1400W HIGH SPEED
HAND DRYER-SILVER
&WHITE
R1400HSD-01,R1400HSD-15
Please read instructions before commencing installation and retain
for future reference.
Model No.
Supply Voltage:
Power Consumption:
IP Rating:
Safety Classi cation:
Blowing Volume:
Air Velocity:
Noise Level:
Delay time:
Dimensions:
Unit Weight:
Warranty:
Complies with EN 60335-2-23:2003+A1:2008+A11:2010, EN60335-1:2012,
EN62233:2008, EN55014-1:2006+A1:2009+A2:2011,
EN61000-3-2:2006+A1:2009+A2:2009
EN61000-3-3:2008, EN55014-2:1997+A1:2001+A2:2008
Complete with one installation template, one cleaning brush, one lter
bag and 5pcs screws, 5pcs wall plugs (Ø8mm)
! Electrical products can cause death or injury, or damage to property. If in any doubt
about the installation or use of this product, consult a competent electrician.
1. Ensure mains supply is switched off before commencing work.
2. Ensure there is at least 600mm of free space around unit
3. Remove tray and front cover of dryer by removing the screws
4. Remove screws to release mounting plate. Choose correct mounting height as
per Figure 1 and 7. Mark appropriate xing points on wall using template
provided. Before drilling, ensure that the hole does not impinge on pipe work,
cables or other building services
5. Attach mounting plate to wall
6. Using screws attach unit to mounting plate and ensure that it is safe and secure
7. Connect supply cable to a plug or fused wall outlet. Connect supply cable to
terminals: Brown (Live), Blue (Neutral) and Green/Yellow(Earth) to switch supply
8. Attach front cover and tray
Recommended Mounting Heights: From oor to bottom of dryer(see gure7)
Children ages
Men
Ladies
11-17
13"
11"
10"
350mm 300mm
250mm
Figure 1
R1400HSD
220-240V ~ /50Hz
1400W
IP22
Class I, Must be earthed
200m
/h
3
110m/s
84dB
1s to 18s
300mm X 250mm X 680mm
8.5Kg
2 year
Children ages
Disabled
3-10
6"
4"
150mm
100mm
ISO 9001:2008
Q UAL IT Y ASSU RE D CO MPANY
Page 1
