Series AFS5001
1-Ch. 8 BIT DIGITAL VIDEO + BI-DIRECTIONAL DATA + 10/100MBPS ETHERNET ON 1 FIBER
Installation/Operation Instructions
Fiber Optic Video & Data & Ethernet Transmission System
Part Number: AFS5001
1-CH Video +
Bi-directional Data +
10/100Mbps Ethernet Transceiver
Alba Fiber System, Inc.
265 E. Merrick Rd., Valley Stream, NY 11580
Tel: 1-516-837-9449
Fax: 1-516-837-9450
E-mail: sales@albafiber.net
Web:
www.albafiber.net
Document Version 1.0
Alba Fiber Systems Inc. Specifications are subject to change without notice. Page 1 9/27/12
www.albafiber.net
sales@albafiber.net
Advertisement
Table of Contents
Summary of Contents for AFS AFS5001-2CTX
- Page 1 Series AFS5001 1-Ch. 8 BIT DIGITAL VIDEO + BI-DIRECTIONAL DATA + 10/100MBPS ETHERNET ON 1 FIBER Installation/Operation Instructions Fiber Optic Video & Data & Ethernet Transmission System Part Number: AFS5001 1-CH Video + Bi-directional Data + 10/100Mbps Ethernet Transceiver Alba Fiber System, Inc. 265 E.
-
Page 2: Table Of Contents
Series AFS5001 1-Ch. 8 BIT DIGITAL VIDEO + BI-DIRECTIONAL DATA + 10/100MBPS ETHERNET ON 1 FIBER Table of Contents Safety Instructions..................3 Fiber Installation Hints.................4 Product Description ..................5 Product Features ..................6 Installation.....................7 Product Signal Format & Specifications............7 Front Panel Pin-out Assignment Diagram............9 Front Panel and Rear Panel LED Indicators..........13 Product Part Number Variations...............13 10.0 Troubleshooting..................14... -
Page 3: Safety Instructions
Series AFS5001 1-Ch. 8 BIT DIGITAL VIDEO + BI-DIRECTIONAL DATA + 10/100MBPS ETHERNET ON 1 FIBER 1.0 Safety Instructions The safety information contained in this section, and on other pages of this manual, must be observed whenever this unit is operated, serviced, or repaired. Failure to comply with any precaution, warning, or instruction noted in the manual is in violation of the standards of manufacture, warranty and intended use of the unit. -
Page 4: Fiber Installation Hints
Series AFS5001 1-Ch. 8 BIT DIGITAL VIDEO + BI-DIRECTIONAL DATA + 10/100MBPS ETHERNET ON 1 FIBER 2.0 Fiber Installation Hints Fiber Information Alba Fiber Transmission Systems are manufactured with optical connector covers to keep them from accumulating dirt. In addition to safety precautions, our manual also provide the following guidelines when working with optical fibers. -
Page 5: Product Description
Series AFS5001 1-Ch. 8 BIT DIGITAL VIDEO + BI-DIRECTIONAL DATA + 10/100MBPS ETHERNET ON 1 FIBER 3.0 Product Description The ALBA FIBER SYSTEMS Series AFS5001 support the simultaneous transmission of 8-bit digital video with two (2) half-duplex RS-485 or one (1) full-duplex RS-422 and one RS-232 data and one 10/100 Mbps fast Ethernet signal on a single fiber. -
Page 6: Product Features
Series AFS5001 1-Ch. 8 BIT DIGITAL VIDEO + BI-DIRECTIONAL DATA + 10/100MBPS ETHERNET ON 1 FIBER 4.0 Product Features NTSC, PAL, SECAM Fiber Optic Video System 8-bit uncompressed Digital Video Encoding complies with RS-250C Specifications Meets EIA RS-170 and RS-343 Standards Supports 1 Composite Video Signal Bi-directional Data channels as interface to RS-232, RS-485, RS-422 (up to 1Mbps) -
Page 7: Installation
Series AFS5001 1-Ch. 8 BIT DIGITAL VIDEO + BI-DIRECTIONAL DATA + 10/100MBPS ETHERNET ON 1 FIBER 5.0 Installation The ALBA FIBER SYSTEMS Series AFS5001 products are interchangeable between Standalone and Rackmount. Cards units occupy two slots in Alba’s standard 19"x4U chassis series AFS940-1 with one power supply (total 9 cards) or ASF940-2 with 2 power supplies (total 8 cards). - Page 8 Series AFS5001 1-Ch. 8 BIT DIGITAL VIDEO + BI-DIRECTIONAL DATA + 10/100MBPS ETHERNET ON 1 FIBER VIDEO Format NTSC, PAL, or SECAM Video Input/Output 1V p-p (75 ohms); max. 1.5V p-p Bandwidth 5 Hz - 10 MHz Video Resolution 700 TV lines Signal-to-Noise Ratio >65dB Weighed Differential Phase...
