Installation and Operation Manual
Selenio 6800™
SFS6803+/OP+SFS+
Audio/Video Frame Synchronizer
and Processing Amplifiers
Edition E
175-100078-00
Delivering the Moment

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Selenio 6800 SFS6803+OP+SFS+ and is the answer not in the manual?

Questions and answers

Summary of Contents for Imagine communications Selenio 6800 SFS6803+OP+SFS+

  • Page 1 Installation and Operation Manual Selenio 6800™ SFS6803+/OP+SFS+ Audio/Video Frame Synchronizer and Processing Amplifiers Edition E 175-100078-00 Delivering the Moment...
  • Page 2 This publication does not in any way warrant description accuracy or guarantee the use for the product to which it refers. Imagine Communications reserves the right, without notice to make such changes in equipment, design, specifications, components, or documentation as progress may warrant to improve the performance of the product.
  • Page 3 SFS6803+/OP+SFS+ Audio/Video Frame Synchronizer and Processing Amplifiers Installation and Operation Manual Edition E April 2013...

  • Page 5: Table Of Contents

    Contents Preface ........................vii Manual Information ..................... vii Purpose ........................vii Audience ........................vii Revision History ......................vii Writing Conventions ....................viii Obtaining Documents ....................viii Unpacking/Shipping Information ................viii Unpacking a Product ....................viii Product Servicing ....................... ix Returning a Product ....................ix References ........................
  • Page 6 Contents Choosing Upgrade Options ..................16 Selecting an External Balun ..................17 Setting Jumpers ......................17 Setting Jumper J3 for Local or Remote Control ............17 Setting Jumpers for 600Ω/Hi-Z Input Impedance Control ......... 18 Jumper Settings for Analog Audio Output Level ............19 Maximum 6800+ Frame Power Ratings ..............
  • Page 7 SFS6803+ and OP+SFS+ Installation and Operation Manual Changing Parameter Settings Using CCS Software ..........47 Setting SFS6803+ and OP+SFS+ Remote Control Parameters ........48 LEDs and Alarms ......................73 Monitoring LEDs ...................... 73 Module Status LEDs ....................75 Alarms ........................75 Chapter 4 Specifications ......................
  • Page 8 Contents Hardware Communication Problems ................. 99 Index ......................... 101...

  • Page 9: Preface

    Preface Manual Information Purpose This manual details the features, installation, operation, maintenance, and specifications for the SFS6803+ and OP+SFS+ audio/video frame synchronizers and processing amplifiers. Audience This manual is written for engineers, technicians, and operators responsible for installation, setup, maintenance, and/or operation of the SFS6803+ and OP+SFS+ audio/video frame synchronizers and processing amplifiers.

  • Page 10: Writing Conventions

    viii Preface Writing To enhance your understanding, the authors of this manual have adhered to the following text conventions: Conventions Table P-2 Writing Conventions Term or Description Convention Bold Indicates dialog boxes, property sheets, fields, buttons, check boxes, list boxes, combo boxes, menus, submenus, windows, lists, and selection names Italics...

  • Page 11: Product Servicing

    SFS6803+ and OP+SFS+ Installation and Operation Manual Product Except for firmware upgrades, SFS6803+ and OP+SFS+ modules are not designed for field servicing. All hardware upgrades, modifications, or repairs require you to return the Servicing modules to the Customer Service center. Returning a In the unlikely event that your product fails to operate properly, please contact Customer Service to obtain a Return Authorization (RA) number, and then send the unit back for...
  • Page 12 Preface AES3-2003 AES Recommended Practice for Digital Audio Engineering–Serial Transmission Format for Two-Channel Linearly Represented Digital Audio Data TIA/EIA-232-E 1991 Interface Between Data Terminal Equipment and Data Circuit-Terminating Equipment Employing Serial Binary Data Interchange EIA/TIA-422-B 1994 Electrical Characteristics of Balanced Voltage Digital Interface Circuits EIA RS-485 1983 Standard for Electrical Characteristics of Generators and Receivers for use in Balanced Digital Multipoint Systems...

  • Page 13: Safety Standards And Compliances

    SFS6803+ and OP+SFS+ Installation and Operation Manual SMPTE 346-M 2000 Specifications for the fiber optic connector type FC/PC Safety Standards and Compliances Laser Safety on page 95 to find the safety standards and compliances for this OPTO+ series product. A 6800+ series safety manual is shipped with every 6800+ Frame Installation and Operation Manual and can be downloaded from our website.

  • Page 14: Safety Terms And Symbols In This Manual

    Preface In accordance with this EU Directive, companies selling electric or electronic devices in the EU will affix labels indicating that such products must be properly recycled. (See our website for more information on dates and deadlines for compliance.) Contact your local Sales representative for information on returning these products for recycling.

