USER MANUAL

DISPLAY FRAME UNIT

subject to modification, errors and omissions excepted * 11-2014 * V1

Table of Contents

Need help?

Do you have a question about the DFU-0133 and is the answer not in the manual?

Questions and answers

Summary of Contents for MedSpace DFU-0133

Page 1 USER MANUAL DISPLAY FRAME UNIT subject to modification, errors and omissions excepted * 11-2014 * V1...
Page 2 we organise your space...
Page 3: Table Of Contents
SUMMARY GENERAL INFORMATION INSTALLATION IN WET ROOMS PRODUCT INFORMATION GETTING STARTED TROUBLESHOOTING TECHNICAL SPECIFICATION WARRANTY TERMS DISPLAY FRAME UNIT we organise your space...
Page 4: General Information
GENERAL INFORMATION - SAFETY CAUTION Only qualified specialist staff may carry out service tasks. Service work is necessary, if the unit has been dam- • aged, e.g. if the mains plug or mains cable have been damaged, if liquid or items are present inside the device, if it has been exposed to water or moisture, if it does not work properly or if it has fallen down.
Page 5 GENERAL INFORMATION - CLEANING Do not clean the screen surface with a coarse item or tissues! These can damage the display surface. A clean, dry cloth is sufficient; never use aggressive cleaners or solvent such as alcohol, thinner or cleaning petrol to clean the Display Frame Unit .
Page 6 In order to have access to the USB port after installation we recommend installing a USB extension cable. CAUTION MedSpace does not offer any guarantee for the screws and dowels delivered with the product. These may need to be replaced on site when considering the weight and quality of the load-bearing wall, since MedSpace is not familiar with the construction environment.
Page 7 Have this product installed by qualified staff only. Use the mounting systems which are specified or recommended by MedSpace. Install the product in a way that it is fixed properly and take care that children are not exposed to danger.
Page 8 Installation of Power Adapters The device may only be operated with the provided power adapter. The rated voltage is indicated on the product label. The device is factory-set to the optimal operating voltage (see Technical Specification). Use only power cords and plugs that are suitable for your local electrical outlets.
Page 9 NOTE The power adapter should be adequately secured to prevent it from becoming unstable and/or falling. Make sure the power source circuits are properly grounded. Use the supplied power cord in order to connect it to the power source. If your installation requires a different power cord, be sure to use an officially approved power cord displaying the mark of the safety agency that defines the regulations for power cords in your country.
Page 10 GENERAL INFORMATION - TRADEMARK HDMI HDMI, HDMI CEC (HDMI Consumer Electronics Control), the HDMI logo and HIGH-DEFINITION MULTIMEDIA INTERFACE are trademarks of HDMI Licensing LLC. ENERGY STAR This product has earned the ENERGY STAR for meeting U.S. Federal energy efficiency guidelines as set by the department of energy and environmental protection agency.
Page 11 GENERAL INFORMATION - DISPOSAL OF OLD EQUIPMENT AND BATTERIES European Union The following symbol indicates that electrical resp. electronic equipment and batteries signed with this symbol should not be disposed of as general household waste at its end of life. Instead, the products should be handed over to the applicable collection points for the recycling of electrical and electronic equipment as well as batteries for proper treat- ment, recovery and recycling in accordance with your national legislation and the Directive 2002/96/EC and 2006/66/ NOTICE: An appendix "Pb"...
Page 12: Installation In Wet Rooms
DIN VDE 0100 T.701. According to this standard, MedSpace monitor systems with DC 12V (Limited Power Source Class II, SELV) can be installed at each position (incl. Zones “0” and “1”) in harsh environments, also in showers and above a bath tub as long as the monitor system is shielded from a sealed glass surface and the (external) power adapter is installed beyond these protection zones.
