Recommended use of a multiple plug adapter for F@sT PLUG 503P
Important :
- Your devices have been already paired during manufacturing and will associate automatically once they are
plugged into the mains : no setup is required.
- The security button cannot be used when the device is in idle mode.
For more information on how to increase security on your network or add additional devices to an existing
powerline network, please consult the User Guide available on the http://support.sagemcom.com website.
All rights reserved. The information and specifications included are subject to change without prior notice. Sagemcom Broadband SAS tries to ensure that
all information in this document is correct, but does not accept liability for error or omission. Non contractual document. All trademarks are registered by
their respective owners. Simplified joint stock company - Capital 35 703 000 Euros - 518 250 360 RCS Nanterre.
Sagemcom Broadband SAS
Headquarters: 250, route de l'Empereur
92848 Rueil-Malmaison Cedex - FRANCE
Tel: +33 (0)1 57 61 10 00 - Fax: +33 (0)1 57 61 10 01
www.sagemcom.com
Device is OFF.
Device is ON.
Device is in «idle mode» when LED flashes
every 15 sec.
No powerline device detected on your network.
At least one powerline device is detected
on your network.
Ethernet port is not connected.
Ethernet port is connected.
Ethernet port
Use the Ethernet port to connect your
equipments using the Ethernet cable provided.
Security button
Press this button between,
- 0-3 sec to join a powerline network
- 7-10 sec to leave the current powerline
network or start a new network
- 12-15 sec to return a device to its original
factory default configuration