  • Page 15: Chapter 1 Introduction

    Introduction Product Description The SFS6803+ and OP+SFS+ are audio/video frame synchronizers and processing amplifiers with SD-SDI digital video input and one genlock reference video input, and four synchronized and processed SD-SDI outputs with embedded audio.The OP+SFS+(C)xxD module has an optional hardware submodule that provides output over fiber in 1 of 17 wavelengths, and the optional submodule on the OP+SFS+R+D receives a fiber input in 1 of 17 wavelengths.

  • Page 16: Optional Features

    Chapter 1 Introduction One serial digital SMPTE 259M SDI input  Genlock (composite or Tri-Level sync)  DARS input (unbalanced, balanced compatible with SFS6803+BD, OP+SFS+BD, or  external balun) Outputs  Four synchronized serial digital SMPTE 259M SDI processed outputs ...

  • Page 17: Hardware Module Types

    SFS6803+ and OP+SFS+ Installation and Operation Manual Up to 9 frames of HD video delay in Sync mode; 11 frames in Delay mode  The SFS68OPT-3G or SFS68OPT-HD-3G upgrade option adds 10-bit video processing with 1080p (progressive) video standard at 50/59.94/60 Hz frame rates as per SMPTE 424M and dual-link as per SMPTE 372M.

  • Page 18: Hardware Options

    Chapter 1 Introduction Hardware All OP+SFS+R+D and OP+SFS+(C)xxD modules are shipped with standard SC/PC fibre connectors. Other connectors are available (see Table 1-4). Options Table 1-4 Available Connectors Item Description OP+OPT+SC SC/PC fiber optic connectors (standard) OP+OPT+ST ST/PC fiber optic connectors (optional) OP+OPT+FC FC/PC fiber optic connectors (optional) Module Descriptions...

  • Page 19: Back Connectors

    SFS6803+ and OP+SFS+ Installation and Operation Manual Table 1-5 Generic 6800+ Module Features Feature Description Module status Various color and lighting combinations of these LEDs LEDs indicate the module state. See Monitoring LEDs on page 73 for more information. Mode select This switch selects between various control and rotary switch feedback parameters.
  • Page 20 Chapter 1 Introduction SDI IN 1 SDI IN 1 SDI OUT 1 SDI OUT 1 SDI OUT 2 SDI OUT 2 DATA I/O SDI OUT 3 GENLOCK DARS METADATA SDI OUT 4 SFS6803+BD and OP+SFS+BD SFS6803+ and OP+SFS+ Figure 1-2 Standard SFS6803+ and OP+SFS+ Back Connectors HMX6803 + OP+HMX+ OP+HMX+...

  • Page 21: Breakout Cables And Pinouts

    SFS6803+ and OP+SFS+ Installation and Operation Manual Breakout The following cables and pinouts are associated with the SFS6803+ and OP+SFS+ products: Cables and Unbalanced Breakout Cable for SFS6803+D on page 7  Pinouts Pinouts for 44-Pin Connector for SFS6803+BD on page 10 ...
  • Page 22 Chapter 1 Introduction AES 1 In AES1 IN AES 2 In AES2 IN AES 3 In AES3 IN AES 4 In AES4 IN AES 5 In AES5 IN AES6 IN AES 6 In AES7 IN AES 7 In AES 8 In AES8 IN AES 1 Out AES1 OUT...
  • Page 23 SFS6803+ and OP+SFS+ Installation and Operation Manual Figure 1-5 Pin Numbers for 44-Pin Connector for SFS6803+D Table 1-6 Pinouts for 44-pin Connector for SSFS6803+D Modules Pin No. on External Connection Type Description Wire Label DB-44M Cable Color Color GENLOCK GENLOCK Black Black BNC GND...
  • Page 24 Chapter 1 Introduction Table 1-6 Pinouts for 44-pin Connector for SSFS6803+D Modules (Continued) Pin No. on External Connection Type Description Wire Label DB-44M Cable Color Color 162A10019X (DB9.3) BALANCED SERIAL IN- SERIAL (DB9) 162A10019X (DB9.8) BALANCED SERIAL SERIAL Yellow IN+ (DB9) BNC GND AES OUT 8 GND AES OUT 8...
  • Page 25 SFS6803+ and OP+SFS+ Installation and Operation Manual Table 1-7 Pinouts for Balanced 44-Pin Connector (Continued) Pin No. on Connection Pin No. on Connection DB-44M Type DB-44M Type AES_IN4+ AES_IN4- AES_IN6+ AES_OUT8+ AES_IN6- AES_OUT8- AES_OUT1+ AES_OUT5- AES_OUT1- AES_IN3- AES_IN5+ AES_IN1+ AES_IN1- DARS_IN2+ AES_OUT3- DARS_IN2-...
  • Page 26 Chapter 1 Introduction Table 1-9 Pin Assignment of DB-9 Connector (Female) in RS-232 Format Pin No. Signal Comments Frame Ground Frame Ground Frame Ground Transmitted Data Not connected Received Data Not connected Metadata Connector for SFS6803+BD The metadata connector cable (provided) has the following connections: Figure 1-7 Metadata Connector Pinouts Table 1-10 Metadata Pinouts for RS-422 Format Pin Number...
  • Page 27 SFS6803+ and OP+SFS+ Installation and Operation Manual Table 1-11 Metadata Pinouts for RS-232 Format (Continued) Pin Number Signal Comments Frame Ground Not connected Transmitted Data Frame Ground Frame Ground Frame Ground Frame Ground Frame Ground Weidmuller Connector for Analog Audio The SFS6803+AI+T, OP+SFS+AI+T, SFS6803+AO+T, and OP+SFS+AO+T back modules have an additional connector.