Page 13: Product Information
WATERPROOF, for DFU-0133 up to DFU-0216 SLIMLINE, for DFU-0260 up to DFU-0840 Low voltage power adapter............. • DC 12V, 66W for DFU-0133 up to DFU-0216 DC 24V, 200W for DFU-0260 up to DFU-0460 DC 24V, 600W for DFU-0550 up to DFU-0840 Power cord........................•...
Page 14 COMPONENT SPEAKER OUT IR OUTPUT POWER (CABLE) 1A Power input DC 12V for DFU-0133 up to DFU-0216 Power input DC 24V for DFU-0260 up to DFU-0840 2 USB input, 1 x USB terminal input, 3 x HDMI terminal 3 HDMI...
Page 15: Getting Started
GETTING STARTED - HOW TO CONNECT External video and audio sources The DFU features one Component (5) and three HDMI (3) inputs. We recommend using the HDMI inputs for best video and sound quality. Connect an HDMI cable to the HDMI output terminal of your STB, VCR, DVD player, BluRay player or the like and one of the three HDMI (3) inputs of the DFU.
Page 16 Open / close OSD menu of DFU Dimmer scene 1 recall Switch between TV and radio Favorite list Sleeptimer Aspect ratio Select audio mode / audio track functions used for MedSpace lighting solutions functions used for MedSpace Set Top Box solutions we organise your space...
Page 17 6. To exit “learn mode” please press and release the key again. The LED indicator is off. In order to reset all keys to MedSpace “factory default” IR commands, please follow the next steps: 1. Press and hold the keys simultaneously until the LED indicator lights constantly.
Page 18 Open / close OSD menu of DFU Sleeptimer Aspect ratio Select audio mode and audio track Dimmer on / off Dimmer scene 1 recall functions used for MedSpace lighting solutions functions used for MedSpace Set Top Box solutions we organise your space...
Page 19 GETTING STARTED - INPUT SOURCE Input Source Within the input source list you can select the available input sources. Press the key on your remote control to open the Input Source list. HDMI 1 HDMI 2 Press the keys until the desired input •...
Page 20 GETTING STARTED - OSD MENU In the on screen display menu (OSD) you can adapt the OSD Settings Image Settings characteristics of the monitor system based on personal OSD Language English Picture Mode Standard preferences. Brightness OSD Time Out 180 s OSD Transparency Contrast Saturation...
Page 21 Image Settings Press the key to open the OSD menu. Navigate to Image Image Settings Settings with the keys. Picture Mode Standard Picture Mode: define the picture mode, choose from • Brightness Standard, Dynamic, Mild, User. In user mode the Contrast settings for Brightness, Contrast, Saturation and Saturation...
Page 22 Audio Settings Press the key to open the OSD menu. Navigate to Audio Settings Audio Settings with the keys. Sound Mode Standard Sound Mode: define the sound mode according • Bass to your preferences, choose from Standard, Music, Treble Movie, Sports, User. In user mode the settings for Balance Bass and Treble may be adjusted manually.
Page 23 Setup Settings Press the key to open the OSD menu. Navigate to Setup Settings Setup Settings with the keys. DFU Model „Model Number“ Save Current Settings: save your current device • Firmware Version „Version Number“ settings. Load Settings: load previously saved device set- •...
Page 24 Volume Limit NOTE Next Page If the OSD menu is deactivated, users are not able to access the OSD menu without password. Start Logo: (de)activate the MedSpace start-up logo • while booting. IR Address Code: determine an individual address •...
Page 25 Input HDMI 1: (de)activate the HDMI 1 input port. • Input HDMI 2: (de)activate the HDMI 2 input port. • Service Settings Input HDMI 3: (de)activate the HDMI 3 input port. • Input HDMI 1 Input Component: (de)activate the Component •...
Page 26: Troubleshooting
TROUBLESHOOTING If the product is not working properly, please check the following troubleshooting hints before you contact customer service: Symptoms Possible Solution Check the status LED. If the status LED is red, the DFU is in standby and the monitor is black, this is normal.
