APEX BASE-CAMP TENT
User HandBook
Warning:
KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS GAZEBO FABRIC.
This Gazebo is made with fabric that meets CPAI-84 Specifications for
flame resistance. It is not fire proof. The fabric will burn if left in continuous
contact with any flame source. The application of any foreign substance to the
.
gazebo fabric may render the flame-resistant properties ineffective.
Made in China
Undercover
Littleton, CO
®
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Apex Digital BASE-CAMP
Summary of Contents for Apex Digital BASE-CAMP
- Page 1 APEX BASE-CAMP TENT User HandBook Warning: KEEP ALL FLAME AND HEAT SOURCES AWAY FROM THIS GAZEBO FABRIC. This Gazebo is made with fabric that meets CPAI-84 Specifications for flame resistance. It is not fire proof. The fabric will burn if left in continuous contact with any flame source.
- Page 2 Must Be Securely Anchored At All Times RAIN WARNING Do not leave unattended in continuous precipitation as water can pocket and cause frame damage. Material is water resistant however we recommend using an occasional waterproof spray to help prevent minor seam dripping.
- Page 3 What’s Inside Base Camp - 1 Set Spikes Pouch Spare Parts Wrenches & Spare Parts Small Spike Frame Big Spike Wheel Bag Top & Polyester/Screen Polyester Door Handbook Combination Door Dome Room - 2 Sets Big Poles Dome Floor Small Poles Big Spike Pole Bag Small Spike...
-
Page 4: Warranty
Warranty It is important that you read this carefully before attempting the Setup! CONGRATULATIONS! You have taken a giant step into a new world of Personal-Shelter ® The Best Choice in Popup-Shade ® ... wherever life-takes-you! Caution! Please read this before proceeding. As a new Undercover ®... - Page 5 Polyester Top Attachment It is important that you read this carefully before attempting the Setup! Note: When assembling be careful not to let polyester-skin touch the ground to prevent dirt and staining. SRT Buckle Snap in all (4) top buckles at the SRT attachment.
- Page 6 Operating Instructions It is important that you read this carefully before attempting the Setup! Base Camp Set-Up: Place the shelter in the center of the area to be covered. Step on footplate, pull leg upward until it locks in the first extended position.
- Page 7 Operating Instructions It is important that you read this carefully before attempting the Setup! Dome Room Set-Up: These free stand Dome Rooms will attach to any side of the Base Camp and zipper into place. Small aluminum pole is for back window of dome room.
- Page 8 Operating Instructions It is important that you read this carefully before attempting the Setup! 1. Move the Dome Room into position so the Connecting Zippers on the base and Dome Room easily fit together. Close the zippers from the top of the arch all the way to both sides.
-
Page 9: User Information
User Information It is important that you read this carefully before attempting the Setup! Frame Break-In Your new frame may be stiff or tight upon first usage, a short break-in period may be required. To help expedite the seating process there are a few things you can do. Lightly apply some WD-40 or other lubricant on a dry cloth, rub down the outer legs and wipe away any remaining residue. - Page 10 One-Person Setup It is important that you read this carefully before attempting the Setup! Position frame assembly in open area. Lock all four upper corner- sliders as shown. Expand frame by slightly lifting and spread to arms length. Extend telescopic legs one at a time to the first lock Carefully lift one side of position, while walking...
-
Page 11: Replacement Parts
Replacement Parts IDENTIFYING PARTS Truss Bar Corner Leg UC-3P8APEX Base Camp Dome Cap Peak Pole Dial-A-Fit ® Truss Bar SRT Mold Corner Mold Dome Cap Peak Pole Corner-Slider Velcro Attachment U-Bracket Leg-Slider U-Bracket Spikes Corner Leg Assembly Upper Leg & Lower Leg Footplate Footplate CRS Wire... -
Page 12: Rules Of The Road
Rules-of-the-Road IMPORTANT INFORMATION READ BEFORE SETUP NEVER setup your Undercover ® without properly anchoring. NEVER leave your shelter unattended. NEVER BBQ or grill beneath your shelter. NEVER forcefully setup or takedown. NEVER assume there is no-wind. NEVER assume that light-rain will not pocket water. NEVER setup near overhanging or other electrical wires. - Page 13 Breakthrough Technology Inner-Truss U-Push Lever U-Wedge Strength and Durability: Forces of Pinch Proof Release Lever: Users Corner-Seam Support: In pursuit of nature play havoc on all pop-up type often complain about the difficulty of setup the Perfect-Fit are critical polyester-skin shelters.
- Page 14 APEX User HandBook GetUndercover.com...
