has selected.
7. Configure your SoundStation VTX 1000 via the unit's
keypad and display, utilizing the Administrative Setup
tools. You will need to enable the Vortex mode. To
access the Vortex mode, press MENU on the
SoundStation VTX 1000. Scroll to ADMIN SETUP and
press SELECT, then scroll to PHONE SYSTEM and press
SELECT, then scroll to VORTEX MODE and press SELECT.
Select VORTEX MODE ON, then press SAVE to save the
configuration.
Note: If your SoundStation VTX 1000 has been assigned a passcode, you will need to enter the passcode after you press
the MENU button. See your SoundStation VTX 1000 user guide for more information.
Please refer to the respective User Guides for each product for warranty and support information.
Copyright© 2004, Polycom Inc. All Rights Reserved. Polycom, the Polycom logo, and Vortex are registered trademarks and SoundStation VTX 1000, Conference Composer and
InstantDesigner are trademarks of Polycom, Inc. in the USA and various countries. All other trademarks are the property of their respective companies. Part #1725-07770-001
rev. C
TM Instant Designer TM software (refer
VORTEX MODE
O
N
OFF ON SAVE
Quick Installation Guide
Vortex ® - SoundStation VTX 1000
Installed Voice System with Wideband Telephone Connection
TM
Connect. Any Way You Want.