  • Page 28: Signal Flow

    Chapter 1 Introduction Table 1-12 Analog Audio Pinouts (Continued) Signal Signal Comments Number Number CH4A+ CH4A- CH4B+ CH4B- In or Out 4 If your module is an SFS6803+AI+T or OP+SFS+AI+T, then the connections will be analog audio inputs. If your module is an SFS6803+AO+T or OP+SFS+AO+T, then the connections will be outputs.

  • Page 29: Chapter 2 Installation

    Installation Unpacking Before you install modules, perform the following: the Module Check the equipment for any visible damage that may have occurred during transit.  Confirm receipt of all items on the packing list. See Checking the Packing List  more information.

  • Page 30: Choosing Upgrade Options

    Chapter 2 Installation Table 2-1 Available Product Packages (Continued) Ordered Product Content Description One SFS6803+BD front module  SFS6803+BD One SFS6803+BD double-slot back connector  Note: Customers must provide a cable for use with the 44-pin connector on SFS6803+BD. Pinouts are listed on page 10.

  • Page 31: Selecting An External Balun

    SFS6803+ and OP+SFS+ Installation and Operation Manual To purchase additional license keys, contact your Sales representative. To activate a license key, see Adding a License Key on page 28. Selecting an If you are not using SFS6803+BD or OP+SFS+BD, for balanced audio you will need external baluns.

  • Page 32: Setting Jumpers For 600Ω/Hi-Z Input Impedance Control

    Chapter 2 Installation Locate jumper J3 on the module (behind the mode select rotary switch). Figure 2-1 shows the location of the J3 jumper. Place a jumper on pins 1 and 2 to set the module for Remote control, or pins 2 and 3 to set the module for Local control.

  • Page 33: Jumper Settings For Analog Audio Output Level

    SFS6803+ and OP+SFS+ Installation and Operation Manual Channel 1B set for 600Ω input Channel 2A set for Hi-Z input Figure 2-4 Jumper Settings for 600W or Hi-Z Inputs Jumper Settings for Analog Audio Output Level This procedure only applies to modules that have the analog audio output submodule: SFS6803+AO+T and OP+SFS+AO+T.

  • Page 34: Maximum 6800+ Frame Power Ratings

    Chapter 2 Installation Table 2-3 Jumper Settings for Analog Audio Output Levels (Continued) Output Level Jumper Jumper Jumper (in dBu, 66 Ω output Impedance) 22 dBu Open Open 1 and 2 24 dBu Open Open 2 and 3 26 dBu Open 2 and 3 Open...

  • Page 35: Installing 6800+ Modules

    SFS6803+ and OP+SFS+ Installation and Operation Manual See the 6800+ Frame Installation and Operation Manual for information about installing and operating an FR6802+QXF, FR6822+, or FR6802+ frame and its components. CAUTION: Before installing this product, read the 6800+ Series Safety Instructions and Standards Manual shipped with every 6800+ Frame Installation and Operation Manual or downloadable from our website.
  • Page 36 Chapter 2 Installation In addition, all fiber optic connections must be inspected and cleaned before they are assembled. Carefully follow the inspection and cleaning steps described in the next pages. Additional safety information appears in Laser Safety on page 95. CAUTION: Ensure that you remove the fiber optic protective covers from the front and back modules before installation.
  • Page 37 SFS6803+ and OP+SFS+ Installation and Operation Manual On the side of the back module that inserts into the front module, remove the inner protective cap from the fiber connection (see Figure 2-6 on page 22). CAUTION: Microscopic dust or other contaminants can seriously impair or disable a fiber optic network.

  • Page 38: Inspecting And Cleaning Fiber Optic Connections

    Chapter 2 Installation Pull out the finger-release screws on the right and left side of the front panel of the frame, and then open the front panel. Grasp the extractor handle on the installed module, and then pull the module out of its slot. Use the handle as a lever.
  • Page 39 SFS6803+ and OP+SFS+ Installation and Operation Manual Keep your cleaning fluids away from open flame or spark.  Figure 2-7 describes the acceptable limits of defects in a fiber connection. Zone 1 Scratches and dust (0 to 20 micron diameter) No scratches or digs are allowed Zone 2 (20 to 50 micron diameter)

  • Page 40: Upgrading Module Firmware

    Chapter 2 Installation Lightly wipe the fiber tip in the central portion of the lint-free wipe. CAUTION: Do not scrub the fiber. Excessive rubbing will leave scratches. Repeat the wiping action on another clean section of the wipe or a new wipe. Inspect the connector again with the fiberscope.

