LuxHome LCD
Wireless Alarm
System
Contents
About Your Alarm System
01. Full Arm
03. Part Arm 2
10. Event Log
19.
20.
User Guide
Page
01
01
01
02
02
02
02
03
03
03
03
04
04
04 + 05
06 + 07
08
09
09
09 + 10
10
11
12 + 13
LuxHome LCD Wireless Alarm
When leaving the premises, the system must be Armed. However, before doing so, check that all
windows are closed and locked, all protected doors are closed and PIR Detectors are not obstructed.
Ensure that pets are restricted to areas not protected by PIR Detectors.
The system has three arming modes, ARM, Part-Arm 1 and Part-Arm 2. The Part-Arm modes allow
for selected zones to be left in a Disarmed state while the reminder of the system is Armed.
When the system is Armed (in any mode) the Control Panel will display the arming mode and the
status of the Latch Key for a few seconds. If enabled, the system Exit-Delay will start and be
counted down on the display. As the Exit-Delay expires the Control Panel will beep, with the beep
rate increasing in steps as the delay expires. At the end of the Exit-Delay all active zones be Armed.
By this time the user must have left the property and closed the final exit door.
If while the system is armed a detector on an active zone is triggered, if enabled, the programmed
Entry-delay for that zone will start and be counted down on the display. As the Entry-Delay expires
the Control Panel will beep, with the beep rate increasing in steps as the delay expires. If the system
has not been disarmed when the Entry-Delay expires an alarm will occur. If however, the Entry-Delay
for the triggered zone has been disabled an alarm will occur immediately.
At the end of the programmed alarm duration the Siren and Control Panel alarms will stop and the
system will automatically re-Arm.
01 - Full Arm
The system can be set in ARM mode using either the Remote Control or the Control Panel as
follows:
Remote Control: Press the 'ARM' button
Control Panel: Press the Arm button followed by the User Password and then the Enter button:
?
?
?
?
,
,
User Access Code
By pressing
button, the programmed exit delay will be overrided to 5 seconds.
02 - Part-Arm 1
The system can be set in PART-Arm 1 mode using either the Remote Control or the Control Panel
as follows:
Remote Control: Press the 'PART-ARM' button
?
?
?
,
Control Panel:
User Access Code
By pressing
button, the programmed exit delay will be overrided to 5 seconds.
.
.
?
,
Page 01
Advertisement
Table of Contents
Related Manuals for 21st Century Alarms LuxHome LCD
Summary of Contents for 21st Century Alarms LuxHome LCD
-
Page 1: Full Arm
Page 01 LuxHome LCD Wireless Alarm When leaving the premises, the system must be Armed. However, before doing so, check that all windows are closed and locked, all protected doors are closed and PIR Detectors are not obstructed. Ensure that pets are restricted to areas not protected by PIR Detectors. -
Page 2: Disarm
Page 02 Page 03 03 - Part-Arm 2 07 - Panic Alarm A full Alarm condition can be immediately initiated at any time (whether the system is Armed or The system can be set in Part-Arm 2 mode using either the Remote Control or the Control Panel Disarmed) in the event of threat or danger by activating a Panic switch on either the Remote Control as follows: or the Control Panel. -
Page 3: Voice Dialer
Page 04 Page 05 11 - Voice Dialer 13 - Remote System Control If the Voice Dialer is enabled and an alarm condition occurs, the system will call for help using your To access the Remote System Control facility the Control Panel has a ‘double dial-in’ feature to recorded alarm messages and up to four telephone numbers. -
Page 4: Chime
Page 06 Page 07 14 - Testing The Alarm System 14 - Testing The Alarm System The Control Panel has a programmed test routine. You may test the system at any time, however it Alarm Test is recommended that the system is tested at regular intervals not exceeding 3 months. Scroll through the top level Test Mode menu until ‘Alarm Test’... -
Page 5: Event Log
15 - Removing Detectors for Decorating 16 - Battery Monitoring The LuxHome LCD Wireless Alarm System is Fully Tampered and will activate the Alarm if PIR and Magnetic Detectors continuously monitor their battery condition. The Control Panel also tampered with, if you wish to remove a Detector or the Control Panel for Decorating the Alarm monitors the battery condition of all PIR and Magnetic Detectors. -
Page 6: Voice Dialer
Page 10 Page 11 18 - Low Battery Indication 20 - Alarm Record Magnetic Contact Detectors: Under low battery conditions, when the Detector is activated the transmit LED will be illuminated Complete the following information during installation for future reference when adding to your for approximately 1s as the door/window is opened. -
Page 7: Latch Key
Page 12 Page 13 21 - Trouble Shooting 21 - Trouble Shooting Full alarm condition occurs when system has Magnetic Contact Detector not working not been triggered by an intruder or is disarmed 1. Ensure batteries are connected with correct Control Unit not working –...
