Summary of Contents for Snell Advanced Media RollPCI
-
Page 1: User Manual
User Manual RollPCI RollNet Interface Card www.s-a-m.com... -
Page 2: Information And Notices
RollPCI User Manual Information and Notices Information and Notices Copyright and Disclaimer Copyright protection claimed includes all forms and matters of copyrightable material and information now allowed by statutory or judicial law or hereinafter granted, including without limitation, material generated from the software programs which are displayed on the screen such as icons, screen display looks etc. -
Page 3: Safety
RollPCI User Manual Safety Safety Explanation of Safety Symbols Explanation of Safety Symbols Erklärung der Sicherheitssymbole This symbol refers the user to important information contained in Dieses Symbol weist den Benutzer auf wichtige Informationen hin, die in der begleitenden Dokumentation enthalten sind. - Page 4 RollPCI User Manual Safety Simboli di sicurezza: Forklaring på sikkerhedssymboler Questo simbolo indica l'informazione importante contenuta nei Dette symbol gør brugeren opmærksom på vigtig information manuali appartenenti all'apparecchiatura. Consultare il manuale. i den medfølgende manual. Questo simbolo indica che all'interno dell'apparato sono presenti Dette symbol indikerer farlig spænding inden i apparatet.
- Page 5 RollPCI User Manual Safety Símbolos de Segurança O símbolo triangular adverte para a necessidade de consultar o manual antes de utilizar o equipamento ou efectuar qualquer ajuste. Este símbolo indica a presença de voltagens perigosas no interior do equipamento. As peças ou partes existentes no interior do equipamento não necessitam de intervenção, manutenção ou manuseamento por parte...
-
Page 6: Manufacturers Notice
About This Manual This manual covers the following products. • RollPCI - RollNet Interface Card Packing List The unit is supplied in a dedicated packing carton provided by the manufacturer and should not be accepted if delivered in inferior or unauthorized materials. Carefully unpack the carton and check for any shipping damage or shortages. -
Page 7: Table Of Contents
2.1 Installing the RollPCI Card ......... . 9 2.2 Connecting RollPCI to the RollNet Network ......9 2.3 RollNet. -
Page 8: Introduction
1. Introduction 1.1 Description The RollPCI is a network interface card enabling connection between a PC workstation and the RollNet high-speed 75 ohm co-axial network. The network connection, made with RG-62/u cable via BNC T-connectors, supports data rates up to 2.5Mbps. BNC-style 75 ohm terminators must be fitted at either end of a bus. -
Page 9: Hardware Installation
Identify the PCI slot where the RollPCI card is to be fitted. Remove the cover and retaining screw from behind the slot. Position the RollPCI card over the slot and carefully insert the card until it is fully seated. Secure the bracket of the RollPCI card by refitting the retaining screw. -
Page 10: Rollnet Over Rs485
RollPCI User Manual Hardware Installation Unit Type Unit Load IQ 3U Box (IQ3A) IQ 1U Box (IQH1S) IQ 1U Box (IQH1A) Roll PCI 2.4 RollNet Over RS485 RollNet coaxial segments may be joined by ‘RS485’ links to over come the 64 unit load limit. -
Page 11: Device Driver Installation
Device Driver Installation 3. Device Driver Installation Before using RollPCI in conjunction with RollNet IP Share, the relevant device drivers must be installed. The drivers are copied to the hard drive during installation of Rollcall Suite. The procedure for installing the device drivers is different depending on the version of Windows used. - Page 12 RollPCI User Manual Device Driver Installation Navigate to the directory in which the driver is stored. In this example it is: C:\Program Files (x86)\SAM\RollCallSuite\RollNetIpShare\Drivers\pci20_64bit_driver Select the 32 or 64-bit directory as required. Click Next. Select Install this driver anyway. After a few seconds the wizard will have installed the driver. Select Close.
- Page 13 RollPCI User Manual Device Driver Installation The hardware displays under CCSI. Right click on it and select Update driver. 10. Select Browse my computer for suitable hardware. Issue 3 Rev 1 Page 13 © 2015 SAM...
- Page 14 RollPCI User Manual Device Driver Installation 11. Select Let me pick from a list of device drivers on my computer. 12. Click Next. Issue 3 Rev 1 Page 14 © 2015 SAM...
-
Page 15: Windows Xp
RollPCI User Manual Device Driver Installation 13. When the driver has successfully updated, click Close. 3.2 Windows XP The Found New Hardware Wizard displays. Select No, not at this time, and click Next. Select Install from a list or specific location and click Next. - Page 16 RollPCI User Manual Device Driver Installation Select Don't search. I will choose the driver to install, and click Next. Select Non-Plug and Play Device, and click Next. Click Have Disk. Issue 3 Rev 1 Page 16 © 2015 SAM...
- Page 17 RollPCI User Manual Device Driver Installation Click Browse to navigate to the directory in which the driver is stored. In this example it is: C:\Program Files\SAM\RollCallSuite\RollNetIpShare\Drivers\pci20_32bit_driver Select the 32 or 64 bit directory as required. Click OK. Click Next. After a few seconds the wizard will have installed the driver. Select Close.
- Page 18 RollPCI User Manual Device Driver Installation 10. The hardware now displays under CCSI. Issue 3 Rev 1 Page 18 © 2015 SAM...
-
Page 19: Technical Data
Compatibility RollNet and PCI bus LED indicators Green LED (ON) Transmitting RollNET traffic to the network Yellow LED (ON) RollPCI is being accessed via its I/O address Power Requirement Current Demand 400 mA (maximum) Environmental Temperature 0 °C to 60 °C operating -40 °C to +85 °C storage...
