1. Included Parts
B20
B30
B20/B30 Installation Instructions
CV 21 (20 300)
x 6
x 6
x 3
CV 30 (20 400)
x 6
x 2
CV 32 (20 500)
x 6
x 6
x 6
CV 42 (20 600)
x 6
x 6
1(4)
Halyard (Marine & Industrial) Limited
Whaddon Business Park
Southampton Road
Whaddon, SP5 3HF
T: +44 (0)1722 710922
F: +44(0)1722 710975
E: technical@halyard.eu.com
W: www.halyard.eu.com
Advertisement
Subscribe to Our Youtube Channel
Summary of Contents for Aquadrive B20
- Page 1 B20/B30 Installation Instructions Halyard (Marine & Industrial) Limited Whaddon Business Park Southampton Road Whaddon, SP5 3HF T: +44 (0)1722 710922 F: +44(0)1722 710975 E: technical@halyard.eu.com W: www.halyard.eu.com 1. Included Parts CV 21 (20 300) CV 30 (20 400) CV 32 (20 500)
- Page 2 2. Tools Required 3. Installation 2(4)
- Page 3 187 Nm 138 lb.ft > 1 mm (3/64") < 3 mm (1/8") 3(4)
- Page 4 B20 42 Nm / 31 lb.ft B30 85 Nm / 62 lb.ft B. Removal A. Installation Remove the screws and screw them into the releaset hreads of the front ring, Thighten screws lightly and align hub. Tighten screws in diametrically opposite sequence in two or three stages up to prescribed settings tabled in these pressing off the rear ring and releasing taper sleeve (fig B).
