- Page 1 Notices Information Htek EHS30 Adapter User Manual Version 2.0.4.4.24 Feb. 2018...
-
Page 2: Notices Information
To use the EHS30, please follow the instructions in this user manual. This EHS30 is only for indoor use. And also avoid in high humidity, water and some other liquids. Do not use the EHS30 during thunderstorms. -
Page 3: Fcc Statement
Notices Information FCC Statement 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. -
Page 4: Table Of Contents
Table of Content Table of Content Notices Information ......................2 Copyright........................2 Safety Instructions ....................2 WEEE Warning ......................2 Cleaning ........................2 FCC Statement......................3 Table of Content ......................4 Introduction ........................5 Description ....................... 5 Compatibility......................5 Getting Started ........................ 6 EHS-30 Package Contents .................. -
Page 5: Introduction
Introduction Description The Htek™ EHS30 Wireless Headset Adapter is perfect for connecting Htek phones to supported wireless headsets. It is simple to use and install, and allows the user to control off-hook, talk, and on-hook modes of Htek (Hanlongtek) IP phones from the headset. -
Page 6: Getting Started
Getting Started Getting Started EHS-30 Package Contents EHS-30 Ports and LEDs Description (1) RJ-12 Port for IP Phone EXT/EHS or Expansion Module (2) Operation LED (3) 3.5mm DC Power Jack (for Plantronics Headsets) (4) RJ-45 Jack (for Jabra Headsets) -
Page 7: Installation For Plantronics Headsets
Plantronics. 2. Connect the included RJ-12 cord between the EHS-30 Adapter RJ12 Port (Port 1) and the EXT/EHS port of the Htek IP Phone (or to the Expansion Module EXT port, if the expansion module is connected). -
Page 8: Installation For Sennheiser Headsets
EHS-30 Adapter. (The RJ-45 cord may be supplied by Jabra or obtained separately). 2. Connect the included RJ-12 cord between the EHS-30 Adapter RJ12 Port (Port 1) and the EXT/EHS port of the Htek IP Phone (or to the Expansion Module EXT port, if the expansion module is connected). - Page 9 2. Connect the included RJ-12 cord between the EHS-30 Adapter RJ12 Port (Port 1) and the EXT/EHS port of the Htek IP Phone (or to the Expansion Module EXT port, if the expansion module is connected). 3. Connect Telephone Port of the SENNHEISER Wireless Headset to the Headset jack of the Htek IP phone.
-
Page 10: Ip Phone Configuration (For All Wireless Headsets)
IP Phone Configuration (for all Wireless Headsets) IP Phone Configuration (for all Wireless Headsets) For Wireless Headset operation, set the following parameters using the IP Phone Web GUI interface: 1. Log in to the Web Configuration GUI for the IP Phone (as described in t he User Manual). -
Page 11: Headset Usage (For All Wireless Headsets)
Headset Usage (for all Wireless Headsets) Headset Usage (for all Wireless Headsets) To use the connected Wireless headset (instead of the IP Phone handset), p ress the Headset key on the keyboard of the phone. The key will light to indicate that you are in Headset mode.
