User Manual IQSDA41 Single/Dual-Channel 12G/3G/HD/SD-SDI Re-clocking Distribution Amplifier with RollCall IQSDA42 Multi-Channel 12G/3G/HD/SD-SDI Re-clocking Distribution Amplifier with RollCall www.s-a-m.com... -
Page 2: Information And Notices
IQSDA41/42 Information and Notices Information and Notices Copyright and Disclaimer Copyright protection claimed includes all forms and matters of copyrightable material and information now allowed by statutory or judicial law or hereinafter granted, including without limitation, material generated from the software programs which are displayed on the screen such as icons, screen display looks etc. -
Page 3: Safety Information
IQSDA41/42 Safety Information Safety Information Erklärung der Sicherheitssymbole Dieses Symbol weist den Benutzer auf wichtige Informationen hin, die in der begleitenden Dokumentation enthalten sind. Dieses Symbol zeigt an, dass gefährliche Spannung vorhanden ist. Es befinden sich keine vom Benutzer zu wartenden Teile im Geräteinneren. Dieses Gerät sollte nur von geschultem Personal gewartet werden Sicherheits-Warnhinweise Die angeführten Service-/Reparatur-Anweisungen sind... - Page 4 IQSDA41/42 Safety Information Simboli di sicurezza: Forklaring på sikkerhedssymboler Questo simbolo indica l'informazione importante contenuta nei Dette symbol gør brugeren opmærksom på vigtig information manuali appartenenti all'apparecchiatura. Consultare il manuale. i den medfølgende manual. Questo simbolo indica che all'interno dell'apparato sono presenti Dette symbol indikerer farlig spænding inden i apparatet.
-
Page 5: Laser Safety
IQSDA41/42 Safety Information Símbolos de Segurança O símbolo triangular adverte para a necessidade de consultar o manual antes de utilizar o equipamento ou efectuar qualquer ajuste. Este símbolo indica a presença de voltagens perigosas no interior do equipamento. As peças ou partes existentes no interior do equipamento não necessitam de intervenção, manutenção ou manuseamento por parte do utilizador. - Page 6 IQSDA41/42 Safety Information EMC Standards This equipment conforms to the following standards: EN 55032:2012 (Class A) Electromagnetic Compatibility of Multimedia Equipment - Emission Requirements. EN 61000-3-2:2014 (Class A) Limits for Harmonic Current Emissions. EN 61000-3-3:2013 Limitation of Voltage Changes, Voltage Fluctuations and Flicker in Public Low-Voltage Supply Systems.
-
Page 7: Table Of Contents
1.1.2 IQSDA42 ........ -
Page 8: Introduction
IQSDA41/42 Introduction Introduction 1.1 Description 1.1.1 IQSDA41 The IQSDA41 is a single- or dual- channel SDI distribution amplifier for UHD-1 12 Gbit/s, HD 3 Gbit/s, 1.5 Gbit/s or SD 270 Mbit/s signals, providing up to 9 equalized and reclocked outputs in a single-width package. Its 60m 12G, 80m 3G, 180m HD input equalization performance and non-reclocking distribution of wide-band signals make it ideal for all distribution applications. -
Page 9: Iqsda42
Introduction 1.1.2 IQSDA42 The IQSDA42 is a configurable single, dual or quad-channel SDI distribution amplifier for UHD-1 12 Gbit/s, HD 3 Gbit/s, 1.5 Gbit/s or SD 270 Mbit/s signals, providing up to 19 equalized and re-clocked outputs of the input in a single width-package. Its 60m 12G, 80m 3G, 180m HD input equalization performance coupled with excellent packing density make it ideal for signal-dense distribution applications. -
Page 10: Order Codes
IQSDA41/42 Introduction • Standards supported: • 12G UHD-1 to SMPTE 2082 • 3G-HD to SMPTE424M • HD-SDI to SMPTE292M • SD-SDI to SMPTE259M-C • DVB-ASI • RollCall monitoring allows all signal paths to be managed. 1.2 Order Codes The following module order codes are covered by this manual: IQSDA4100-1B4 12G/3G/HD/SD-SDI Re-clocking Distribution Amplifier. -
Page 11: Enclosures
IQSDA41/42 Introduction The following SFP modules are available for the IQSDA range: FC1-13TR-12G Fiber transceiver, 1 x 12G Rx, 1 x 12G Tx (1310nm). FC1-13T2-12G Fiber transceiver 2 x 12G Tx (1310nm). FC1-13R2-12G Fiber transceiver 2 x 12G Rx. 1.3 Enclosures The IQSDA4x modules can be fitted into the enclosure types below. -
Page 12: Technical Specification
Inputs and Outputs Signal Inputs SDI Inputs 1 or 2 (configurable) x 12G/3G/HD/SD-SD (IQSDA41) 1, 2 or 4 (configurable) x 12G/3G/HD/SD-SD (IQSDA42) Connector/Format HD-BNC/75 Ohm panel jack on standard SAM connector panel Input Cable Length Up to 60 m Belden 1694A @ 12 Gbit/s Up to 80 m Belden 1694A @ 3 Gbit/s Up to 180 m Belden 1694A @ 1.5 Gbit/s... - Page 13 Output Jitter SD-SDI 0.2 UI (10 Hz) / 0.2 UI (1 kHz) 3G/HD-SDI 1.0 UI (10 Hz) / 0.2 UI (100 kHz) Power Consumption Module Power 5PR IQSDA41 Consumption 8PR IQSDA42 Issue 1 Rev 1 Page 13 © 2017 SAM...
