Summary of Contents for Shenzhen Clou IOT Technologies Co., Ltd CL7206B5A
- Page 1 CL7206B5A Integrated Fixed Reader User Manual (V1.0.1) Shenzhen Clou IOT Technologies Co., Ltd ...
- Page 2 Welcome to be CLOU’s user. Thanks for choosing CLOU’s Integrated Fixed Reader CL7206B5A. We believe our device will bring convenience for your work.
-
Page 3: Table Of Contents
CONTENTS I, Technical specifications .................................. 5 1.1 Product features .................................... 5 1.2 Main functions & technical specifications ........................... 5 1.2.1 The main function ..................................5 1.2.2 Performance Parameters ............................... 5 1.2.3 Work Environment ..................................6 II, Physical structure .................................... - Page 4 4.1 Demo software functions ................................ 13 4.2 DEMO software application ..............................13 4.3 Demo software version number............................13 V, Common failure phenomenon ..............................14 5.1 Daily maintenance..................................14 5.2 Common failure analysis & resolutions ..........................14 VI, Packaging, accessories, transportation &...
-
Page 5: I, Technical Specifications
I, Technical specifications 1.1 Product features CL7206B5A is a high cost-effective RFID reader which ingrates reader module & antenna. It complies with ISO18000-6C/6B protocols, working frequency support international main frequency bands: 902MHz ~928MHz, 860MHz ~865MHz，output power 20~27dBm adjustable. This device is featured by long range, high-speed reading, &... -
Page 6: Work Environment
DC output 24V±1.5V/2.5A High degree of protection: IP65 1.2.3 Work Environment Operating temperature range: -20 ℃ ~ + 70 ℃ Relative humidity: 5% RH ~ 90% RH (+ 25 ℃) ... -
Page 7: Ii, Physical Structure
II, Physical structure 2.1 Physical structure Pic 2-1 CL7206B5A physical structure CL7206B5Areadersize... -
Page 8: Weight
290mm×290mm×55mm(accessories not included) 2.2Weight 1.6kg（accessories not included） 2.3Interfacedefinition This reader use 14 cores cable for power support and data communication. Detailed definitions as in following table: No. Definition 1 GND 2 GND 3 24V 4 GPO2/wiegand 1 5 GPO1/ wiegand 0 6 GPI 7 Network receiving differential negative 8 Network receiving differential positive 9 Network sending differential negative 10 Network sending differential positive 11 ... -
Page 9: Iii, Installation Description
In order to ensure normal and stable operation of the equipment and your personal and property safety, please carefully read the following notes before installing CL7206B5A reader device： 1. First check whether the outlet is connected to the ground, and check if the local power supply voltage meet reader voltage requirements;... -
Page 10: Connecting A Pc
3.3.2 Connecting a PC ☆ Reader cable interface includes all signal cords in the interface definition table. ☆RS-232 interface is used for short-range communication (less than 10m), can be connected to a PC via DB9 connector for communication. ☆ R485 port is used for longer range serial port communications (less than 80m); ☆Ethernet port is used for longer range communications (less than 80m). -
Page 11: Vertical Pole Installation
(2) Using two U-bolts and two toothed installation bracket to fix the reader on vertical rod through the L-bracket. As per illustrated in picture 3-2. Pic 3-2 Horizontal pole installation 3.5.2 Vertical pole installation （1）Align the L-shaped mounting bracket against the screw poles on bottom of reader housing, then install the rubber and screw the M6 nuts, refer to pic 3-3: (2) Using two U-bolts and two toothed installation bracket to fix the reader on vertical rod through the L-bracket，refer to pic 3--4. -
Page 12: Acceptance
Pic 3-4 Vertical pole installation 3.6 Acceptance 3.6.1 Checking physical installation Check & ensure the reader is fixed safely; Check & ensure cables are connected securely. Check & ensure screws are screwed firmly. 3.6.2 Checking reader performance ☆ check & confirm the reader is working normally； ☆... -
Page 13: Iv, Operation Guide
IV, Operation Guide 4.1 Demo software functions The demo software is for system control, communication mode selection, parameters setting, tag reading/writing & data display etc. 4.2 DEMO software application Software environment Windows 2000 Service Pack 3, Windows Server 2003, Windows XP Service Pack 2, Windows 7. Hardware environment P4/1.7GHzor above，512M memory or above、40G hardware disk. -
Page 14: V, Common Failure Phenomenon
V, Common failure phenomenon 5.1 Daily maintenance ☆Check & ensure if the RF connector is fixed firmly ☆Check & ensure the screw that fixes reader & antenna is not loose. ☆Check & ensure the RF cable connection point skin is not peeling off. ☆Check &... -
Page 15: Vi, Packaging, Accessories, Transportation & Storage
Pic 6-1 carton box size Packaging carton box size: 350 mm×350 mm×190mm 6.2 Accessories Pic 6-2 accessories list Name Material code Unit Remarks CL7206B5A reader 26052835000001 standard equipped Power adapter 24V/2.5A 20109000000324 standard equipped AC power cable 20350000000195 standard equipped... -
Page 16: After-Sale
Generally, we will provide timely amendments to this manual. If it’s not provided timely, please consult our service department. Shenzhen Clou IOT Technologies Co., Ltd. Email: lucky@szclou.com; Tell: +86 755 36901039 Website: http//www.clouiotech.com... - Page 17 Warranty Description: In order to offer users better service, our company provide warranty card with each device, please keep it to enjoy the service. 1, Products can replace free under conditions within one month after sale, in the precondition of normal operation without repairing.
