Logic Gear XL series Quick Start Manual

Hide thumbs

Table of Contents

Quick Links

Download this manual

www.logicgearnavigation.com

Logic Gear (Australia) PTY Ltd

ABN 98 108 198 812

Table of Contents

Need help?

Do you have a question about the XL series and is the answer not in the manual?

Questions and answers

Summary of Contents for Logic Gear XL series

Page 1 Logic Gear (Australia) PTY Ltd ABN 98 108 198 812...
Page 2: Quick Start Guide
Quick Start Guide Logic Gear 3D Navigation v8.0 May 2008...
Page 3 Your Logic Gear GPS is small enough to fit into your shirt pocket or handbag when not being used in the car. It includes extra multimedia player functions a digital-music player for your favorite music, a digital-video player for watching videos or playing photo slide shows of your loved ones, and an Ebook for viewing your text notes.
Page 4 “drag & drop” for moving the map, or scaling it in map mode. AC HOME CHARGER (optional accessories – purchase separately) Your Logic Gear XL series GPS battery has already been charged during production. We recommend that you charge the battery only after that first charge is used up. The...
Page 5: Safety First
first time you should charge it for 12 hours. Subsequent charge times may take 2 to 3 hours. plug the charger into the charger socket of the GPS. plug the charger into a power point. the orange charging indicator on the front of the device will light up indicating power supply is available and your GPS is charging.
Page 6: Usb Cable
DC CAR CHARGER When using your Logic Gear GPS in a vehicle we recommend that you always use the DC car charger to power the unit, especially on long journeys. Always install the DC car charger cable so that it does not obscure any other instruments or controls or interfere with driving.
Page 7 Logic Gear’s GPS has a built-in (optional) Safety Mode that will prevent you from using screen functions if your car is in motion. Unless you have a passenger to operate, we...
Page 8 If you are planning to use your GPS while driving, remember to keep your eyes on the road ahead, and do not attempt to operate the controls of the device while driving. Never place your GPS where it might obstruct the driver’s view of the road ahead, is within the deployment zone of airbags, or where it might cause injury in case of an accident.
Page 9 GPS signal is available. Guidelines for safety operating the Logic Gear GPS In some environments operating GPS is prohibited. Turn off your GPS before boarding any aircraft or if you are in a health care facility or hospital.
Page 10 Installing in-car holder with adjustable windscreen mount slide the GPS device charger holder into the adjustable windscreen mount place the suction cup onto the desired location on the windscreen (or glass area), and push the lever to lock the suction cup. Check with reasonable force to ensure the mount is fully locked in place.
Page 11 Hardware components...
Page 12 Touch Screen Display Light Indicator-orange means external power is available, green means charging is completed, off means battery power is in use. Speaker Stylus - use to reset your unit or tap the touch screen Power on/off control - press and hold for more than 3 seconds to turn the power on or off, press once to switch sleep or awake mode SD card slot - align your card with the contacts pins facing away from you and cut off corner face down before inserting your card...
Page 13 14. Battery cover - press and slide downward to open Security Password (PIN) Your Logic Gear Navigator is protected with password security. Every time your GPS is turned on, you are required to enter your 6 digit PIN to enter.
Page 14 Change PIN: Tap the set up button to access the PIN code updates screen. Enter your original PIN, then enter your new PIN, and reconfirm your PIN by entering the numbers again. Tap confirm button to proceed. Forgot PIN: If you forget your PIN, you need to contact Logic Gear.
Page 15: Device Main Menu
DEVICE MAIN MENU opens in Your GPS this screen and it is the root menu of your device. GPS: Tap to start Logic Gear navigation software. Settings: Tap to access device settings include application/language/back light/ volume/power/clock/system Music: Tap to start music player...
Page 16: Device Settings
DEVICE SETTINGS This settings screen is for device settings include Application/Language/Back Light /Volume/Power/Clock/System/Video Input. Note you must enter GPS to change or updates any navigation settings. Application: Tap to access navigation software path settings, map updater Language: Tap to access language selection (device only – not navigation) Back light: Tap to access back light settings and display screen AUTO off timer Volume:...
Page 17: Touch Screen Calibration
Video Input: Tap to access settings for AV-IN/Auto Reversing Camera TOUCH SCREEN CALIBRATION As with many electronic devices eg. any PDA with a touch screen, sometimes your screen just won’t respond to your taps, or you tap a certain button on the screen and it doesn’t respond, or your screen doesn’t show any image at all –...
Page 18 SETTING APPLICATION PATH Logic Gear XL GPS is designed so that you have options to run your multiple navigation software from multiple locations. Your home map is usually preloaded on the internal onboard memory (NANDflash) and your additional overseas maps are loaded on SD card which you load into the SD card slot.
Page 19: Map Update
MAP UPDATE To update your onboard map with a new updated local map that you have purchased (either on a preloaded Logic Gear SD card or a downloaded version from our site), follow these procedures; insert the SD card, and reboot your device (ensure to exit all running applications...
Page 20 prior to loading your update) in the main Device menu, tap Settings / Application Tap the “MAP UPDATE” BUTTON when loading is completed, reboot our device to complete installation AV-IN / AUTO Reverse Camera This feature is specifically designed for use with your in-car reversing camera. Your GPS cradle has an inbuilt VIDEO-IN port.
