Summary of Contents for HIMS BookSense
- Page 1 HIMS Co,.LTD. BookSense – User Guide BookSense User Guide English Manual For Software Version in draft (v0.5) March, 2009. HIMS Co., Ltd. 139-9, Gajung-dong, Yuseong-gu, Daejeon, Korea 305-350 Phone: +82-42-864-4460 Fax: +82-42-864-4462 Email: hims@himsintl.com Website: www.himsintl.com...
- Page 2 HIMS Co,.LTD. BookSense – User Guide MIC Jack Earphone jack Pause/play/Power Button Mode Button Record Button Volume Button Hold Button Key Pad AC Adapter Hall OTG Port BookSense Front...
- Page 3 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
-
Page 4: Table Of Contents
1.1 What is the “BookSense”?..........................5 1.2 Contents of Package .............................6 2. Hardware Specifications............................7 3. Basic Functions and Structures........................8 3.1 What functions you can do with BookSense? ..................8 3.2 Power On and Off ............................8 3.3 Switching Modes............................8 3.4 Checking Date & Time..........................8 3.5 Basic Key Interfaces.............................8... - Page 5 HIMS Co,.LTD. BookSense – User Guide 7. Radio ..................................19 7.1 What is supported in the Radio?......................19 7.2 Keys to play the Radio..........................19 7.3 Record Channel ............................19 7.4 Options in the Radio ..........................19 7.5 Manage Registered Channels......................... 20 8.
-
Page 6: Overview Booksense
“BookSense” and your ears. Once you connect AC adaptor to “BookSense”, it will take 20 seconds until the system is loaded. It is same when you press reset switch which is located on the right side as a small... -
Page 7: Contents Of Package
HIMS Co,.LTD. BookSense – User Guide 1.2 Contents of Package “BookSense” Device Battery pack AC adaptor ( 5V DC, 2A) Earphone SD Card (1G) – White mode only USB Cable for connecting to PC USB Cable for using USB thumb drive... -
Page 8: Hardware Specifications
SD Card Slot User Data Memory : 4GB – BookSense XT Only FM Radio – BookSense XT Only Bluetooth 2.0 (Support stereo Bluetooth headset) – BookSense XT Only Stereo Earphone Jack (3.5 pie) Stereo Microphone Jack (3.5 pie, available for Line-In) -
Page 9: Basic Functions And Structures
HIMS Co,.LTD. BookSense – User Guide 3. Basic Functions and Structures 3.1 What functions you can do with BookSense? Media Player: Play various audio file formats DAISY Player: Play DAISY contents Book Reader: Read text files with various methods Radio: Receive signals from the radio station, recording channel, manage user... -
Page 10: Program Menu Keys
HIMS Co,.LTD. BookSense – User Guide Cancel current work: Press CANCEL button Check battery status: Press OK button more than 2 seconds 3.6 Program Menu Keys Press MENU button (located at the center of NAVIGATION buttons) You can’t call menu while dialog box is activated... - Page 11 HIMS Co,.LTD. BookSense – User Guide Format Default Storage Device Help Mode (Not supported yet)
-
Page 12: Media Player
HIMS Co,.LTD. BookSense – User Guide 4. Media Player 4.1 What is supported in the Media Player? MP3, MP4, OGG, WAV, WAX, WMA(Protected-WMA is not supported yet), asf file format Audible audio(.aa, .aax), NLS audio(3gp file, AMR-WB+: Not supported yet), RFB&D audio files(AudioPlus, AudioAccess: Not supported yet) -
Page 13: Options In The Media Player
HIMS Co,.LTD. BookSense – User Guide Interfaces in Playlist Move to next item: Press RIGHT ARROW button Move to previous item: Press LEFT ARROW button Move to top item: Press UP ARROW button Move to bottom item: Press DOWN ARROW button... - Page 14 HIMS Co,.LTD. BookSense – User Guide Call menu by pressing MENU button and move to “Playback Settings” menu by pressing UP or DOWN ARROW button and then press RIGHT button or OK button In “Selection” combo box, you can select one of settings such as “Read file name”, “Number of interval repeat”, “Shuffle:ON/OFF”, “Repeat”, or “Store...
