PROJECTOR LIFT MODEL . SI-100
INSTALLATION MANUAL
Thank you for purchasing the new Harkness Screens SI-100 Projector Lift.
The SI-100 is supplied with a set of components and accessories that make it suitable for installation
for the majority of standard AV applications, but note must be made of the restrictions that apply to the
weight capability of this unit and not exceeded.
Before installing the projector lift, please read the following instructions carefully:
The projector lift must be used INDOORS ONLY.
Please confirm that your projected image width will fit your screen from your
proposed mounting location prior to installation.
Incorrect use of the lift, including exceeding the maximum lifting weight, would be
dangerous. The manufacturer does not take responsibility for any damage to property or
personal injury if the lift is used outside of recommended specifications.
This product uses a 230V AC Motor. DO NOT attempt to service the motor.
Incorrect servicing could lead to risk of electric shock. For any repairing, please contact us
directly or via the Harkness dealer you purchased the unit from.

SUPPLIED EQUIPMENT LIST :

When you open the packaging, please CHECK that it contains ALL the components below :
A) 1 MECHANIC PROJECTOR LIFT SUPPLIED WITH A PLASTIC CABLE CHANNEL AND MOTOR
WITH A 3 METER CABLE WITH FOUR ELECTRIC WIRES ( UP, DOWN, NEUTRAL AND EARTH)
B) 4 "L" FORM ALUMINIUM BRACKETS FOR CEILING MOUNTING
C) ON/OFF SWITCH UNIT
D) INSTRUCTIONS FOR ELECTRICAL CONNECTIONS BETWEEN MOTOR AND SWITCHER
E) 4 THREADED BARS M6 L. 25 CM AND 2 MOUNTING PLATES FOR THE FALSE CEILING PLATE.
F) 8 HEX HEAD SCREWS 6x16 MM.
G)
16 NUTS M6 FOR MOUNTING THE THREADED BARS TO THE MOUNTING PLATES AND TO THE LIFT

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SI-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Harkness Screens SI-100

  • Page 1 Thank you for purchasing the new Harkness Screens SI-100 Projector Lift. The SI-100 is supplied with a set of components and accessories that make it suitable for installation for the majority of standard AV applications, but note must be made of the restrictions that apply to the weight capability of this unit and not exceeded.
  • Page 2 INSTALLATION INSTRUCTIONS Use the HEX-headed screws listed as “F” in the equipment list, to mount the “L” brackets to the profile of the lift, as shown in PICTURES 1A, 1B and 1C below: Mount the lift to the ceiling using the suitable bolts/screws (NOT SUPPLIED) and verify that the projector lift is perfectly horizontal using a sprit level.
  • Page 3 Once you have mounted the lift, position the projector either on or under the grill using the screws indicated in the instruction manual of your projector, as shown on PICTURES 2A, 2B and 2C. Connect the projector lift to the electricity supply as explained on the attached instructions for electrical connections (D).
  • Page 4 Fit and align the trim kit by hanging the threaded rods from the slot as Picture 3C. If the panel is not balanced, move the projector lift either releasing the screws that lock the “L” brackets to the aluminium profile making them sliding or releasing the screws that anchor the brackets to the ceiling using the sliding hole milled out of them (max 3 cm.
  • Page 5 TECHNICAL DATA POWER SUPPLY 230 V 50 HZ MAX CONSUMPTION 90 W TORQUE 8 NM MOTOR SPEED 12 RPM DIMENSIONS (CLOSED) 576X140X550 (WXHXD in mm.) DIMENSIONS (OPEN) 576X1023X550 (WXHXD in mm.) DIMENSIONS OF THE GRILLE 415x450 (W x D in mm.) MAXIMUM CAPACITY 15 KG.
  • Page 6 S.I. – 100 Electrical Motor & Switch Connections : Wiring Diagram ‘D’...