  • Page 41: Chapter 3 Operation

    Operation Operating Notes When you set the control parameters on the SFS6803+ and OP+SFS+, observe the following: If you make changes to certain parameters, other related parameters may also be  affected. See Cross-Functional Parameter Changes on page 42 for more information.

  • Page 42: Activating Sfs6803+ And Op+Sfs+ Functions

    Chapter 3 Operation Activating SFS6803+ and OP+SFS+ Functions The following sections provide information about the SFS6803+ and OP+SFS+ special functions: Adding a License Key on page 28  Fast Video Switch on page 28  Audio Test Tones on page 29 ...

  • Page 43: Audio Test Tones

    SFS6803+ and OP+SFS+ Installation and Operation Manual Audio Test Table 3-1 describes the frequency and levels of each audio output test tone, available as a selection from each of the Output Ch (1–16) Source Select and Audio Procamp AES Tones (1A-8B) Out Source parameters (see page 68).
  • Page 44 Chapter 3 Operation The audio embedding modes are Audio Group (1–4) Embedding Mode parameters (see page 61). Table 3-3 briefly describes the Append, OverWrt, and Auto options available from each of the embedding modes. Table 3-3 Embedding Mode Options Options Description Append Attempts to insert the audio data and control packets...
  • Page 45 SFS6803+ and OP+SFS+ Installation and Operation Manual ADS before embedding Other Other auxilliary data auxilliary data ADS after embedding group 1 Other Other auxilliary data Group 1 auxilliary data Figure 3-2 In Append Embedding Mode, Adding Group 1 When Auxiliary Data is Present If you attempt to insert audio into Group 1 when Group 1 audio data already exists in the ancillary data space, an error is returned, as shown in Figure...
  • Page 46 Chapter 3 Operation ADS before embedding Group 2 ADS after embedding group 1 Group 2 Group 1 Figure 3-5 Append Embedding Mode, Adding Group 2 Following Group 1 An audio group cannot be divided. In Append embedding, the audio group is always added following the last block in the ADS.

  • Page 47: Audio Embedding Errors

    SFS6803+ and OP+SFS+ Installation and Operation Manual Figure 3-8 shows how overwrite embedding appears in the ancillary data space when there is auxiliary data where Group 1 should be inserted. ADS before embedding other other auxilliary data auxilliary data ADS after attempting to embed group 1 other other auxilliary data...

  • Page 48: Mono Channel Audio Embedding

    Chapter 3 Operation Set the embedding mode to Auto.  If the group is present, it will be overwritten; if it is not present, it will be appended. The overwrite and append errors are actually warnings that the operation is not being performed.

  • Page 49: Audio V-Fade

    SFS6803+ and OP+SFS+ Installation and Operation Manual Set the audio group embedding mode (Processing > Audio > Embedding): Audio Group 1 Embedding Mode: Auto Audio Group 2 Embedding Mode: Off (incoming audio group 2 will be preserved) Audio Group 3 Embedding Mode: Off (incoming audio group 3 will be preserved) Audio Group 4 Embedding Mode: Off (incoming audio group 4 will be preserved)
  • Page 50 Chapter 3 Operation Note: Any other combination of reference and output standard triggers a Mismatched Output/Ref Standards alarm. Table 3-5 Supported Reference and Output Video Standard Combinations in Sync Mode Reference Standard Output Video Standard 1080i 59.94 720p 59.94  ...

  • Page 51: Audio Synchronization

    SFS6803+ and OP+SFS+ Installation and Operation Manual Audio Synchronization By default, SFS6803+ and OP+SFS+ synchronize de-embedded or AES input audio with timing information from the video frame synchronizer prior to re-embedding the audio. (See page 60.) If you deactivate the Audio Track Video parameter, you can output unsynchronized audio. You can set the Audio LOV Output Mode parameter so that the audio is either passed or muted in the event of loss of video.

  • Page 52: Seamless Sound Function

    Chapter 3 Operation Seamless When used in conjunction with HMX6803+ as a de-embedder and with HDX6803+ as an embedder, the SFS6803+ can provide an uninterrupted (“popless”) embedding and Sound de-embedding path for the discrete audio channels regardless of the presence or input Function switching of the video, as long as a constant video standard is maintained.
  • Page 53 SFS6803+ and OP+SFS+ Installation and Operation Manual Note: The ADS Clean parameter removes all audio groups from the video stream. If an audio group already exists and you do not want to replace it, or if the audio group to be embedded does not exist, set the ADS Clean parameter to No (Processing >...

  • Page 54: Test Pattern Generator

    Chapter 3 Operation To set the AES output(s) to be sourced directly from the audio deembedder using the appropriate Demux Ch source, set the Output AES 1-8 Source Select parameter to Demux Ch 1/2, Demux Ch 3/4, etc. (Output > Audio Source Select > AES Audio). For optional minimum propagation delay, set the Frame Sync Bypass parameter to Yes (Processing >...

