AirGate-Modbus
INSTRUCTIONS MANUAL
INTRODUCTION ....................................................................................................................................................................................... 1
SPECIFICATIONS ....................................................................................................................................................................................... 2
CONNECTION AND INSTALLATION .......................................................................................................................................................... 3
OPERATION .............................................................................................................................................................................................. 4
OPERATION MODES................................................................................................................................................................................. 5
USING THE OPERATION MODES .............................................................................................................................................................. 6
LONG REACH APPLICATION ..................................................................................................................................................................... 7
SETUP SOFTWARE.................................................................................................................................................................................... 8
CONFIGURATION MODES ........................................................................................................................................................................ 9
DETERMINATION AND SELECTION OF THE SERIAL PORT (COM) - WINDOWS ....................................................................................... 10
CONFIGURATIONS - AIRGATE-MODBUS ................................................................................................................................................ 12
DATA COMMUNICATION - SERIAL ......................................................................................................................................................... 13
DATA COMMUNICATION - WIRELESS ................................................................................................................................................... 14
MODBUS COMMANDS .......................................................................................................................................................................... 15
DESCRIPTION OF SOME REGISTERS ....................................................................................................................................................... 15
HOLDING REGISTERS TABLE ................................................................................................................................................................... 17
SUPPORTED MODBUS REGISTERS ......................................................................................................................................................... 17
ACCESSORIES ......................................................................................................................................................................................... 22
WARRANTY ............................................................................................................................................................................................ 22

INTRODUCTION

AirGate-Modbus is an equipment with a link interface function between a network with Modbus RTU protocol about RS485 and a
wireless network with proprietary protocol about IEEE 802.15.4. Resulting from an advanced technological development, the
product stands out in many aspects, such as high performance, high connectivity and easy setup and operation. This technology is
presented as the ideal solution for applications which require flexibility and interoperability.
Its main characteristics are:
SMA connector for antenna;
2 dBi antenna;
Two connectors for one RS485 Modbus RTU interface;
USB Device (Mini-B);
Status indicator LEDs;
Button used to enter setup mode.
INTAB INTERFACE-TEKNK AB
V1.1x C
AirGate-Modbus
1/22