Page 27: Technical Specification
TECHNICAL SPECIFICATION - DFU DIMENSIONS IR eye Status LED DFU Size 354.0mm 239.0mm 30.5mm 30.5mm 28.5mm 293.0mm 165.0mm 177.0mm 301.5mm 227.0mm 7.0mm 30.0mm 80.0mm 159.0mm 12.0mm 13.3" 13.94" 9.41" 1.20" 1.20" 1.12" 11.54" 6.50" 6.97" 11.87" 8.94" 0.28" 1.18" 8.94" 6.26"...
Page 28 TECHNICAL SPECIFICATION - DFU FEATURES Features DFU-0133 DFU-0185 TFT, Thin Film Transistor / LED Display Type / Backlight 293 x 165mm / 11.54“ x 6.50“ 409 x 230mm / 16.10“ x 9.06“ Active Screen Area 337mm / 13.3“ 470mm / 18.5“...
Page 29 DFU-0216 DFU-0260 DFU-0320 TFT, Thin Film Transistor / LED 476 x 268mm / 18.74“ x 10.55“ 576 x 324mm / 22.68“ x 12.76“ 698 x 393mm / 27.48“ x 15.47“ 546mm / 21.5“ 660mm / 26.0“ 800mm / 31.5“ 16:9 1920 x 1080 1366 x 768 1920 x 1080...
Page 30 TECHNICAL SPECIFICATION - DFU FEATURES Features DFU-0420 DFU-0460 TFT, Thin Film Transistor / LED Display Type / Backlight 930 x 523mm / 36.61“ x 20.59“ 1018 x 572mm / 40.08" x 22.52" Active Screen Area 1067mm / 42.0“ 1168mm / 46.0" Diagonal 16:9 Picture Format...
Page 31 DFU-0550 DFU-0650 DFU-0840 TFT, Thin Film Transistor / LED 1209 x 680mm / 47.60“ x 26.77“ 1428 x 803mm / 56.22“ x 31.61“ 1.860 x 1.046mm / 73.23“ x 41.18“ 1387mm / 54.6“ 1639mm / 64.53“ 2134mm / 84.0“ 16:9 1920 x 1080 Horizontal: Horizontal:...
Page 32 TECHNICAL SPECIFICATION - DFU PORTS Ports DFU-0133 up to DFU-0840 Line Audio Input 1 x RCA terminal, white, red Component Input 3 x RCA terminal, green, blue, red HDMI Input 3 x HDMI terminal Input Ports 1 x USB terminal...
Page 33 TECHNICAL SPECIFICATION - DFU SPECIAL FEATURES Special Features DFU-0133 up to DFU-0840 Multimedia Player Software Update CI (Common Interface) Autostart Signal Scan Hotel Mode RS-232 FM Radio Teletext Weak Signal Enhancement Noise Reduction DISPLAY FRAME UNIT we organise your space...
Page 34 TECHNICAL SPECIFICATION - USB MEDIA SUPPORT USB Media Support File Extension Video Audio .avi DivX, XviD, MPEG-4 .mpg MPEG-1, MPEG-2 MP3, WMA, AAC Movie .dat MPEG-1 .mov / .mkv H.264 .mp3 .wma Music .m4a /.aac Progressive JPEG .jpg / .jpeg Baseline JPEG .bmp Photo...
Page 35 ET_428 600W / 25A 100~240V AC 24V DC 0° - 40°C / 32° - 104°F 20 - 90% 3530g ET_426: DFU-0133 up to DFU-0216 ET_547: DFU-0260 up to DFU-0460 TRG70A120 66W Switching Adapter ET_428: DFU-0550 up to DFU-0840 Tel: 886-4-7690261 Fax: 886-4-7699292.7698031...
Page 36: Warranty Terms
Certificate regarding the year, month and date of purchase, the changed, destroyed or defaced serial numbers or in case of be repaired, or at MedSpace´s option replaced free of charge. To customer’s name, the dealer’s name, and the serial number.
Page 37 This worldwide Warranty Certificate and proof of purchase must be presented at an authorized MedSpace repair service or dealer station before any repair can be made under the conditions of warranty. In addition to the one year Worldwide Warranty issued by MedSpace, Ger- many, the European Warranty is valid for two years from the date of purchase.
Page 39 RETURN MATERIAL AUTHORISATION In case of a defect, please fill out the form and enclose to the package. RMA No. Company Name Contact Address Place, Date Postcode, City Country Phone Signature E-Mail How to proceed: Prior to sending any goods, please make sure to request an RMA-Nr. from us by phone or email. Please complete the RMA form, in particular giving as detailed a description as possible of the fault encountered.
Page 41 RETURN TO FACORY In case of a defect, please contact the MedSpace service department in order to receive a RMA number. Returns without indicated valid RMA number cannot be processed and will be refused. MedSpace Service and Support Phone: +49 7462 923 90-900...
Page 44 HDMI, the HDMI logo and high-definition multimedia interface are trademarks of HDMI Licensing LLC. This product, parts, components and the assembly are protected by or might be part of one or more of the following intellectual property rights: US 7455412 B2 - US 7589893 B2 E-Mail: info@med-space.de EP 1168285 B2 - EP 1429308 B2 - EP 1809828 B1...
