Canoga Perkins 9161 User Manual

Network interface device
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
9161
Network Interface Device
User Manual
the

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 9161 and is the answer not in the manual?

Questions and answers

Summary of Contents for Canoga Perkins 9161

  • Page 1 9161 Network Interface Device User Manual...
  • Page 3 Perkins and any unauthorized use or disclosure of such drawings, specifications and information is prohibited. Canoga Perkins reserves the right to change or update the contents of this manual and to change the specifications of its products at any time without prior notification. Every effort has been made to keep the information in this document current and accurate as of the date of publication or revision.
  • Page 5 CAUTION! This product may contain a laser diode operating at a wavelength of 1300 nm - 1600 nm. Use of optical instruments (e.g., collimating optics) with this product may increase eye hazard. Use of controls or adjustments, or performing procedures other than those specified herein may result in hazardous radiation exposure.

  • Page 7: Table Of Contents

    Set Up the PC for Terminal Operation ..................3-2 Management User Interface ........................3-2 General Screen Format.........................3-2 User Interface Organization ......................3-3 Login and the 9161 Main Menu....................3-9 Managing the 9161 ..........................3-10 Configure the 9161 for the System....................3-10 View Device Information ......................3-11 Manage the Date and Time......................3-11 Manage SNMP and Host Access....................3-12...
  • Page 8 Appendix A Warranty Information..............A-1 Appendix B Acronym and Abbreviation List ............B-1 List of Figures Figure 1. The 9161 Front Panel ......................1-1 Figure 2. Remote Fault Signal ......................2-4 Figure 3. Link Loss Forwarding Propagation ..................2-4 Figure 4. General Screen Format ......................3-3 Figure 5.

  • Page 9: Chapter 1 Overview

    In addition, the 9161 offers Layer 2 statistics, remote software upgrade, remote control and monitoring, and management through CanogaView. The 9161 supports two ports that receive and transmit 10 Gigabit Ethernet data over single mode fiber (SMF) or multimode fiber (MMF) at 1310 or 1550 nm wavelength.

  • Page 11: Chapter 2 Hardware Installation And Functions

    9161, then secure the screws. • To use the 9161 as a standalone unit, place it on a secure, flat surface within reach of the power and fiber optic connections 3.

  • Page 12: Power-Up, Hardware Functions, And Leds

    Cabling for the 9161 includes the serial cable to the Terminal port, the Ethernet cable for a UTP port, and the fiber optic link to the Tx and Rx ports. 5. Plug the serial cable into the SLIP or Terminal port on the rear panel and your PC. For the pinouts, see Chapter 5, Specifications.

  • Page 13: Alarms

    System self-test Receiving Remote Fault Non-network connection Green Network connection Amber System self-test Alarms The 9161 can generate Traps and Major and Minor Alarms. For details about the Traps Log and setting up notification, see Chapter 4. 9161 Network Interface Device...

  • Page 14: Remote Fault

    Figure 2. Remote Fault Signal Link Loss Forwarding When LLF is enabled, a fault on one side of the 9161 propagates to the other side to notify that device and stops signal transmission (brings down the link). See Figure Error! Reference source not found..

  • Page 15: Chapter 3 Using The Software

    HyperTerminal or similar terminal emulation software, a standard SNMP network manager, and CanogaView. Setting Up for Network Management Typically, the 9161 runs within the network on an Ethernet connection, communicating with your Network Management Platform. Set Up the Network Management Platform You must run several Management Information Bases (MIBs) on your Network Management Platform in order to successfully manage this module.

  • Page 16: Set Up The Pc For Terminal Operation

    The Management User Interface for the 9161 provides screens for setup, monitoring, and diagnostics. You can access the screens directly by connecting to the serial port of the 9161 These sections discuss the screens for the 9161, using a Telnet session for access.