Page 21 There are 4 setting modes to accommodate different display arrangements from the camera. AWAKE BUZZER This feature is designed to assist you stay awake during a long distance drive. Tap the “bell” icon on the device main menu, to enter Awake Buzzer settings. You may set to it to buzz you every 15/30/45mins.
Page 22: Music Player
MUSIC PLAYER Tap the “music” icon in the device main menu, choose the folder that contains MP3 compatible music files and double tapping a file it will automatically play your file or to select all files and then tap to confirm adding all files to your track. To add more files to your track list tap then tap then follow the above...
Page 23: Movie Player
MOVIE PLAYER Tap the “movie” icon on the device main menu, choose the folder that contains AVI compatible video files and double tap a file and it will automatically play your file or tap to select all files and then tap to confirm adding all files to your track list.
Page 24: Photo Viewer
or previous files, or display a listing without exiting the application. Tap the to exit the application and return to the device main menu PHOTO VIEWER Tap the “movie” icon on the device main menu, choose the folder that contains AVI compatible video files and double tap a file toll automatically play your file or to select all files and then tap to select all files and then tap to confirm...
Page 25: E-Book Viewer
Note : deleting files from the track list does not delete your files from your folders Tap the screen while the video is playing to switch between the full screen viewing and thumbnail viewing. You may choose to pause, play, stop, forward and backward, and adjusting volume or mute.
Page 26 Your Logic Gear navigation map is written with a unique SWID (software identification number). When you purchase additional overseas or future updated maps, you must provide Logic Gear with this SWID code in order to activate the new licence. To obtain your SWID code, access the “About”...
Page 27 POI: tap this button and your speedcam POI file will be automatically updated (make sure the new speedcam file is saved on SD card). FILE TRANSFER TOOL On–board File Transfer application is designed for ease of managing your map updates and multi-media files.
Page 28 To transfer files from device to storage card, highlight your selected files on the right (NANDflash), then open the target folder on your storage card by double tapping the folder on the left (storage card), then tap left arrow in the right side to transfer file. Delete files to delete files, highlight your selected file then tap delete.
Page 29 Please use this User Guide as a quick start up guide only. We strongly recommend you read the very detailed “Logic Gear 3D Navigation User Manual” and be familiar with the navigation software operating procedures prior to use this product on road. The “Logic Gear 3D Navigation User Manual”, in larger format and in other languages is available...
Page 30 When Logic Gear Navigator is started the first time, you need to select whether to start the program in “Simple mode” or in “Advanced mode”. The two operating modes of Logic Gear Navigator mainly differ in the menu structure and the number of available features.
Page 31 To switch from Advanced mode to Simple mode: on the startup screen (Navigation Menu), tap Startup screen: the Navigation menu After selecting Simple mode, the Navigation menu appears. From here you can reach all parts of Logic Gear Navigator. The Navigation menu contains the following options:...
Page 32 Points of Interest. for the list of your favourite destinations. to navigate or to browse the map. to customize the way Logic Gear Navigator works. to stop navigation, and exit Logic Gear Navigator.
Page 33: Navigating To An Address
Navigating to an address In the Navigation menu, tap By default, Logic Gear Navigator proposes the country/state and city, suburb, town, or settlement where you are. If needed, tap the button with the name of the country/state, and select a different one from the list.
Page 34 To select the city, suburb, town, or settlement from the list of recently used ones, tap the button To enter a new city, suburb, town, or settlement: Tap the button with the name of the settlement, or if you have changed the country/state, tap Start entering the city, suburb, town, or settlement name on the keyboard.
Page 35 Navigating to an address Enter the street name: Start entering the street name on the keyboard. Get to the list of results: After entering a couple of characters, the names that match the string appear in a list.
Page 36 to open the list of results before it appears automatically. Pick your street from the list. Enter the house number: Enter the house number on the keyboard. to finish entering the address. The map appears with the selected point in the middle. Tap from the Cursor menu.
Page 37 Navigating to a POI On the Map screen, tap to return to the Navigation menu. In the Navigation menu, tap Select the area around which the POI should be searched: : The POI will be searched around a given address.
Page 38 : The POI will be searched around the Cursor. : The POI will be searched around the current GPS position. : The POI will be searched around the destination of the active route. : The POI will be searched not around a given point but by the size of the detour it means from the active route.
Page 39 N vigating to a POI You can narrow the search using the following: Select the POI group (e.g. Accommodation), and after that, if needed, select the POI subgroup (e.g. Hotel or Motel). To find the POI by its name, tap , and use the keyboard to enter a part of the name.
Page 40 Map Screen The most important and most often used screen of Logic Gear Navigator is the Map screen. The map looks similar to a conventional road-map. The blue arrow represents your current position, and the green line shows the recommended route.
