Summary of Contents for AutoCoach ACS300
- Page 1 ACS300 Wireless Speaker Hub User Manual...
-
Page 2: Table Of Contents
5.1 Squad: ........................10 5.2 Channel: ........................10 13. Charging the battery .................... 11 13.1 AC Adapter:......................11 14. Caring for your AutoCoach device ............... 12 14.1 Storage:......................... 12 14.2 Handling: ....................... 12 14.3 Resetting: ......................12 ACS300 Speaker Hub User Manual... -
Page 3: Acs300 Controls & Indicators
Note: There are two types of button presses on buttons 1 and 2 . A “Short Press” is of less than 0.5 Seconds Duration. A “Long Press” is of greater than 0.5 Seconds duration. ACS300 Speaker Hub User Manual Page 2... - Page 4 ① - Menu Button - ON / OFF Button – when long pressed inwards. Menu Item Selector – twist knob to cycle through menu items. Battery Percentage Readout – short press inwards activates a voiced reading of the ACS300’s remaining battery percentage.
-
Page 5: Turning On And Off
When the unit’s battery falls below 50%, the Status LED 3 will turn from blue ○ to green. When the battery falls below 25%, the Status LED 3 will start flashing red. At this point we recommend charging the Speaker Unit. ACS300 Speaker Hub User Manual Page 4... -
Page 6: Resetting The Unit
3 Seconds. After two seconds the unit will announce “Rebooting” followed by the Status LED flashing for approx. 1 second. After booting, the unit will announce the software version (AutoCoach version .8). Press in both Dials for more... -
Page 7: Connecting To Your Smart Watch
Confirm your connection by starting a race in Master Race Mode on your Smart Watch and listening for the Starter Sounds from the Speaker Unit. Refer to ACS100 User Manual for detailed instructions regarding your Smart Watch ACS300 Speaker Hub User Manual Page 6... -
Page 8: Connecting To Your Computer
“race start” (a voiced “take your marks” and a start beep) depending on what button is used with the Smart Watch. Regardless of which start is chosen, the Speaker Unit will also produce a bright white starting flash. ACS300 Speaker Hub User Manual Page 7... -
Page 9: Timing Mode
Times recorded by the left stopwatch in the Smart Watch, including splits, will be read out by the Speaker Unit preceded by “left”. Times read out by the right stopwatch will be read out by the Speaker Unit preceded by “Right”. ACS300 Speaker Hub User Manual Page 8... -
Page 10: Smart Watch In Master Interval Mode
Speaker Unit preceded by “Right”. Alternatively, a “coach start” (voiced “8, 9, go!”) can be used by changing the Squad Setup in the ACS100 Smart Watch to an even number value (e.g. squad 6). ACS300 Speaker Hub User Manual Page 9... -
Page 11: Other Menu Items
1 until the Speaker Unit announces ○ “Channel”. From here, use the Select Dial 2 to choose a desired group and ○ hold down the Select Button 2 until the Speaker Unit confirms the selection by announcing “Store”. ACS300 Speaker Hub User Manual Page 10... -
Page 12: Charging The Battery
6. Charging the battery 6.1 AC Adapter: The ACS300 Wireless Speaker Hub can be recharged with the supplied AC Adapter (5V 1000mA USB socket), or by connecting the unit to a PC or MAC via the supplied USB cable. From 0% Battery level, charging usually completes within 3 hours. We recommend recharging when the battery level is below 30%, in order to be confident you have enough power for a day’s usage. -
Page 13: Caring For Your Autocoach Device
7.2 Handling: The Speaker Unit is water RESISTANT, and NOT water proof. Do not submerge the ACS300. After usage around splashes, make sure to shake water out of the unit and wipe off remaining droplets. 7.3 Resetting: If the program fails to respond or the device will not turn on, try performing a Reboot as per Section 1.3.
