Gas on Glass Hob Range
JSI-UK Models
30, 40, 60, 70, 90 & 120cm:
3110 Series
4110 Series
6110 Series
6170 Series
6410 Series
7110 Series
7120 Series
7130 Series
7410 Series
9110 Series
9120 Series
9130 Series
9140 Series
9160 Series
9170 Series
9210 Series
9510 Series
9170 Series
1270 Series
January 2014
Version 4 English (UK)
PLEASE READ FULLY BEFORE INSTALLATION OR USE.
OPERATING AND INSTALLATION - JAN 2014
Installation Instructions
User Guide
Warranty Information
*LPG USE - SEE PAGE 4 and 5
WWW.JSI-UK.COM
(Manual Control Models Only)
Index
WEEE
Dimension and Cut Outs
Warranty
Page 1
Page 2
Page 3
Page 3
Page 4
Page 4
Page 4
Page 5
Page 6
Page 8
Page 8
page 8
Page 9
Page 9
Page 1 of 9
Advertisement
Table of Contents
Summary of Contents for JSI 3110 series
-
Page 1: Table Of Contents
Gas on Glass Hob Range (Manual Control Models Only) Installation Instructions User Guide Warranty Information JSI-UK Models Index 30, 40, 60, 70, 90 & 120cm: 3110 Series Packaging Page 1 4110 Series WEEE Page 2 Safety Page 3 6110 Series... -
Page 2: Operating And Installation – Jan
Your warranty cover is for 2 year parts and labour and a further 3 years parts See Warranty section of this user guide for further information Should your JSI appliance require a repair within the manufacturing guarantee period please call 01666 317077 OPERATING AND INSTALLATION –... -
Page 3: Packaging
(2002/96/EC) (The “WEEE Directive”) and the subsequent European Parliament and Council Directive 2003/108/EC that amended the WEEE Directive. As a result, JSI-UK pay a proportion of the purchase cost to ensure that collection of the equivalent weight of household appliances are disposed in accordance with these regulations when purchased through a retailer or trade supplier. -
Page 4: Safety
Safety In use The JSI range of gas hobs have flame failure devises fitted as standard to all of the burners. The use of gas appliances without flame failure devices is illegal in the UK where there is multiple occupancy (flats, apartments etc.) so this hob may be fitted anywhere. -
Page 5: Safety Of Children
The minimum safety distance between the top of the gas cooker or hob and the bottom of the cooker hood is 65cm (electric hobs) and 75cm (gas hobs) or those clearances as provided by the hood OPERATING AND INSTALLATION – JAN 2014 WWW.JSI-UK.COM Page 5 of 9... -
Page 6: Installation
The power cable should be H05VV-F type 3 core 5mm and no more electrical appliances should be connected through it. The connection leads are in accordance with the following codes: Green/Yellow = Earth Blue = Neutral Brown = Live OPERATING AND INSTALLATION – JAN 2014 WWW.JSI-UK.COM Page 6 of 9... - Page 7 2) Remove the injectors by removing their screws and replace with the LPG jets supplied in the original fittings pack. 3) Refit the burners and pan supports 4) No air adjustment is required with these products from JSI-UK Minimum Adjustment 1) Remove by pulling the gas knobs 2) Ignite the burner and turn the adjustment screw clockwise to decrease and clockwise to increase flame intensity.
-
Page 8: Operation Controls And Use
Triple Crown 240-260mm o All JSI Models have Flame Safety Devices. To light, press control knob down and turn anticlockwise to light. Hold down for about 10-15 seconds to establish flame. o If the flame goes out for any reason, the Flame Safety Device will shut down the gas supply and the lighting process will need to be recommenced. -
Page 9: Service
The warranty, after sales, repairs and maintenance are all covered by JSI Service across the UK. If your appliance should break down with the warranty period contact our after sales team on: JSI SERVICE 01666 317077 Repair parts are stocked in the UK which supports engineers all over the country.