  • Page 55: Audio Delay Ranges

    SFS6803+ and OP+SFS+ Installation and Operation Manual Disable the associated audio embedder (Audio Grp 1-4 Pair 1-2 Embed Control). For  example, if Dolby-E is passing through group 1, pair 1, set the Audio Group 1 Pair 1 Embed Control parameter to Disable. Set the ADS Clean parameter to No.

  • Page 56: Cross-Functional Parameter Changes

    Chapter 3 Operation Seven input parameters (Input > AFD/VI/WSS De-embedder) on SFS6803+ modules  indicate the presence of AFD, WSS, and VI data when you determine the lines where this data is likely to appear, if present. The single processing parameter (Out Aspect Ratio, which appears at Processing > ...

  • Page 57: Ads Clean Parameter

    SFS6803+ and OP+SFS+ Installation and Operation Manual ADS Clean Depending on the setting of the ADS Clean parameter (listed on page 56), the Audio Group (1–4) Embedding Mode parameters have different options. Parameter Table 3-8 ADS Clean Parameter ADS Clean Audio Group (1–4) State Embedding Mode Options...

  • Page 58: Channel Word Length

    Chapter 3 Operation Note: The forced setting (center column) takes effect before the identified parameter (right column) becomes activated or deactivated. Table 3-9 Cross-Functional Parameters Enabled/Disabled Condition Forced Setting Parameters Audio Ch 1 Gain = 0 Audio Ch 1 Gain = Disabled ...
  • Page 59 SFS6803+ and OP+SFS+ Installation and Operation Manual The SD parameters apply when SDI Video Standard Set is set to either 525i 59.94 or  625i 50, or when it set to Auto and SDI IP Video Standard Feedback is 525i 59.94 or 625i 50.

  • Page 60: Changing Parameter Settings

    Chapter 3 Operation Changing Parameter Settings You can change parameter settings at the card edge. You can change the parameter settings, view read-only parameters, view alarms, and adjust alarm settings using CCS software. See the following topics: Changing Parameter Settings Using Card-Edge Controls on page 46 ...

  • Page 61: Changing Parameter Settings Using Ccs Software

    SFS6803+ and OP+SFS+ Installation and Operation Manual Recalling Factory Default Parameter Settings SFS6803+ and OP+SFS+ Parameters on page 49 describes all of the parameter settings for SFS6803+ and OP+SFS+ modules, including the original factory defaults. To return this module to its factory default settings, you can either reset each parameter individually or do a global recall following this procedure.

