EMO Systems PSU E720 Instructions For Use

Models

EMO BATTERY PHANTOM PSU E720 (20-720)

Description

Single channel, battery powered, 48 volt microphone phantom power supply.
Low battery indicator.
Battery life, using an alkaline battery – approx. 80 hours.
Dimensions: 110 x 60 x 32mm.

Battery

This unit is powered by a 9V battery; PP3, MN1604, 6LF22, 4022 or equivalent.
The battery is fi tted by removing the four lid screws.
Take care not to trap the battery leads when replacing the lid.
The use of an alkaline battery is recommended to ensure long life.
It should be replaced at least annually.

Operation

The unit is turned on by operating the rocker switch on the box lid.
The 'Low Battery' indicator will illuminate for a short time at switch-on. If this does not happen then either the battery is
dead or there is no battery fi tted.
If the 'Low Battery' light comes on during operation (or does not extinguish after switch-on) then the battery should be
replaced as soon as possible.
The unit will continue to supply 48V down to very low battery voltages.
Only use suitable microphones with this 48V phantom power supply.
Do not connect microphones requiring a T-Power supply to this unit.
For further information or servicing please contact your local E.M.O. Dealer.
E.M.O. Systems, Crowther Road, Washington, NE38 0BW, UK. (Tel:+44 (0)191 418 1000), www.emosystems.co.uk
Our Policy is one of continuous development: all specifi cations and design details are subject to change without notice.