  • Page 17: User Interface Organization

    1.1 System Information (3-13) 1.1.1- System Name 1.1.2- Contact 1.1.3- Location 1.1.4- Customer 1.1.5- Information 1 1.1.6- Information 2 1.1.7- Circuit Info 1 1.1.8- Circuit Info 2 1.1.9- Service Code 1.1.10- Date-in-Service 1.1.11- Date-out of-Service 1.1.12- Equipment Type 9161 Network Interface Device...
  • Page 18 Password Configuration 1.6.1- Minimum Length 1.6.2- Minimum Alpha Characters 1.6.3- Minimum Numeric Characters 1.6.4- Minimum Punctuation Characters 1.6.5- Maximum Consecutive Character Types 1.6.6- Maximum Consecutive Same Characters 1.6.7- Allow username in password 1.6.8- Password Expiration Time 9161 Network Interface Device...
  • Page 19 1.6.9- Password Reuse Count Lockout/Logout Configuration 1.6.10- Lockout After Failed Attepts 1.6.11- Lockout Type 1.6.12- Lockout Time 1.6.13- Display Lockout Message 1.6.14- Lockout Message 1.6.15- Lockout Console Port 1.6.16- Inactivity Lockout Time 9161 Network Interface Device...
  • Page 20 2 Switch Configuration 2.1 Global Spanning Tree Parameters 2.1.1- Admin Mode 2.1.2- Version 2.1.3- Configuration Name 2.1.4- Configuration Revision 2.1.5- Priority 2.1.6- Hello Time 2.1.7- Forward Delay 2.1.8- Max Age 2.1.9- BPDU Forwarding Mode 2.1.10- View/Change Interface 9161 Network Interface Device...
  • Page 21 3.2 Port Statistics 3.3 Clear Counters on All Ports 4 Reports 4.1 Device Description 4.2 System Log 4.2.1- View First Page 4.2.2- View Last Page 4.2.3- View Previous Page 4.2.4- View Next Page 4.2.5- Clear The Log 9161 Network Interface Device...
  • Page 22 5.1.7- Start/Stop Test 5.2 PING 5.2.1- Ping Address 5.2.2- Ping Count 5.2.3- Ping Size 5.2.4- Start Pinging 6 Utilities 6.1 Set Date & Time 6.2 Restore Defaults 6.3 Restart System 6.4 Swap Bank & Restart 7 Logout 9161 Network Interface Device...

  • Page 23: Login And The 9161 Main Menu

    <Enter> at the prompts for the username and password. Otherwise, type your username and press <Enter>, then type your password and press <Enter>. The Main Menu appears after you log in and provides access to all functions for the 9161: setup, diagnostics, and reports. See Table Error! Reference source not found..

  • Page 24: Managing The 9161

    Managing the 9161 You can manage the hardware and software for the 9161, including communication access. Configure the 9161 for the System The System Information screen provides various categories of optional information that system administrators may track. To access the System Information screen, and follow these steps: 1.

  • Page 25: View Device Information

    Manage the Date and Time An accurate date and time in the 9161 assures accuracy for events listed in the System Log and for traps and alarms sent to the system administrator. You can choose either of two methods for setting the date and time, depending on your access to an external network and your need for accuracy.

  • Page 26: Manage Snmp And Host Access

    SNTP Server IP Address: Enter the address for the server; 0.0.0.0 indicates no server • Time Resync Interval in hours: Set how often, in hours, that the 9161 tries to synchronize its time to the Sntp server; Range is 0 (attempt to synchronize at bootup, only) to 24 (once daily) •...

  • Page 27: Manage Traps And Alarms

    9161 Traps Log, but do not trigger alarms. Use the Trap Configuration screen to view the current configuration and to enable or disable traps for the 9161. For a list of events that trigger traps, see Table Error! Reference source not found.. To set up the traps, follow these steps: 1.

  • Page 28: View System Events And Traps

    Use the Management Packet Control screen to enable or disable transmission of management packets through any specific port on the 9161. If you disable a port, that limits that port to only network traffic, the port cannot receive or send any packets that would manage the 9161. To access the Management Packets Filter screen, follow these steps: 1.

  • Page 29: Managing Security

    " appears, you can log on in a regular VT100 session, access the Transfer complete Utilities menu, and type 4, Swap Banks" to reset the 9161 and start using the new software. Managing Security To effectively provide system security for a variety of network applications, the 9161 works with SNMPv3.

  • Page 30: Set Up User Accounts

    You can set up an account for a user, whether another supervisor, operator, or observer, to access the 9161. You can also update or delete usernames or permissions. Settings for certain values for some parameters, such as SNMPv3 Authentication and Privacy Protocols, can determine or limit which values you can set for other parameters.

  • Page 31: Change Your Password

    , and press <Enter>, then select your account User name. 5. On the Edit User Account screen, type , "UI Password," and enter your new password, 8 to 15 characters, and press <Enter>. 6. To return to the Main Menu, press <Esc>. 9161 Network Interface Device 3-17...

  • Page 32: Manage Logged In Users

    Manage Logged In Users At times, you may need to monitor which users are currently logged in to the 9161 and, if needed, you can force a specific session off (requires supervisor access). The User Log shows information about the current users by session number; an asterisk (*) next to the session number indicates your session.

  • Page 33: Set Up The Notification Destination For Traps

    Authentication Protocol; this is generated automatically for the Authentication Password, but can be changed if the destination uses a different Authentication Key generation algorithm; 16 Hex characters for MD5 protocol or 20 Hex characters for SHA protocol. 9161 Network Interface Device 3-19...

  • Page 34: Managing The Network Interface

    When STP is enabled, the 9161 monitors the incoming data packets and periodically sends Bridge Protocol Data Units (BPDU). STP monitors the incoming BPDUs to detect any loops. If the same BPDU arrives on two ports, STP blocks one port to remove the loop.

