Gehring Group Deluxe Fold Down User Manual

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

Download this manual

1. Safety instructions and notes

1.1 Safety instructions

1.2 Notes

2. Basic structure and name

3. Assembly method and requirements

3.1 Installation of headlight and front fender

3.2 Installation of front wheel

3.3Installation of front brake

3.4Installation of steering handle

3.5 Adjustment of Pedal, Tire, Power Assisting

Operation and adjustment

4.1Introduction of power assistant system

3.6 Charging

4.3Adjustment of quick release parts

4.4Reflection and lightening system

4.5 Safety height mark

4.6 Braking system

4.7 Speed control system

4.8 Damping system

4.9Rear rack

5. Use and maintenance

5.1 Routine inspection before use

5.2 Daily use, inspection and maintenance

6. Riding guidance troubleshooting

User's Manual

Table of Contents

Need help?

Do you have a question about the Deluxe Fold Down and is the answer not in the manual?

Questions and answers

Summary of Contents for Gehring Group Deluxe Fold Down

Page 1 User’s Manual 1. Safety instructions and notes 1.1 Safety instructions 1.2 Notes 2. Basic structure and name 3. Assembly method and requirements 3.1 Installation of headlight and front fender 3.2 Installation of front wheel 3.3Installation of front brake 3.4Installation of steering handle 3.5 Adjustment of Pedal, Tire, Power Assisting Operation and adjustment 4.1Introduction of power assistant system...
Page 2: Safety Instructions And Notes
Electric-power- assistant bicycle, equipped with pedals and an auxiliary electric motor, which cannot be propelled exclusively by means of this auxiliary electric motor, except in the start-up assistance mode, and the start-up assistance speed is less than 6 km/h Compared with bicycle, Electric bicycle only add motor, controller, charger, battery. When riding, electric power will make riding easier and save labor.
Page 3 Please usually check the brakes, tires, handlebar and rim for safety riding. Please regularly check the rims of bike, especially for the rim of the V brake, that avoid the regularly using brakes causing the rim edge thinning and affect the strength of the rim, resulting the tries blowout and result the user’s injury. Please termly check the frame, fork and suspension connection, it may get injury if riders misuse.
Page 4 1. Basic structure and name 1. leather handle 2. LCD display 3. Shimano Shifter 4. Brake lever 5.stem 6. Stem folding clamp 7. LED light 8. PET mudguard 9. suspension front fork 10. Wheel 11. Disc brake 12. Wheel Reflector 13. Saddle 14.
Page 5 Correct Operation Stages ！Warning: For your safety concern, please practice in open tracts for the first time ride. After mastering the tricks, you may ride on regular roads and follow the traffic rules consciously. Do not lend it to people who do not know how to ride the electric bicycle, do not disassemble and refit the electric bicycle, please pay attention that brake in advance to allow longer braking distance in rainy or snowy weather.
Page 6 3.2Installation of front wheel 3.2.1Installation of common front wheel 1. Take out the front wheel, and loose the nut on the front hub; 2. Remove the black plastic rack below the front fork, and place the front wheel hub into the front fork contact pin; 3.
Page 7: Installation Of Brake Cable
Note: The rotor must be installed with the “rotation” arrows pointing in the same direction as the forward rotation of the wheel. 3.3.2Mounting the adapter and caliper 1. Mount the relevant adapter to the caliper body. Insert 5mm bolts through the two adapter slots on the body and screw into the holes on the adapter.
Page 8: Operation And Adjustment
3.5 Adjustment of Pedal, Tire, Power Assisting Hall Sensor 3.5.1. Pedal Installation and Adjustment: Take out pedals from box, put one of pedals (of which the axial end has “L”) on the left side of the cyclist, and put another (of which the axial end has “R”) on the right side of the cyclist.
Page 9 and “MODE” button to switch between different assist levels. Press the To the right of the “ ”button is the battery monitor, all of the 4 leds are active, which indicates that the battery is full. Please recharge the battery whenever the number of active led is less than 2. Press the “...
Page 10 cylinder of battery pack are on, make the opening groove behind the battery pack align with the battery case slider, put the battery pack down into along the battery case slider until the discharge hole at the bottom of battery pack and the discharge plug of battery pack in complete contact, finally press slightly with key into the inside key, at the same time turn the key in a clockwise direction until the key cylinder go through the hole on the battery case slider, then loosen...
