Thank you for your purchase of a spec.dock iPod solution for your vehicle. 2point5
recommends professional installation of our packages. Audio connections may vary according
to your particular setup. For any clarification on your particular vehicle, please email
info@2point5.com
or call 770-414-6038 with any further questions.
spec.dock BMW e63 v.2 Installation Instructions
Begin by gently prying the hazard and door lock button assembly out of the dash trim.
This is quite possibly the most delicate and difficult part of the installation process. It is
not recommended to use any metallic tool. There are specially designed plastic panel
tools that are quite effective at removing this switch, which most installation
professionals should have at their disposal. Cosmetic damage to the trim and switches
can occur if extreme caution is not used.
1
Advertisement
Summary of Contents for 2point5 spec.dock
- Page 1 Thank you for your purchase of a spec.dock iPod solution for your vehicle. 2point5 recommends professional installation of our packages. Audio connections may vary according to your particular setup. For any clarification on your particular vehicle, please email info@2point5.com or call 770-414-6038 with any further questions.
- Page 2 Once you have removed and unplugged the switch, you will see a single Torx T-20 screw located behind and above the switch. Remove this screw. Now, using only your hands, unsnap the center air vents from the dash and set aside.
- Page 3 After removing the air vents, you will see two Phillips-head screws to be removed. Once these have been removed, use only your hands to unsnap the trim around the radio as shown. Be careful to unsnap the clips all the way around before attempting to fully remove this piece.
- Page 4 Behind the climate controls in the radio trim piece you just removed, you will see three plugs that must be disconnected. Unplug these and set the radio trim piece aside. Once you have disconnected these electrical connections, do not turn the vehicle’s ignition on again until all plugs are reconnected.
- Page 5 After unsnapping and lifting the shift boot out of the way, use only your fingers again and unsnap the trim bezel around the shifter as shown. On the backside of the trim bezel around the shifter are three plugs to be disconnected.
- Page 6 Underneath the shifter trim bezel are three more Philips head screws to remove. Once these screws are removed, you can begin to lift the final trim piece around the shifter out of the console. This piece includes the ashtray location where the spec.dock will be mounted.
- Page 7 On the backside of this trim, you will need to disconnect the cigarette lighter and the three plugs shown here. This piece can now be removed completely from the vehicle.
- Page 8 You can now route the spec.dock’s wiring through the factory opening shown above and lower the spec.dock into position. Make sure that the ashtray carrier itself is free of debris and has been cleaned with a degreaser such as denatured alcohol to ensure proper adhesion of the included double-sided tape.
