Summary of Contents for ALEKTO 6801
- Page 1 Document Model Revision 6801 Alekto_Reparatur_Manual.doc Alekto Repair Manual Revision Changes Date - Treatment of the washers 23.01.13 - Capacitor spe...
- Page 2 Index 1 Open the case.............................1 2 Unplug the CPU board........................2 3 Remove the case..........................3 4 CC2 replacement..........................4...
-
Page 3: Open The Case
1 Open the case To open the case, you need to screw out 7 screws. The 7 screws are shown in Figure 1 to 3. Figure 3: Case - Bottom side Figure 2: Case – Left side Figure 1: Case – Right side Pull out the front to open the case. -
Page 4: Unplug The Cpu Board
2 Unplug the CPU board The CPU board is held with two screws. To remove the CPU board, you need to screw out both screws. Figure 4: CPU Board The board can be moved upward with some force. Attention! The old version of the board has 2 washers on each of the both screws. -
Page 5: Remove The Case
3 Remove the case To remove the case, you need to screw out two screws and two bolts. Which are marked on the Fig 3.1 Figure 5: IO Board... -
Page 6: Cc2 Replacement
4 CC2 replacement ℃ Desolder a capacitor CC2 and solder a new LPS Series 470uF/16 V 105 8x11 JACKCON Electrolytic Capacitor (P/N: LPS471M16V811). Figure 6: IO Board Figure 7: IO Board - Zoom in Assemble the unit in reverse order.
