5617 (V1.0)
Remote Video Unit
With 15" LCD Monitor
Model Numbers
5617-P..........................................Post Mount w/Standard LCD
5617-SUN-P................................Post Mount w/ Sun View LCD
5617A-P.......................................Post Mount w/ Standard LCD and Audio Speaker & Microphone
5617A-SUN-P..............................Post Mount w/Sun View LCD and Audio Speaker & Microphone
5617-S..........................................Side Arm Mount w/Standard LCD
5617-SUN-S................................Side Arm Mount w/ Sun View LCD
5617A-S.......................................Side Arm Mount w/ Standard LCD and Audio Speaker & Microphone
5617A-SUN-S..............................Side Arm Mount w/Sun View LCD and Audio Speaker & Microphone
FOR TECHNICAL SUPPORT CALL 1-877-236-0245
For more complete system information see the document
"5000 Series Audio/Video System Installation & Service Manual"
08-325 (11/7/11)
Advertisement
Table of Contents
Summary of Contents for Hamilton 5617-P
- Page 1 5617 (V1.0) Remote Video Unit With 15” LCD Monitor Model Numbers 5617-P..........Post Mount w/Standard LCD 5617-SUN-P........Post Mount w/ Sun View LCD 5617A-P........Post Mount w/ Standard LCD and Audio Speaker & Microphone 5617A-SUN-P......Post Mount w/Sun View LCD and Audio Speaker & Microphone 5617-S..........Side Arm Mount w/Standard LCD...
- Page 2 For larger installations it may be desirable to have more than one power control kit if some lanes are closed at times while other lanes are open. Optionally Hamilton Air pneumatic units that have an E0873 I/O Control Board can use an E10036 Video Power Control Cable to control the relay board in the video head.
- Page 3 If the 5617 includes audio, connect the speaker wires to the black/white twisted pair and the microphone wires to the shielded cable. Note for Hamilton Air units that have an I/O Control Board: Connect the cable from the audio matrix to the control board terminal strip as usual.
- Page 4 Figure 5 Important Note: Newer Hamilton Air units that have an E0873 I/O Control Board do not require the Video Power Control Kit. For these units use a Video Power Control Cable (E10036) to connect the I/O Board in the pneumatic unit to the Relay Board in the 5617.