  • Page 35: Figure 7. Typical Spanning Tree Application

    ID tag as it exits a port. The customer's tag for a VLAN is assigned through the VLAN; the double (service provider's) tag is derived from the PVID and assigned before the packet exits the 9161. See Figure Error! Reference source not found. and follow these guidelines: •...

  • Page 36: Check And Update Port Information

    Check and Update Port Information The Port Information screen shows the current conditions for all ports in the 9161 with options to view parameters and statistics for specific ports. Configuration information includes the model number, description, and revision, the serial number, and link, remote fault, and physical status. To access the Port Information screen, follow these steps: 1.

  • Page 37: Set Up Vlans

    If two or more bridges share the same priority, the lowest MAC address defines the highest priority. • Hello Time (sec): Set how often the 9161 sends BPDUs if this 9161 is the Spanning Tree root. •...

  • Page 38: Set Up Optional Double Tagging

    • Double Tagging Enable/Disable: Enable, add service provider ID tags to packets as they exit the 9161; or Disable, strip service provider ID tags from packets before they exit the 9161 • Accept Frame: Accept frames for this VLAN Only or Accept All frames •...

  • Page 39: Set Up Multiple Spanning Tree Parameters

    Use the Global Spanning Tree Report screen to view Global STP parameters and interface statistics and status for the 9161. To access the Global Spanning Tree Report screen, follow these steps: 1. From the Switch Configuration menu, type 3, "Global Spanning Tree Report," and press <Enter>.

  • Page 40: Check The Static And Dynamic Arp Tables

    The Static ARP table lets you set or change specific IP and MAC addresses for up to 10 ports. The Dynamic ARP table lists currently-assigned IP and MAC addresses for various 9161 ports. To view, set, or remove a static ARP address, follow these steps: 1.
  • Page 41 9161 Network Interface Device 3-27/(3-22 Blank)

  • Page 43: Chapter 4 Maintenance And Troubleshooting

    Measure Transmitter Output Power To measure the output power, follow these steps: 1. Clean the connectors on the fiber optic test cable, then plug it in to the Tx connector on the 9161. 2. Warm up each component for at least 30 minutes.

  • Page 44: Measure Receiver Input Power

    Measure optical fiber links at the shortest wavelength of operation to determine the limiting factor in the loss budget. Each device that transmits to an 9161 has a loss budget that is specified by the manufacturer and recorded on a data sheet provided with the equipment. That loss budget must be greater than the total of the measured loss of the fiber link and the attenuation of the 9161s.

  • Page 45: Troubleshooting

    The fiber optic cable is within the specifications and loss budget of the optic interface module. • The line length between the 9161 and the remote link does not exceed the allowable loss budget or overdrive limit. • All host modules in the link are turned on.

  • Page 46: Problems With Fiber Optics

    Test Latency and Jitter If a fault occurs on a connection, use the Latency/Jitter Test to set up test conditions and view test results for troubleshooting the 9161. To test latency and jitter, follow these steps: 1. From the Diagnostics menu, type , "Latency/Jitter Test,"...

  • Page 47: Chapter 5 Specifications

    Chapter 5 Specifications 9161 Specifications Standards: IEEE 802.3 Dimensions: 1.72" H x 13.375" W x 17.25" D (44 x 340 x 438 mm) Weight: 0.3 lb. (0.136 Kg) Operating Temperature: 0° to 50° C Operating Humidity: Up to 90% (non-condensing)

  • Page 48: 9161 Xfp Module Model Numbers

    9161 XFP Module Model Numbers 10GigE XFP Modules XFP1-0265 10 GBase-SR 850nm MM 300m LC XFP1-2265 10 GBase-LR 1310nm SM 10km LC XFP1-3465 10 GBase-ER 1550nm SM 40km LC XFP1-3665 10 GBase-ER 1550nm SM 80km LC 9160 10 Gigabit Ethernet Network Interface Device...

  • Page 49: Appendix A Warranty Information

    Appendix A Warranty Information Current Warranty information is available on-line in the Client Login Area of the Canoga Perkins web site (www.canoga.com) or by contacting Technical Support at 800-360-6642 (voice) or fiber@canoga.com (email). 9160 10 Gigabit Ethernet Network Interface Device...

  • Page 51: Appendix B Acronym And Abbreviation List

    Multiple Spanning Tree Physical Layer RMTF Remote Fault Receive signal SBMC Side-Band Management Channel Single Mode Single Mode Fiber SNMP Simple Network Management Protocol Spanning Tree Protocol TFTP Trivial File Transfer Protocol Transmit signal 9161 Network Interface Device B-1/(B-2 Blank)