-
Page 9: Front Panel Pin-Out Assignment Diagram
Series AFS5001 1-Ch. 8 BIT DIGITAL VIDEO + BI-DIRECTIONAL DATA + 10/100MBPS ETHERNET ON 1 FIBER 7.0 Panels Layout and Pinout Assignment Diagrams Figures 7.1, 7.2, 7.3 and 7.4 below show the front and rear panel layout for both the TX/RX; Figures 7.5 below show the connector diagrams of rear panel layout;... - Page 10 Series AFS5001 1-Ch. 8 BIT DIGITAL VIDEO + BI-DIRECTIONAL DATA + 10/100MBPS ETHERNET ON 1 FIBER Figure 7.5: the connection diagram of rear panel for both the TX/RX. Alba Fiber Systems Inc. Specifications are subject to change without notice. Page 10 9/27/12 www.albafiber.net sales@albafiber.net...
-
Page 11: Front Panel Led Indicators
Series AFS5001 1-Ch. 8 BIT DIGITAL VIDEO + BI-DIRECTIONAL DATA + 10/100MBPS ETHERNET ON 1 FIBER 8.0 Front Panel LED Indicators Both the Transmitter (TX) and Receiver (RX) cards have front panel mounted indicators to provide visual operational status of the card and each of the channels. Below are listed and described the functions of the various LED indicators. - Page 12 Series AFS5001 1-Ch. 8 BIT DIGITAL VIDEO + BI-DIRECTIONAL DATA + 10/100MBPS ETHERNET ON 1 FIBER AFS5001-RX LED STATUS INDICATORS LINK – OPTICAL CONNECTION PRESENT(ON) OPTICAL CONNECTION ABSENT (OFF) VIDEO OUTPUT STATUS INDICATORS V1 - VIDEO PRESENT (ON) VIDEO ABSENT (OFF) DATA INPUT/OUTPUT STATUS INDICATORS DTX –...
-
Page 13: Front Panel And Rear Panel Led Indicators
1 full-duplex Ethernet One 10/100Mbps One 10/100Mbps AFS5001-1STX / AFS5001-2STX Transmitter AFS5001-1CTX / AFS5001-2CTX AFS5001-1SRX / AFS5001-2SRX Receiver AFS5001-1CRX / AFS5001-2CRX 1=MM, 2=SM; S=Standalone, C=Card (rackmount) Alba Fiber Systems Inc. Specifications are subject to change without notice. Page 13 9/27/12 www.albafiber.net... -
Page 14: Troubleshooting
Series AFS5001 1-Ch. 8 BIT DIGITAL VIDEO + BI-DIRECTIONAL DATA + 10/100MBPS ETHERNET ON 1 FIBER 10.0 Troubleshooting Below is a listing of several problems that may arise during the installation & operation of the fiber units. If user encounters issues in the installation or operation, please refer to list below. Problem: Card does not fit in chassis slots Action: Check card orientation. -
Page 15: Warranty
Series AFS5001 1-Ch. 8 BIT DIGITAL VIDEO + BI-DIRECTIONAL DATA + 10/100MBPS ETHERNET ON 1 FIBER 11.0 Warranty 3 years warranty for product - please refer to Alba Fiber Systems warranty document. Repair If product is found to be defective, user must contact a local distributors or re-seller. In order to return any items for repair or credit, buyer must receive a dated Return Materials Authorization form (RMA #), assigned by Alba Fiber Systems Customer Service department.