-
Page 15: Daisy Player
HIMS Co,.LTD. BookSense – User Guide 5. DAISY Player 5.1 What is supported in the DAISY Player? DAISY 2.0/2.02/3.0, DAISY XML/Digital Talking Book ANSI/NISO Z39.86 2002, 2005 NLS contents (3gp, AMR-WB+: Not supported yet) RFB&D contents (AudioPlus, AudioAccess-Protected WMA: Not supported yet) Bookshare.org DAISY contents... - Page 16 HIMS Co,.LTD. BookSense – User Guide Heading: move by heading Level: navigate level from 1 to 5 level depth (Maximum depth is depend upon DAISY contents format) Page: move by page Mark: move by mark (only set mark before) Move to next of selected mode option: Press RIGHT ARROW button Move to previous of selected mode option: Press LEFT ARROW button Pause &...
-
Page 17: Book Reader
HIMS Co,.LTD. BookSense – User Guide 6. Book Reader 6.1 What is supported in the Book Reader? txt, rtf, doc, docx, html, xml, brl, brf Bookshare Braille file(.bks: Not supported yet) 6.2 Keys to play digital books File Selection Interfaces... -
Page 18: Options In The Book Reader
HIMS Co,.LTD. BookSense – User Guide Other Key Interfaces (while playing) Button 1: Set bookmark or voice memo Button 2: Go to bookmark or voice memo Button 3: Delete bookmark or voice memo Button 4: Read slowly Button 5: Normal speed... - Page 19 HIMS Co,.LTD. BookSense – User Guide You can put the value from 60 to 100 for “characters per line” You can put the value from 18 to 40 for “lines per page” You can move between above two items by pressing UP or DOWN ARROW...
-
Page 20: Radio
HIMS Co,.LTD. BookSense – User Guide 7. Radio 7.1 What is supported in the Radio? Receive signal from the radio stations Record channel Manage user’s channels 7.2 Keys to play the Radio Increase channel by 0.1Mhz: Press LEFT ARROW button Decrease channel by 0.1Mhz: Press RIGHT ARROW button... -
Page 21: Manage Registered Channels
HIMS Co,.LTD. BookSense – User Guide External Speaker Setting Your earphone will work for antenna for receiving signals from radio station so you need to insert earphone into device. In that case, if you want to hear radio through speaker, you need to set this option to YES Press UP or DOWN ARROW button and select either YES or NO. - Page 22 HIMS Co,.LTD. BookSense – User Guide When you are asked to put Button that you want to use for registering channel, move through items from 1 to 6. If one of them is empty, you can register current cannel to Button by pressing OK button.
-
Page 23: Voice Recording
HIMS Co,.LTD. BookSense – User Guide 8. Voice Recording 8.1 What is supported in the Voice Recording? Recording voice, lecture and nature sound via internal or external Microphone. Line-In recording for external audio source.(Not supported yet) 8.2 Keys to record Voice or Sound? Recording: Long pressing of RECORD button. -
Page 24: Bluetooth
HIMS Co,.LTD. BookSense – User Guide 9. Bluetooth 9.1 What you can do with the built-in Bluetooth device? Bluetooth ON: Press OK button when you Bluetooth OFF: Enabled device Connecting headset Disconnecting headset: Unpair Bluetooth device: Delete the connecting Information... -
Page 25: Common Options
HIMS Co,.LTD. BookSense – User Guide 10. Common Options 10.1 Alarm Setting You can move to “Alarm Setting” menu and run menu by pressing RIGHT ARROW button or OK button. You can move each setting by pressing UP or DOWN ARROW button. -
Page 26: Tts Settings
HIMS Co,.LTD. BookSense – User Guide If you set completely, press OK button to apply your setting. If you want to cancel the setting press CANCEL button 3 times and close edit box. If you want to check current date and time, press OK button “Check Date &... -
Page 27: Check System Status
HIMS Co,.LTD. BookSense – User Guide Set bit level: By pressing RIGHT or LEFT button you can select either 8bit or 16bit. Select channel: By pressing RIGHT or LEFT button you can select either stereo or mono. 10.5 Check System Status You can move to “Check battery Status”... -
Page 28: Help Mode Setting (Not Supported Yet)
HIMS Co,.LTD. BookSense – User Guide You can move each setting by pressing RIGHT or LEFT ARROW button to select one of these options ‘disabled’ ‘message’ ‘beep’ while running software. The default is beep. If you select one of these options, press OK button to apply setting. If you want to cancel setting, press CANCEL button. -
Page 29: Warning And Warranty
HIMS Co,.LTD. BookSense – User Guide 11. Warning and Warranty Under decision... -
Page 30: Contact Information
BookSense – User Guide 12. Contact Information If you are having any problems with BookSense, please contact the dealer from whom you bought your unit. If you require further assistance, please contact us at hims@himsintl.com. Or, you can contact HIMS by phone at +82-42-864-4601.
