INSTALLATION AND INSTRUCTION MANUAL FOR
eaReefPro 1800S / 1500S / 1200S / 900S / 600SCube Aquariums
For guidance please refer to: hse.gov.uk/toolbox/manual.htm
Never attempt to clean the aquarium with a sharp,
blade-like object as this may damage the silicone bond
It is important to ensure that any water that is spilled
onto the cabinet is wiped off and dried immediately.
Failure to do so will invalidate the warranty
PLEASE READ all of the instruction manual before attempting
Evolution Aqua Ltd. - Evolution House - Kellet Close - Wigan - Lancashire - United Kingdom - WN5 0LP
t +44 (0) 1942 216554 - f +44 (0) 1942 418 489 - e info@evolutionaqua.com - w www.evolutionaqua.com
This product requires Manual Handling.
Know your limitations before lifting!
and invalidate the warranty.
to set-up your new eaReefPro Aquarium
CARE
IMPORTANT
IMPORTANT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the eaReefPro 1800S and is the answer not in the manual?

Questions and answers

Summary of Contents for Evolution Aqua eaReefPro 1800S

  • Page 1 Aquarium Evolution Aqua Ltd. - Evolution House - Kellet Close - Wigan - Lancashire - United Kingdom - WN5 0LP t +44 (0) 1942 216554 - f +44 (0) 1942 418 489 - e info@evolutionaqua.com - w www.evolutionaqua.com...
  • Page 3 WARNING: PLEASE READ THE FOLLOWING SAFETY INFORMATION FIRST. DANGER: To avoid a possible electric shock, ensure all electrical devices are switched off when carrying out maintenance. Take extra care when handling a wet aquarium. Do not attempt repairs yourself; return the appliance to the place of purchase for service or dispose of the appliance.
  • Page 4 INTRODUCTION Congratulations on purchasing an Evolution Aqua aquarium. The eaReefPro aquarium range has been professionally designed for today’s reefkeepers. eaReefPro is suitable for beginners right through to those at the cutting edge of the hobby, and combines practicality with modern looks, durability with premium quality.
  • Page 5: Table Of Contents

    CONTENTS eaReefPro parts list PAGE 6 Specifications and dimensions PAGE 7 How the aquarium works PAGE 12 Installation instructions PAGE 14 Completing the installation and equipment PAGE 18 Setting the weir running height PAGE 19 How to get the best from your eaReefPro aquarium PAGE 21 Troubleshooting PAGE 23...
  • Page 6: Eareefpro Parts List

    EAREEFPRO PARTS LIST Your eaReefPro Aquarium comes complete with the following items: 1) eaReefPro Aquarium 2) Cabinet. 3) Glass sump with base mat fitted. Adjustable with base mat fitted. baffles not factory fitted. * eaReefPro1800 has a separate reservoir tank WEIR SIDE 4) Adjustable baffle plates,...
  • Page 7: Specifications And Dimensions

    SPECIFICATIONS AND DIMENSIONS eaReefPro600SCube VIEW FROM FRONT OF TANK SPECIFICATION eaReefPro600SCube Aquarium dimensions 600mm(L) x 600mm(W) x 600mm(H) Sump dimensions 500mm(L) x 380mm(W) x 400mm(H) Cabinet dimensions 600mm(L) x 600mm(W) x 900mm(H) Total system volume (nett) 198 litres adjustable upwards Display tank volume (nett) 168 litres Sump running volume (nett)
  • Page 8 SPECIFICATIONS AND DIMENSIONS eaReefPro900S VIEW FROM FRONT OF TANK SPECIFICATION eaReefPro900S Aquarium dimensions 900mm(L) x 500mm(W) x 600mm(H) Sump dimensions 800mm(L) x 350mm(W) x 400mm(H) Cabinet dimensions 900mm(L) x 500mm(W) x 830mm(H) Total system volume (nett) 267 litres adjustable upwards Display tank volume (nett) 236 litres Sump running volume (nett)
  • Page 9 SPECIFICATIONS eaReefPro1200S SPECIFICATION eaReefPro1200S Aquarium dimensions 1200mm(L) x 600mm(W) x 600mm(H) Sump dimensions 800mm(L) x 450mm(W) x 450mm(H) Cabinet dimensions 1200mm(L) x 600mm(W) x 900mm(H) Total system volume (nett) 441 litres adjustable upwards Display tank volume (nett) 396 litres Sump running volume (nett) 45 litres adjustable upwards Sump top-up reservoir volume 24.3 litres...
  • Page 10 SPECIFICATIONS eaReefPro1500S SPECIFICATION eaReefPro1500S Aquarium dimensions 1500mm(L) x 600mm(W) x 600mm(H) Sump dimensions 900mm(L) x 450mm(W) x 450mm(H) Cabinet dimensions 1500mm(L) x 600mm(W) x 900mm(H) Total system volume (nett) 536 litres adjustable upwards Display tank volume (nett) 490 litres Sump running volume (nett) 46 litres adjustable upwards Sump top-up reservoir volume 29.17 litres...
  • Page 11 SPECIFICATIONS eaReefPro1800S VIEW FROM FRONT OF TANK SPECIFICATION eaReefPro1800S Aquarium dimensions 1800mm(L) x 600mm(W) x 600mm(H) Sump dimensions 800mm(L) x 450mm(W) x 400mm(H) Cabinet dimensions 1800mm(L) x 600mm(W) x 900mm(H) Total system volume (nett) 588 litres adjustable upwards Display tank volume (nett) 525 litres Sump top-up reservoir volume 49 litres...
  • Page 12: How The Aquarium Works

