ASSEMBLY INSTRUCTIONS AND PARTS LIST
ITEM

DESCRIPTION

NO.
1 MIXER MOTOR
2 #8-32 KEP NUT
3 SHAFT COUPLING WITH SETSCREWS
SHAFT ASS'Y. 5/16" DIA. X 30" LG. & 3" PROP.
4
SHAFT ASS'Y. 5/16" DIA. X 24" LG. & 3" PROP.
SHAFT ASS'Y. 5/16" DIA. X 18" LG. & 3" PROP.
SHAFT ASS'Y. 5/16" DIA. X 12" LG. & 3" PROP.
SHAFT ASS'Y. 5/16" DIA. X 30" LG. & 3" PROP.
5 PIVOT BOLT
6
CLAMP BODY ASSEMBLY
7 3/8-16 HEX NUT
8 MOUNTING BRACKET ASSEMBLY
9 MOUNTING BRACKET
10 MOUNTING BRACKET
"L" SERIES MIXER
DOVER
A COMPANY
MIXER MODELS: L-1-300, L-1-CL, L-1-BK
ATTENTION:
Laboratory mixers are designed for mixing of fluid in a container.
The mixer is mounted using a supplied clamp or bracket, which is
attached to a tank. The shafts with propeller are removable
for cleaning.

General Safety Information

Warning: These mixers are intended for specific functions.
(1) Be certain that all mounting hardware and the setscrews
of coupling are properly tightened prior to operation.
(2) Be certain propeller is not touching bottom or side of the
mixing container before starting mixer.
(3) Do not attempt to remove the mixing container or mixer when
mixer is operating, as this could result in personal injury or
damage to the mixer.
(4) Always wear safety goggles when operating the mixer.

Assembly Instructions

(1) Assemble Mixer as per the drawings. Make sure all hardware
is tight.
(2) Attach the coupling (Part # 3) to the air motor shaft (Part #1)
(3) Insert the shaft and propeller assembly into the coupling.
Tighten the setscrew.
L-1-CL L-1-CL 24

QTY.

PART NO.

PART NO.
1 100783 100783
101221 101221
4
1 000967 000967
1 001073 -
1 - 003129
1 - -
1 - -
1 - -
1 000528 000528
002092 002092
1
1 100642 100642
1 000529 000529
2 - -
1 - -
295 DeKalb Pike, North Wales, PA 19454
TEL: 215-699-8700
FAX: 215-699-0370
Toll Free FAX: 1-800-255-4017
TO INSURE SAFE AND EASY USE OF YOUR MIXER,
READ THESE INSTRUCTIONS BEFORE USING.
Description
Please follow all instructions to insure
safe and proper use.

MIXER MODELS

L-1-CL 18 L-1-CL 12 L-1-E
PART NO. PART NO. PART NO.
100783 100783 100783
101221 101221 101221
000967 000967 000967
- - -
- - -
003128 - -
004113
- -
- - 000970
000528 000528 000528
002092 002092 002092
100642 100642 100642
000529 000529 000529
- - -
- - -
L-1-BK L-1-300
PART NO. PART NO.
100783 100783
101221 101221
000967 000967
001073 001073
- -
- -
- -
- -
- -
- -
- -
- -
000968 -
- 003287