Page 11 4.2.2Charging steps and method Charge Methods and Steps 1. When the battery needs charging, please check the nominal voltage and charge plug of battery, choose the original recharger that complies with the nominal voltage and charge plug of battery; It is forbidden to use the non-original recharger to charge the battery to avoid serious safety accidents.
Page 12 3. Then insert the power plug of recharger into a household AC relocatable pad. Please do not insert the plug into the AC in the stagnant water or when there is water on hands as to avoid causing electric shock hazards. 4.
Page 13 when the indicator turns green instead of being red, then the battery is fully charged. A new bike might well be recharged for 8-9 hrs after a deep discharging for the first time. It is to activate the active substances inside the battery. Later, it can be re-charged even if its power is not used up. Common sense of charging and use: The battery should be charged in a spacious environment, staying away from high temperature, high humidity and close fire, because the battery and the charger are electronic products, high temperature and humidity will corrode electronic...
Page 14 4.3.3Folding method of folding bike 1.Push the black clockwise. 2.Push downward the lever and rotate backward the stem.
Page 15 3.Rotate black lever first then the silver one. 4.Rotate the front end of the frame to the left. 4.4Reflection and lighting system The reflection system includes a reflector on the rim, front and rear passive lamp, backpack, helmet and reflective patch on riding clothes.
Page 16: Braking System
Saddle angle: In order to avoid leaning forward when riding, it is appropriate for the front end of the saddle to lean upward, the front and rear position can be appropriately adjusted based on individual height. Minimum height of the saddle: move the quick release handle to the OPEN position, then put the saddle post to the lowest place, and when the saddle post cannot enter into the saddle tube of the frame, it is the minimum height of the seat.
Page 17 The effective stroke of the brake cable is about a half of the distance between the brake lever and the grip; Common sense of the use of braking system When the distance between the brake shoe and the rim is too large, it is adjusted by the brake lever or the clamp. When the brake cable or brake shoes are worn seriously, replace it timely in order to maintain traffic safety.
Page 18 Type of derailleur: dial type (as shown) The derailleur is separately positioned on both sides of the handle, and the left controls the front one, the right controls the rear one. 4.7.2Adjustment of the derailleur The derailleur is classified into the front derailleur and back derailleur When the shift cables are loose or too tight, if the speed controller doesn’t work properly or the chain falls off, the H, L bolt is adjusted.
Page 19: Damping System
4.7.3Chain When the chain and elongate it to a certain extent, it will in the chain will climb to the chain wheel and jump, and at this time the chain has not meshed with the chain wheel correctly, thus affecting the cycling performance; in case of such a situation, the chain should be timely adjusted.
Page 20: Use And Maintenance
4.9 luggage carrier 1. The largest load of the luggage carrier is 25Kg; 2.Do not adjust the luggage carrier arbitrarily, please consult the supplier to make an adjustment if necessary; Don’t to modify the luggage carrier. 3.Do not transport heavy objects; if a heavy object is put on the rear rack, the bike’s steering performance will be affected and the braking performance will be reduced, as will result in danger 4.The assembly of the luggage carrier is (as shown): 5.When you need to use the rear rack, Please check whether the screws are tight.
Page 21: Maintenance
5.2Everyday use and inspection of electric bike In everyday use of the electric bike, a number of mechanical, electrical parts will be worn, screws and other fasteners are also easy to loose and the functions of the electrical appliances would be lost. If the occurrence of these phenomena is not noted, it is prone to failure, and it is also prone to the risk when cycling, so drivers must be responsible for routine inspection and maintenance.
Page 22: Troubleshooting
*Braking skills: as we all know the principle of hard braking is first stopping the rear brake then the front brake. But in case of an emergency, everyone will stop all together. If the braking distance is appropriate, the bike can stop securely; if the slowdown is too fast, people often would be thrown forward and in order to prevent this danger, the best way is intermittent braking, and meanwhile the hip is pushed backward.