    Every eaReefPro aquarium comes complete with a built in reservoir chamber for RO/DI water in the sump. Evolution Aqua recommend that all eaReefPro sumps are fitted with a reputable brand of Auto Top Up...
  • Page 13 HOW THE AQUARIUM WORKS WHAT HAPPENS WHEN THE POWER GOES OFF? When power goes off, water flow to the main display tank stops. Main tank water will back syphon down the flare nozzle and narrow inlet tube until the syphon is broken by the flare nozzle drawing in air.
  • Page 14: Installation Instructions

    INSTALLATION First your eaReefPro cabinet must be positioned. PLEASE NOTE: Your finished aquarium should be away from doors and radiators, out of direct sunlight and near to, but not directly over, power sockets. POSITIONING THE CABINET One litre of water weighs one kilogram (1kg) so your furnished aquarium with sump will weigh at least as much in kilograms as its total volume in litres.
  • Page 15 If desired, the grey PVC rigid pipe can be permanently welded together using solvent weld (not supplied). Evolution Aqua solvent weld order code is S79-0-500. DO NOT SOLVENT WELD THE BLACK FITTINGS AS THIS WILL PREVENT REMOVAL OF THE BLACK ACRYLIC GRILL.
  • Page 16 STEP-BY-STEP PIPEWORK INSTALLATION 1. Disconnect nut and one seal from 2. Place component 1, with rubber 3. Place rubber seal ring onto component 2 and firmly push onto seal in place, into hole 1 inside the component 2, sump side. component 1.
  • Page 17 Removable strainer STEP-BY-STEP OUTLET ASSEMBLY INSTALLATION 13. Tighten both components. 14. Ensure elbow on component 5 is 15. Place acrylic weir comb inside. Turn component 5 clockwise inline and facing the hole that is in NOTE: The weir comb should be and component 6 anti-clockwise.
  • Page 18: Completing The Installation And Equipment

    COMPLETING THE INSTALLATION We recommend cleaning the aquarium and sump at this stage and to vacuum out any bits of silicone or debris that may be there. Be careful not to scratch the glass. NEVER ATTEMPT TO CLEAN THE AQUARIUM WITH A SHARP , BLADE-LIKE OBJECT AS THIS MAY DAMAGE THE SILICONE BOND AND SCRATCH THE TANK AND INVALIDATE THE WARRANTY.
  • Page 19: Setting The Weir Running Height

    SETTING THE WEIR RUNNING HEIGHT STEP 1 - Ensure that main tank and sump are filled with water. STEP 2 - Turn red handle on ball valve to fully open. STEP 3 - Turn on sump pump. STEP 4 - Start to close ball valve by turning red handle in small increments. STEP 5 - Water level in back of weir will start to rise and overflow into the emergency overflow pipe (component 3).
  • Page 20 USING THE ADJUSTABLE BAFFLES Most closed reef systems employ the use of a protein skimmer in their sumps. Every protein skimmer manufacturer, and model, recommend a different optimum water height for it to run in, which may cause problems with conventional fixed baffle glass sumps. One way is for the manufacturer or tank builder to take an average sump running height of say 200mm, but with recommendations varying between 150mm and 250mm or more, for some makes and models this average can be far from ideal.
  • Page 21: How To Get The Best From Your Eareefpro Aquarium

    Solids (TDS). Monitor source water regularly to ensure that the above parameters are as close to zero as possible. 2. SALT – Evolution Aqua recommend that a good brand of premium reef quality marine salt is used in order to provide the right balance of water chemistry and trace elements.
  • Page 22 Tip: to take accurate measurements you must first ensure that the salinity is correct. 8. PURE REEF BALANCE – Use Evolution Aqua’s PURE Reef Balance to maintain a biological equilibrium in your reef aquarium. Our bacterial product is a unique combination of live marine- specific bacteria and enzymes.
  • Page 23: Troubleshooting

    TROUBLESHOOTING Noise coming from the weir Check the water level in the weir. It should be level with the top of the emergency standpipe (component 3.) If more than the tiniest trickle is overflowing down the emergency pipe a hollow noise may be caused. This can be prevented by further fine adjustment of the double union ball valve on component 2, and/or further adjustment by way of an electronically controllable sump return pump.
  • Page 24: Warranty

    Evolution Aqua shall not be liable for incidental or consequential damages resulting from the use of this product, or arising out of any breach of this warranty. All express and implied warranties, including the warranties of saleability and fitness for particular purpose, are limited to the applicable warranty period set forth above.
  • Page 25 Customer under this warranty. Signature: Date: Evolution Aqua Ltd. may contact you in the future with product updates or offers, which may be of interest to you. If you do not wish to receive this information please tick this box. ...
  • Page 26 REGISTER YOUR 1 YEAR WARRANTY COVER, COMPLETE THE FORM ON THE REVERSE OF THIS PAGE OR GO TO www.evolutionaqua.com AND COMPLETE ONLINE. WARRANTIES - EVOLUTION AQUA - KELLET CLOSE - WIGAN - LANCASHIRE - WN5 0LP - TEL: 01942 216554...
  • Page 28 QUALITY CONTROL CHECKLIST 1800S (tick) 1500S (tick) 1200S (tick) 900S (tick) 600SCUBE (tick)      CABINET COLOUR write eaReefPro eaReefPro eaReefPro eaReefPro eaReefPro PARTS 600SCUBE 900S 1200S 1500S 1800S PICKED Aquarium and Sump (*Reservoir tank on 1800) Cabinet Inlet and outlet assemblies Bundle...