  • Page 62: Setting Sfs6803+ And Op+Sfs+ Remote Control Parameters

    Chapter 3 Operation If your module has an optional laser transmitter component (OP+SFS+(C)xxD), the Laser Wavelength parameter displays the wavelength. If the module does not have an optical component, the Laser Wavelength parameter displays Not Installed. In addition, OP+SFS+(C)xxD has one additional alarm that standard SFS6803+ modules do not.
  • Page 63 SFS6803+ and OP+SFS+ Installation and Operation Manual All parameters clip unless otherwise indicated. Table 3-12 SFS6803+ and OP+SFS+ Parameters Bank/ Path Parameter Name Function Options or User Range Switch General Serial Number Displays the module’s (string) unique identifier License Key Activates options String Installed Options...
  • Page 64 Chapter 3 Operation Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch  SDI Electrical IP Pres Reports the presence of the SDI input video signal   SDI Optical IP Pres Reports the presence of the SDI input video signal ...
  • Page 65 SFS6803+ and OP+SFS+ Installation and Operation Manual Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch  CRC Error Counter 0, 4 Clears all CRC error Clear counters  EDH Error Counter Reports the number of 0 to 32767 EDH errors that have...
  • Page 66 Chapter 3 Operation Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch Unbalanced  DARS Input Select Selects the source of the DARS signal Balanced  Note: This parameter is only available with SFS6803+BD and OP+SFS+BD options.
  • Page 67 SFS6803+ and OP+SFS+ Installation and Operation Manual Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch Input > Audio > V-bit  V-bit Mute Enable 4, C Enables automatic muting of audio outputs when ...
  • Page 68 Chapter 3 Operation Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch  Group (1–4) Parity Reports if a parity error Error has occurred in the  specified de-embedder  Group (1–4) ECC Reports if an Error Error Correction Code error has...
  • Page 69 SFS6803+ and OP+SFS+ Installation and Operation Manual Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch Group 4 Channel 3– Reports the delay, relative -699050.666 to +699050.645 msec 4 Delay to video, of channel pair 3–4 in audio group 4 Input >...
  • Page 70 Chapter 3 Operation Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch 12 to 19 (525 Input) (14)  VI Detect Line Fld 1 Controls the video line number to detect VI 8 to 22 (625 Input) (11) ...
  • Page 71 SFS6803+ and OP+SFS+ Installation and Operation Manual Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch Enabled  SRC (1–16) Status Reports the state of the specified sample rate Bypassed  converter Processing >...
  • Page 72 Chapter 3 Operation Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch Aud Ch (11–12) 5, F Adjusts delay for the 0.000 ms to (SRC6a–6b) Delay 6, 1 specified audio channel 1320.000 ms ...
  • Page 73 SFS6803+ and OP+SFS+ Installation and Operation Manual Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch Aud Ch (27–28) 7, 1 Adjusts delay for the 0.000 ms to (SRC14a–14b) Delay 7, 2 specified audio channel 1320.000 ms ...
  • Page 74 Chapter 3 Operation Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch (SFS6803+AO+T and OP+SFS+AO+T only) Processing > Audio > Output Gain > Analog Audio Output Analog Applies attenuation to -6 dB to 0 dB Audio Lvl Offset analog audio output levels...
  • Page 75 SFS6803+ and OP+SFS+ Installation and Operation Manual Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch Processing > Audio > Embedding 15 to 54 (1080p, 1080i, and 1080psf  Dolby-E Start Line 12, 9 Specifies the starting formats) (19)
  • Page 76 Chapter 3 Operation Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch Processing > Metadata Disable  Metadata 12, 6 Enables embedding of Embedding Enable metadata Enable  0x45  Metadata Selects the DID to use Embedding DID when embedding 0x50...
  • Page 77 SFS6803+ and OP+SFS+ Installation and Operation Manual Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch Processing > Video > Delay 0.000 us to 29.616 us (1080p 30, 1035i  Horizontal Phase 14, 3 Adjusts the horizontal 60, 1035i 60)
  • Page 78 Chapter 3 Operation Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch Processing > Video > Synchronization  Frame Sync Bypass 13, D Bypasses control for the video frame synchronizer  Delay mode ...
  • Page 79 SFS6803+ and OP+SFS+ Installation and Operation Manual Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch Disable  White Clip Enable 13, 7 Controls level clipping according to the White Enable  Clip Level control White Clip Level 13, 8...
  • Page 80 Chapter 3 Operation Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch  VBI Line (10–20) Deletes to black the active Delete video portion of the  selected VBI line (all standards) ...
  • Page 81 SFS6803+ and OP+SFS+ Installation and Operation Manual Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch Unbalanced  Output AES (1–8) 11, 9 Selects the type of output Interface (balanced/unbalanced) for Balanced ...
  • Page 82 Chapter 3 Operation Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch Output > Audio Source Select > Embedded audio SRC1a (default SRC11a+11b   Output Emb Ch (1– 8, E Selects the source for the for Output Emb 16) Source Select specified output channel...
  • Page 83 SFS6803+ and OP+SFS+ Installation and Operation Manual Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch Output > Audio Source Select > AES audio SRC1a SRC11a+11b   Audio Procamp AES 9, F Selects the source for the (1A-8B) Out Source specified AES audio...
  • Page 84 Chapter 3 Operation Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch (SFS6803+AO+T and OP+SFS+AO+T only) Output > Audio Source Select > Analog Audio SRC1a SRC11a+11b   Output Analog Aud Selects the source for the Ch(1A-4B) Src Sel specified output analog SRC12a+12b...
  • Page 85 SFS6803+ and OP+SFS+ Installation and Operation Manual Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch 12 to 19 (Embed 525)  AFD Embed Line Controls the video line number where the AFD 8 to 22 (Embed 625) ...
  • Page 86 Chapter 3 Operation Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch VI Select Controls the VI code that When Out Aspect When Out Aspect gets embedded (526/625 Ratio is set to 4:3: Ratio is set to 16:9: only) 16:9 top...

  • Page 87: Leds And Alarms

    SFS6803+ and OP+SFS+ Installation and Operation Manual Table 3-12 SFS6803+ and OP+SFS+ Parameters (Continued) Bank/ Path Parameter Name Function Options or User Range Switch Full frame  WSS Select Controls the WSS code that gets embedded (625 14:9 center  only) 14:9 top ...
  • Page 88 Chapter 3 Operation Module status LEDs Monitoring Figure 3-10 Location of SFS6803+ and OP+SFS+ LEDs Table 3-13 Monitoring LEDs Color Indicators Meaning AUTO Green Auto detection of the SD-SDI input standard is active 720P Green Selected video standard is 720p 1035I Green Unused...

  • Page 89: Module Status Leds

    SFS6803+ and OP+SFS+ Installation and Operation Manual Table 3-13 Monitoring LEDs (Continued) Color Indicators Meaning AUDIO 3 Green Indicates presence of AES audio on AES input 3 AUDIO 4 Green Indicates presence of AES audio on AES input 4 AUDIO 5 Green Indicates presence of AES audio on AES input 5 AUDIO 6...
  • Page 90 Chapter 3 Operation The following settings can be made for each alarm within Pilot or Navigator software. Table 3-15 Alarm Options Alarm Option Effect Enable/Disable This option toggles between Enabled and Disabled. If the alarm is Enabled, an alarm condition generates an alarm; but if it is Disabled, the alarm condition is ignored.
  • Page 91 SFS6803+ and OP+SFS+ Installation and Operation Manual Table 3-16 Alarm Definitions (Continued) Alarm Option Default Settings Alarm Name Priority Trigger Clear Loss of DARS Locked (with AES option) 2 sec 2 sec Group (1–4) Append Embedding Error 1 sec 2 sec Group (1–4) Overwrite Embedding Error 2 sec 2 sec...
  • Page 92 Chapter 3 Operation...

