Page 2
ExaSAN C1M Quick Start Guide TABLE OF CONTENTS Page# TABLE OF CONTENTS ....................1. What should be in the box? ................2. What "C1M" supports?..................3. Hardware configuration ..................4. C1M LED indicators ....................5. Note ..........................
Page 3
1. What should be in the box? 2. What "C1M" supports? The ExaSAN C1M has 1 QSFP port and 1 Thunderbolt port to convert ExaSAN PCIe to Thunderbolt with downward compatibility. C1M is compatible with following ExaSAN products: ExaSAN PCIe Storage:...
Page 4
2. Connect up your hardware accordingly, power up your storage first, then power up the C1M ( connect the power adapter to C1M and make sure the flip switch in on DAS mode ), lastly power up your MAC device.
Page 5
b. Add controller (click Add Controller bottom in RAIDGuardX GUI) If all hardware were connected correctly, your storage controller should appear as localhost, if not, please try manually adding on the controller (you can find “Manual Add Controller” in Manu Bar/Controller) and input IP 127.0.0.1 to search, notice, default password is 00000000(eight zero) Storage controller appear as localhost.
Page 6
c. Create array d. Format device (click Create Array bottom in (/Applications/Utilities/Disk Utility) RAIDGuardX GUI) Once storage array is created, you After adding the controller, you can can see the storage device in disk create your storage array to your utility, format it to your desired layout desired configuration.
Page 7
4. C1M LED indicators When C1M is active, you can refer to the following description for the front LED. indicators. Green / White Blue Name Description DAS mode in green/ Flash when data transfer is occurring Mode/Access indicator SAN mode in white/...
