The Switch you purchased contains following items：
Item
Switch
1
2
Power cord
Plastic-foot
3
Quick Installation Guide
4
5
Mounting Kits
6
TM6*12mm Screw
KM4*8mm Screw
7
Name
POE PORT S
POE PORT S
Quantity
1
1
4
1
2
4
8
POE PORT S
COMBO
COMBO
Unit
Set
Piece
Piece
Piece
Piece
Stars
Stars
Advertisement
Summary of Contents for UNIVIEW NSW162P
- Page 1 The Switch you purchased contains following items： Item Name Quantity Unit Switch Power cord Piece Plastic-foot Piece Quick Installation Guide Piece Mounting Kits Piece TM6*12mm Screw Stars KM4*8mm Screw Stars POE PORT S POE PORT S POE PORT S COMBO COMBO...
- Page 2 Panel Status Meaning Green Power connected Power LED Power disconnected or power failure Green Link established Sending/receiving data Flashing Status LED Link No link Orange Supplying power POE LED POE Staus Not supplying power...
- Page 4 16/24-port PoE Ethernet Switch Items Dimensions 440*280*44mm (L x W x H) Fixed Port ● 16/24×10/100Base-TX auto-sensing Ethernet PoE ports ● 2×Gigabit combo uplink port (SFP (default)and RJ45) ● 10Base-T: Cat 3/4/5 UTP, maximum transmission distance: 100m. ● 100Base-TX: Cat 5/6 UTP, maximum transmission distance: 100m. Cable type ●...
- Page 5 ● This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and ( 2) this device must accept any interference received, including interference that may cause undesired operation.
