DTY MD12 Operation Manuals

2-ch vehicle digital video recorder

Advertisement

Product:
Model:
Frame number:
Purchase Date:
Year
Month
Client name:
Contact Address:
Contact Tel:
Guarantee Maintain Explanation
1.Filling the card according to the facts.
2.The card must be sealed with franchiser's cachet, or it is
invalidation.
3.Guarantee date: if any defective goods found within 1 year,
our factory repairs it freely.
4.the following situations are not within guarantee range:
(1)beyond guarantee date;
(2)owing to connection error, the chip be burnt;
(3)man-made mistakes.eg:the disrepair shell or button;
(4)assemble or disassemble it by oneself;
(5)operate it beyond temperature, humidity ratings;
(6)other defect which are not made by our factory.
5.If need guarantee, please contact the franchiser to confirm it.
6.
Please keep the guarantee properly. We will not supply it again if
you lose.
Day
D V R
使 用 说 明 书
The instruction apply to following model:MD12/MD12G. Please read carefully before operation!
MD12

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MD12 and is the answer not in the manual?

Questions and answers

Summary of Contents for DTY MD12

  • Page 1 (6)other defect which are not made by our factory. 5.If need guarantee, please contact the franchiser to confirm it. Please keep the guarantee properly. We will not supply it again if you lose. The instruction apply to following model:MD12/MD12G. Please read carefully before operation!...
  • Page 2: Table Of Contents

    INDEX Q1: Crash Solution: Cut off power, then restart. Q2: No Image Solution: Check the camera connection. Note: connect/pull out the camera after power off. Q3: Unable to power on Solution: Check the power connection & power capacity of battery. Q4: Unable to power on after dirty shutdown while updating Operation of power and controlling combined wire...
  • Page 3: Boot Rec

    6. Please keep water and any liquid away from the machine, in order not to cause short circuit; 7. Please don't press buttons simultaneously and operate illegally, or it won't work. Function introduction MD12 is a new generation of 2 channels digital video recorder. By adopting advanced dual- . Reset Select Reset ,Press OK to comfirm.
  • Page 4: Packing List

    PACKING LIST SYSTEM SETTINGS Packing list 5. System Setting--On Main Menu page, select System Setting, press OK to confirm. Left image System Setting will be shown. One mainframe ; 6. One IR emote control Time Time Zone Press UP or DOWN to select, and press OK to Language confirm.
  • Page 5: Schedule

    On Rec. Setting page, select Technical parameter Overwrite, and press OK to confirm. Left page REC. Setting will be shown: Item No. MD12 Boot Rec. Overwrite record when full Working voltage DC 12V~24V(suggest to use vehicle power adapter) Pre Event Rec.
  • Page 6: Time

    INTERFACE EXPLANATION Interface explanation 3.3.2 Mask Area--When the Mask Area is selected, left image will be shown. Yellow Square: It is the Active Square, press UP, DOWN, LEFT, RIGHT to move the yellow square Power and controlling combined and select the area you want to mask, press OK to wire interface confirm.
  • Page 7 CONNECTING DIAGRAM Connecting diagram 3.1 Boot Rec--On REC. Setting page, select Boot Rec., and press OK to confirm. Left page REC. Setting will be shown. Boot Rec. YES--Start record once turn on Pre Event Rec. NO--Don't start record when turn on Motion Detection Schedule Press UP or DOWN to select, and press OK to...
  • Page 8: Format

    SD CARD INSTALLATION SD card operation instruction 2. Video Setting On Main Menu, select Video Setting by pressing UP or DOWN key, and press Video Setting OK to enter into submenu as left image shown. Here you can set the video resolution, frame rate and quality.
  • Page 9: File Browse

    Main Menu Operation of power and controlling combined wire 1. Automatic control: Press MENU key to enter into Main Menu, use UP or DOWN key to select submenu, press Feature: DVR start working once engine is started, and it will turn off after saving the OK to confirm.
  • Page 10: Reset

    IR REMOTE CONTROLLER CONTROL OPERATION Turn on/off IR remote controller control operation 1. Turn on DVR automatically: DVR will be turn on automatically when starting engine.(Powe ndicator will be steady red) 2. Standby status: when DVR is turned on, press the " "...