-
Page 14: Connections
IQSDA41/42 Connections Connections This section describes the physical input and output connections provided by the IQSDA41/42. 3.1 SDI Input/Output Serial digital inputs and outputs are via HD-BNC connectors which terminate in 75 Ohms. The number of connectors varies according to the actual module variant in use. -
Page 15: Rear Panel Leds
IQSDA41/42 Rear Panel LEDs Rear Panel LEDs The LEDs on the rear panel of the module indicate input status. There is one LED per input. • When Green: Input enabled, signal valid. • When Yellow: Input disabled or Reclocker Bypass active. •... -
Page 16: Operation Using The Rollcall Control Panel
IQSDA41/42 Operation Using the RollCall Control Panel Operation Using the RollCall Control Panel This section contains information on using IQSDA41/42 modules with RollCall. For help with general use of the RollCall application, open the user manual by clicking on the main RollCall toolbar. The IQSDA4x will dynamically configure itself depending on rear and SFP options. -
Page 17: Information Window
IQSDA41/42 Operation Using the RollCall Control Panel 5.2 Information Window The Information window is displayed at the top of each page, next to the pages list. It can displays basic information about the input and output status of the module; select a radio button as required. -
Page 18: Input Output Page
IQSDA41/42 Operation Using the RollCall Control Panel 5.3 Input Output Page The Input Output page enables inputs and outputs to be configured, and determines how the module behaves in the event of an input error. 5.3.1 Configuration Use the radio buttons to select the input/output configuration. The options available are dependant on the particular module hardware configuration in use;... -
Page 19: Setup
IQSDA41/42 Operation Using the RollCall Control Panel 5.4 Setup The Setup page displays basic information about the module, such as the serial number and software versions. Use the functions on the page to restart the module or return all settings to their factory or default settings. -
Page 20: Input Name
IQSDA41/42 Operation Using the RollCall Control Panel 5.4.4 Input Name These are the input names displayed in logs. To change the name of Input 1 or Input 2, type the name in the text field and click S. To return the name to its factory default, click P. -
Page 21: Logging - Misc
IQSDA41/42 Operation Using the RollCall Control Panel 5.5 Logging - Misc The Logging - Misc page displays current log information regarding the unit’s basic parameters. The following options are available. Enable check boxes to activate logging. Log Field Description Reports the module serial number, which consists of an S followed by eight digits. -
Page 22: Logging - Input
IQSDA41/42 Operation Using the RollCall Control Panel 5.6 Logging - Input The Logging - Input page displays current input logging information. The following options are available. Enable check boxes to activate log fields as required. Log Field Description INPUT_N_STATE= Reports current state of the input signal. Valid values are: •... -
Page 23: Logging - Output 1-N
IQSDA41/42 Operation Using the RollCall Control Panel 5.7 Logging - Output 1-n The Logging - Output 1-n pages display current logging information for each output. The following options are available. Enable check boxes to activate log fields as required. Log Field Description OUTPUT_N_STATE= Valid values are:... -
Page 24: Rolltrack
IQSDA41/42 Operation Using the RollCall Control Panel 5.8 RollTrack The RollTrack page allows information to be sent, via the RollCall network, to other compatible units connected on the same network. 5.8.1 Disable All When checked, all RollTrack items are disabled. 5.8.2 Index This slider enables up to 16 RollTrack outputs to be set up. -
Page 25: Address
IQSDA41/42 Operation Using the RollCall Control Panel RollTrack Source Description TX N Bias High LASER Bias currently above limits. TX N Bias Low LASER Bias currently below limits. RX N Power OK Receive power is within limits. RX N Power High Receive power is above limits. - Page 26 IQSDA41/42 Operation Using the RollCall Control Panel RollTrack Source Description RollTrack message was sent and received successfully. Unknown RollTrack message has been sent but transmission has not yet completed. Timeout RollTrack message has been sent but no acknowledgement received. This could be because the destination unit is not at the location specified.
-
Page 27: Memory 1-16
IQSDA41/42 Operation Using the RollCall Control Panel 5.9 Memory 1-16 The Memory 1-16 page enables up to 16 configurations to be saved and recalled later. Default memory names can be changed to provide more meaningful descriptions. 5.9.1 Recall Memory This column lists the settings that have been previously saved. If no settings have been saved, None Selected is displayed. -
Page 28: Last Recalled Memory
IQSDA41/42 Operation Using the RollCall Control Panel 5.9.3 Last Recalled Memory The Last Recalled Memory pane displays the most recently recalled memory. If any of the settings have been changed since it was recalled, an asterisk will be displayed after the memory name.