  • Page 93: Chapter 4 Specifications

    Specifications Overview The following specifications appear in this chapter: Inputs on page 79  Outputs on page 82  Propagation Delay on page 87  Power Consumption on page 87  Start-Up Time on page 87  Specifications and designs are subject to change without notice. Note: Unless explicitly stated, all references to SFS6803+ and OP+SFS+ also pertain to SFS6803+BD and OP+SFS+BD.
  • Page 94 Chapter 4 Specifications Table 4-1 SDI Video Input 3G HD-SD Item 1.5G HD-SDI Specification SD-SDI Specification Specification 1080p: 23.98, 24, 25, 29.97, 525: 59.94 Hz   Frame rate 1080p: 50, 59.94, 60 Hz 30 Hz 625: 50 Hz  1080psf: 23.98, 24 Hz ...

  • Page 95: Aes/Dars Input (Aes-Enabled Modules Only)

    SFS6803+ and OP+SFS+ Installation and Operation Manual AES/DARS Input (AES-Enabled Modules Only) Table 4-2 AES/DARS Input Balanced/DARS Specification Item (With SFS6803+BD, OP+SFS+BD, Unbalanced/DARS Specification or External Balun) Standard AES 3 AES 3, SMPTE 276M Connector 44-pin connector; or 3-pin connector, BNC (IEC 169-8) female XLR with external balun Sensitivity...

  • Page 96: Outputs

    Chapter 4 Specifications Outputs SDI Video Output Note: 1.5G HD-SDI video output specifications only apply if you have a SFS68OPT-HD license key. 3G HD-SDI video output specifications only apply if you have installed a SFS68OPT-3G or SFS68OPT-HD-3G license key. Table 4-4 SDI Video Output Item 3G HD-SDI Specification 1.5G HD-SDI Specification...

  • Page 97: Aes Audio Outputs (Aes-Enabled Modules Only)

    SFS6803+ and OP+SFS+ Installation and Operation Manual AES Audio Outputs (AES-Enabled Modules Only) Note: Balanced AES output specifications are provided for the configuration with SFS6803+BD, OP+SFS+BD, or external baluns, and require the Output AES Interface Control parameter to be set to Balanced (see page 72).

  • Page 98: Data I/O Output

    Chapter 4 Specifications Data I/O Output Table 4-7 Data I/O Output Item Specification Number of outputs Output connector BNC (IEC169-8) Impedance 75Ω Reference Video Table 4-8 Reference Video Item Specification Level 1 V pk-to-pk +6 dB/-3.5 dB Signal type Analog composite 525/625 or tri-level sync (1080i/p/720p) Connector BNC per IEC 169-8...

  • Page 99: Optical Port (Op+Sfs+(C)Xxd And Op+Sfs+R+D Only)

    SFS6803+ and OP+SFS+ Installation and Operation Manual Optical Port (OP+SFS+(C)xxD and OP+SFS+R+D Only) Table 4-10 Fiber Option Video Output (OP+SFS+(C)xxD) Item Specification Number of inputs Number of outputs Output connector BSC2 Optical Coupler 3 Gb/s  Transmitter signal type 1.5 Gb/s ...

  • Page 100: Rs-232/Rs-422

    Chapter 4 Specifications Table 4-12 Optical Port Performance Specifications–Output (Transmitter) Item Typical Conditions Fixed Wavelength Modules (OP+SFS+13D) Peak wavelength (FP) 1290 nm 1310 nm 1340 Spectrum width (RMS) (FP) 2 nm 4 nm Average output power (FP) -8 dBm -7 dBm -6 dBm Multiple Wavelength Modules (OP+SFS+(C)xxD) Peak wavelength (CWDM)

  • Page 101: Propagation Delay

    SFS6803+ and OP+SFS+ Installation and Operation Manual Propagation Delay Table 4-14 Propagation Delay Item Specification Video Frame synchronizer in Delay Frame synchronizer bypassed: mode and AV Timing off: 1080p 3G: 4.70 µsec 1080p 3G: 1.50 µsec   1080p/i: 9.50 µsec 1080p/i: 3.0 µsec ...

  • Page 102: Operating Temperature

    Chapter 4 Specifications Operating Temperature The operating temperature for SFS6803+ and OP+SFS+ modules is 41° to 113°F (5° to 45°C).

