Summary of Contents for FAAFTECH FT-LVDS-BM17
- Page 1 INSTALLATION MANUAL FT-LVDS-BM17...
-
Page 2: Installation
4th – Finish the installation process by testing the interface and the accessories. See functioning instructions on pages 7-8. Important Notice: Do not isolate the ventilation entries in the FT-LVDS-BM17 equipment using foam, carpet or similar objects. Doing so can cause damages... -
Page 3: Dip Switches
DIP Switches Set up the interface’s DIP Switches while the equipment is unplugged from the whip, and while the car ignition is off. 1 2 3 4 5 6 7 8 Configuration Table UP enables RGB (GPS) input DIP 1 DOWN disables RGB input UP enables AV1 (DVD) input DIP 2... -
Page 4: Original Screen
CONNECTIONS ORIGINAL SCREEN Connect the LVDS OUT from the equipment to the original screen Remove the original LVDS cable and connect it to the equipment’s LVDS IN Connect the red and white RCA from AV OUT to the whip’s AV IN. Note: for vehicles without AUX input, Connect to POWER connect this to the FM transmitter... - Page 5 CONNECTIONS No function IR sensor connection for pág 2 LVDS remote control usage pág 3 External AV commuting button connection. Optional usage RGB input No function AV1 Input Refer to page 3 (DVD/mirror) No function AV2 Input Use this to power the (TV) rear camera Front camera...
- Page 6 IR PROGRAMMING Lorem ipsum Follow the steps below in order to program the IR that will control the DVD and the Digital TV through the vehicle’s original commands. 1st – After the LVDS installation, select input AV1 or AV2; 2nd – Point the remote to the LVDS IR sensor, connected to the equipment’s IR input.
- Page 7 DVD or DTV on the IR MEMORY menu. Keys for programming 7th – Finish the programming by exiting the MENU OF FACTORY. Scan the QR code to watch the IR programming video, or go to www.faaftech.com/videos/bm17...
- Page 8 USAGE Follow the steps below in order to access and use the equipment’s AV inputs. 1st – In the original multimedia menu, access the AUX audio source. In vehicles without AUX entries, choose the FM frequency from the installed transmitter. 2nd –...
- Page 9 USAGE If you are using a DVD and a TV on inputs AV1 and AV2, it is possible to use the iDrive and the touch commands (when available) to control these accessories. In order to use the iDrive command, spin the iDrive to visualize the icons on the screen, and then spin the iDrive to select the icon you want.
- Page 10 Problem Solving 1.After installing the interface, the radio won’t turn on. • Review the installation and check if the cables are connected according to the images on pages 3 and 4; • Check if the cables are well connected.; 2.When I try to access AV1 or AV2, no sound will come out. •...
-
Page 11: Warranty
Warranty FAAFTECH assures their clients a 01 (one) year period against defects in materials and workmanship, proved by presenting both the receipt of purchase from the reseller to the costumer and the present Warranty Certificate filled, observing the following: 1. FAAFTECH will null the warranty if Faaftech or their authorized technical... -
Page 12: Technical Support
TECHNICAL SUPPORT Follow us on social media +55 0800 603 2330 or +55 62 3241 4600 suporte@faaftech.com.br www.faaftech.com.br Available from Monday to Friday, from 8 a.m. to 6 p.m. Brasilia time...
