Mighty Dwarf 5002-40100 Manual

Vibration speaker

Advertisement

Quick Links

6
1
2
4
3
5
12
7
Play/Pause button
Charging LED Light
1
Red light on for charging,
8
PREV/Volume minus
2
Green light for fully charged
button
ON/OFF/BT
Mic
3
"OFF" button-speaker off,
9
Next /Volume plus
"ON" -Line in function,
4
button
"BT"-Bluetooth function on
Bluetooth hands-free
Line in
10
5
phone call button
3.5MM Audio Port
LED
Light
Line out
Connect other audio
Red light on for Line in
11
6
device to play music
function, blue light on
at the same time.
for Bluetooth function
DC 5V(Micro USB)
NFC induction zone
7
12
4

Specifications

Testing Contents
Power Output
RMS 26W
S/N
≥65dB
Frequency range
30Hz---18KHz
Speaker Impe dance
4Ω,26W
Power Supply
Built
in 1400mAh Lithium battery
-
3.5mm audio jack
Audio Socket
phone
Tablet PC
PC
Audio Source
,
,
NFC
Bluetooth 4.0,Line in/out,Hands-free MIC,
,
Function list
Touch Panel

Sparkling Features

●Superbass- 26W output, Higher content Neodymium
vibration driver grants more powerful sound
●Power supply
high-class Lithium battery, more powerful and
energy-saving(3.7V, 1400mAh)
Upgrade the power supply means from external
power adaptors to DC 5V micro USB charging cable
●Touch Panel - LED indicator light on touch panel
simplifies your options
1
Feel different rhythm on different materials
material
8
9
10
11
Bluetooth Pairing name: Vibro-26W
●Bluetooth software version: CSR 4.0 + EDR
●Bluetooth working distance: 0-10 meters for
Bluetooth audio device.
Computer
MP3/4
etc
,
,
,
.

Near Field Communication

Bluetooth connection is enabled by simply
using your smartphone touches the NFC
induction zone or bring them into proximity,
usually no more than a few inches.
●Then music on your smartphone will be played
automatically.
●Touch the induction zone again, Bluetooth is
disconnected, the speaker will remember where
the music stops.
sounds perfomance
Back Page
2
Cover Page

Touch Key

Mic
Hands-free
When the speaker is connected to your smartphone
via Bluetooth, if a call comes in, just a simple touch
on the phone mark on speaker, then you can talk with
your friends freely.
Line in/out
It can work with smartphone, computer, MP3, MP4,
most of the audio device.It enables multiple speakers
playing music at the same time.
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5002-40100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mighty Dwarf 5002-40100

  • Page 1: Specifications

    Feel different rhythm on different materials sounds perfomance material Play/Pause button Charging LED Light Red light on for charging, PREV/Volume minus Green light for fully charged button ON/OFF/BT “OFF” button-speaker off, Next /Volume plus “ON” -Line in function, button “BT”-Bluetooth function on Bluetooth hands-free Line in phone call button...
  • Page 2 5002‐40100 Addendum: Troubleshooting    LED Light Indicator  (Refer to control menu on user manual, #6)    Solid RED= Audio Line in Mode  Fast Blinking BLUE= Bluetooth enabled, on discoverable mode.  Dimming Blue Blinking= Error in pairing and require restart.  Solid BLUE= Bluetooth enabled, already Paired with Bluetooth device    Standard Bluetooth troubleshooting Procedure:    1.  Enable Bluetooth function on the device you wish to connect the speaker with and wait a few second to make sure the Bluetooth module  is fully enabled.  2.  Turn on the speaker to Bluetooth (BT) mode (with Blue LED indicator light flashing) and wait three seconds after the “beeping sound”  before trying to pair the device.  3.  Usually it takes a few seconds to discover the speaker: “VIBRO‐26W”  4.  If you are having trouble ID the speaker with Bluetooth:   • For Android device, you will need to press “SCAN” button and wait for the scan to complete.  • For IOS device, you can simply close the Bluetooth function and turn on again to search for the speaker.    If you are still having difficulty pairing your device with the speaker, Please restart both  the speaker and your device. (Refer to your device  manual for restarting instructions if necessary)  Standard NFC troubleshooting Procedure:  1. Make sure that your device has NFC function and locate your NFC antenna (please refer to back of your device or user manual for NFC  antenna location).   2. Turn  on  the  speaker  to  Bluetooth  (BT)  mode  (with  Blue  LED  indicator  light  flashing)  and  wait  three  second  after  the  “beeping  sound”  before trying to pair the device. ...