Page 41 : Switches between 2D (classic top-down view) and 3D (perspective view for navigation) map modes. : Opens the Navigation menu. If you have moved the map, a button appears. Tap this button to move the map back to the current GPS position.
Page 42 End User Licence Agreement (EULA) Logic Gear GPS and navigation software are provided for use under licence. You are required to accept Logic Gear’s and its providers’ end user licence agreements before you are authorized to use your Logic Gear GPS.
Page 43 installation or use, shall be deemed as your formal acceptance of all terms and conditions contained in this licence. Under the licence you are entitled to install the software product loaded on the enclosed SD card or preloaded on internal flash memory in the accompanying navigation hardware device in order to operate and use the navigation device.
Page 44 2. Conclusion of the Agreement 2.1. The Parties hereby acknowledge that present Agreement shall be concluded by implicit conduct of the Parties, without a signature of the Parties. 2.2. The User hereby acknowledges that following the lawful acquisition of the software product constituting the object of present Agreement (Section 4), any degree of use, installation to a computer or other hardware, installation of such hardware into a vehicle, pressing of the „Accept”...
Page 45 3. Applicable law 3.1. In issues not regulated by present Agreement the jurisdiction of the Republic of Hungary shall be applicable, with specific reference to the Act No. 4 of 1959 on the Civil Code (CC) and to Act No 76 of 1999 on Copyrights (CA). 3.2.
Page 46 4.4. Error corrections, additions, updates used by the User as defined in Section 2 following the conclusion of present contract shall also be deemed as part of the software product. 5. Owner of copyrights 5.1. The Licensor - unless contractual or legal regulations state otherwise - is the exclusive owner of all material copyrights vested in the software product.
Page 47 5.5. By concluding present Agreement, Licensor shall withhold all rights vested in the software product, except for those that the User is entitled to according to explicit legal regulations or that of present Agreement. 6. Rights of the User 6.1. The User is entitled to install the software product on one hardware device (desktop, handheld, portable computer, navigation device) at a time, and to run and use one copy thereof.
Page 48 7.1.1. to multiply the software product (to make a copy thereof); 7.1.2. to lease, rent, lend, distribute, transfer it to a third person with or without a consideration; 7.1.3. to translate the software product (including translation (compilation) to other programming languages); 7.1.4.
Page 49 8.1. Licensor hereby informs the User that although the greatest care was taken in producing the software product, yet with respect to the essence of the software product and the technical limitations, the Licensor does not warrant for the software product being completely error free, and the Licensor is not bound by any contractual obligation by which the software product obtained by the User should be completely error free.
Page 50 8.5. The Licensor shall hereby also draw the attention of the User with great emphasis to the fact that while utilising the software product in any form of transportation, observing the traffic regulations and rules (e.g. use of obligatory and/or reasonable and suitable security measures, proper and generally expected care and attention in the given situation, and special care and attention required due to utilising the software product) is the exclusive responsibility of the User;...
Page 51 9.1.3. claim that the person under breach give proper compensation (even by way of publicity, to the expense of the person under breach); 9.1.4. claim the return of the increase of assets due to the breach; 9.1.5. claim ceasing the breaching situation, the restitution of the state before the breach, to the expense of the person in breach, and may claim the destruction of instruments and materials used for the breach, and that of the objects created by the breach;...
Page 52 12 months from the date of purchase (“warranty”). Within this period, Logic Gear retains the exclusive right to repair or replace the product or offer a full refund of the purchase price at its sole discretion. Such repairs or replacement will be made at no charge to you for parts or labor.
Page 53 Logic Gear by the use of part and components not manufactured and sold by Logic Gear by non-compliance with the instructions supplied in the user’s manual through operation outside the usage parameters stated in the user’s manual,...
Page 54 Logic Gear shall not be liable for (i) any fraud on the part of its employees and/or agents; or (ii) any fraudulent misrepresentation on the part of its employees and/or agents.
Page 55 This limitation of liability, however, will not apply to claims for personal injury. LIMITATION OF REMEDY The entire liability of Logic Gear and any of its resellers shall be limited to the amount actually paid by you for the product notwithstanding any damages that you might incur for...
Page 56 Logic Gear is not liable for any claim made by a third party or made by you for a third party arising out of the use of or inability to use the product even if Logic Gear has been advised by you of the possibility of such damages.
Page 57 You must return the hardware, along with proof-of-purchase and an explanation of the defect, to the address provided to you by Logic Gear, who is entitled to charge you for reasonable shipping and handling costs made in connection with the repair or replacement of the product.
Page 58 FCC RF Radiation Exposure Statement: This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body and must not be co-located any other antenna or transmitter.
