Barcus-Berry C5200 Installation Manual

Specifications for the 3000 Piezo Buffer Preamp with EQ

Input (EQ Flat)
Input Interface = RCA unbalanced
Input Impedance = 2.2 Meg Ohms
Maximum Input Level = 2.0 vrms
Output (EQ Flat, Volume Max)
Output Interface = 1/4" unbalanced
Output Impedance = 2K Ohms
THD = .008% @ 1kHz
Noise = -92dBu
S/N = 100dBu
Bass = +/- 12dB @ 50Hz
Treble = +/- 12dB @ 10kHz
Frequency Response = 5Hz - 30kHz (+/- 1dB)
Power Supply
Power Source = 9 Volts @ 380 Microamps
Battery Life = Approximately 1,000 hours
N. Charleston, SC 29419-3366
www.barcusberry.com
Made In The U.S.A.
This Barcus-Berry product is designed to satisfy
the most rigorous demands of the profession-
almusician and the precision manufacturing
techniques employed provide assurance of
long-continued, trouble-free service. For
outstanding performance and dependability, you
can always rely upon BARCUS-BERRY— the
world's leading name in musical instrument
transducers, pickups and microphones.

Limited Warranty

This Barcus-Berry product is warranted for a period
of one (1) year from the date of purchase against
defects in workmanship and parts.
P.O. Box 63366
Woodwind & Brass System
Installation InstructIons
W o o d W I n d & B r a s s t r a n s d u c E r s Y s t E M
6525
for
model no.
C5200
ö õ