  • Page 103: Appendix A Audio Bit Manipulation

    Audio Bit Manipulation Overview The tables in this appendix contain information on the manipulation of bits that occur when using SFS6803+ and OP+SFS+ modules. The following items are documented: Manipulating Channel Status Bits (C-Bit) on page 90  Manipulating Validity and User Bits (V-Bit and U-Bit) on page 92 ...

  • Page 104: Manipulating Channel Status Bits (C-Bit)

    Appendix A Audio Bit Manipulation Manipulating Channel Status Bits (C-Bit) Table A-2 Channel Status (C-Bits) Data Description Byte Function Remarks RX ignores bit  [0] Consumer Use [1] Professional Use TX sets bit to 1  RX sets up audio ...
  • Page 105 SFS6803+ and OP+SFS+ Installation and Operation Manual Table A-2 Channel Status (C-Bits) Data Description (Continued) Byte Function Remarks RX ignores bits  3 to 5 [000] Not indicated [001] Max Length–1 TX sets bits according  [010] Max Length–2 to transmitted word [011] Max Length–3 length [100] Max Length–4...

  • Page 106: Manipulating Validity And User Bits (V-Bit And U-Bit)

    Appendix A Audio Bit Manipulation Table A-2 Channel Status (C-Bits) Data Description (Continued) Byte Function Remarks RX ignores bits  14 to 17 0 to 7 Local sample address code TX passed bits  unmodified RX ignores bits  18 to 21 0 to 7 Time-of-day sample address code TX passed bits...

  • Page 107: Identifying Audio Characteristics (Audio Sampling Frequency And Word Length)

    SFS6803+ and OP+SFS+ Installation and Operation Manual Identifying Audio Characteristics (Audio Sampling Frequency and Word Length) Table A-4 Audio Sampling Frequency and Word Length Item Remarks RX: 32 to 108 kHz  Audio sampling frequency TX: 48 kHz  RX: 16 to 24 bits ...
  • Page 108 Appendix A Audio Bit Manipulation...

  • Page 109: Appendix B Laser Safety Guidelines

    Laser Safety Guidelines Laser WARNING Safety Use of controls, adjustments, and procedures other than those specified in this document may result in hazardous laser radiation exposure. Optical fiber telecommunication systems use semiconductor laser transmitters that emit infrared light that is normally not visible to the human eye. Although a conventional laser produces a small beam of light, the power density is very high, and it can cause damage to your eyes.

  • Page 110: Precautions For Unenclosed Systems

    Appendix B Laser Safety Guidelines Ensure technicians have satisfactorily completed an approved training course before performing installation or maintenance. Ensure there are appropriate warning labels near the optical ports of the modules. Precautions During service, maintenance, or restoration, an optical fiber telecommunication system is considered unenclosed.

  • Page 111: Appendix C Communication And Control Troubleshooting Tips

    Communication and Control Troubleshooting Tips Software Communication Problems Problem The frame is powered up, but the module does not communicate with CCS Navigator or the web GUI interface. Solutions Ensure you have specified the proper module slot.  See your 6800+ Frame Installation and Operation Manual for more information about slot identification.
  • Page 112 Appendix C Communication and Control Troubleshooting Tips Problem The IP address of the frame has been forgotten. Solution Follow this procedure: Remove the ETH6800+ module from the frame. Select DIP switch 2 on the ETH6800+ module and slide the tab to the forward position. This sets the ETH6800+ module to its default IP address of 192.168.100.250.
  • Page 113 SFS6803+ and OP+SFS+ Installation and Operation Manual Problem CCS software sees the frame, but does not find all of the modules. Solutions Remove any legacy 6800 series products.  Plug your modules in before starting the discovery.  Start your discovery after the frame and all modules have fully powered up. ...
  • Page 114 Appendix C Communication and Control Troubleshooting Tips Problem The module does not seem to work. Solutions Ensure the correct frame is powered up.  Verify that all appropriate rear connections are secure.  Gently push the module into its slot in the frame to ensure it is seated properly. Then ...
  • Page 115 Index Acknowledge, alarm 76 Back connector 5 Adjustable frame delay 36 installing 21 ADS (ancillary data stripper) 30 Balanced audio 3 ADS clean parameter 43 inputs 81 AES input specification 81 outputs 83 AES optional license 2 Bank selection 46 Black clip 65 alarm 77 –...
  • Page 116 Index Delay mode 35 Description, general 1 Laser output specifications 84 Discovering a module 48 – – Laser precautions 21 Dry cleaning 25 LEDs 4 control 46 module status 75 monitoring 73 Embed mode parameters 30 License keys 49 Embedder adding 28 ancillary data 29 purchasing 16...
  • Page 117 SFS6803+ and OP+SFS+ Installation and Operation Manual SD operating mode 44 fiber optic video output 85 setting at card-edge 46 laser output 84 Standards Path, audio 37 RoHS compliance xi PCM audio 44 WEEE compliance xi Phase, horizontal and vertical 63 Start-up time specification 87 Pinouts –...
  • Page 118 Index...
