Page 1 DigiPin 13 PaRe remote for panasonic camera www.digipin13.hr Dario Vidović 20.2.2018.
Page 2 Manual PaRe controller – remote for panasonic camera After inserting 9V battery and mounting controler on tripod, connect left part (with wheel) of controller to the right part (small with zoom rocker) with USB 2.0 cable with 5 pole.
Page 3 FUNCTIONS OF REMOTE Buttons, wheel and potentiometer: Manual / Auto Manual / Auto Iris switch Focus switch Power on / off Focus-iris upper limiter Focus wheel Potentiometer for with push button Manual iris correction for encoder multiplier Memory Location 3 Focus-iris Memory Memory...
Page 4 Focus near Limiting focus value in manual mode: When we focusing far some object in the scene, for limiting focus upper distance push focus lock button once, than button will lighting red and also the wheel will not be able to exceed the locked value.
Page 5 To store new value in memory, repeat same procedure on wanted MEM button. While focusing with wheel, if you get to the value of one of the MEM button, this button will light. For recall MEM values, push once wanted button. Speed of transition between recalled memory value: Default speed for transition is 1000ms (1 second).
Page 6 Multiplier for encoder focus wheel: For faster focusing you can change multiplier by short push (like click on computer mouse) on focus wheel in to the right. One time (1) - will set multiplier x1 what is default value. Three time (3) - will set multiplier x2, (double counting).
Page 7 IRIS – APERTURE POSSIBILITY When the controller is in manual iris control mode, the potentiometer opens and closes the aperture. Good possibility is lock aperture value on controller. (useful when panning from dark to illuminated scene). For lock aperture higher value, set value with potentiometer then hold upper lock button for 1sec to store aperture current value.
Page 8 With Rocker we control zoom Wide or Tele and very smooth zooming speed. Button on top, have record start and stop function with red light signalization of record status. REC button with red light signalisation Zoom TELE Zoom WIDE Made in Croatia, by Dario Vidović, DigiPin 13 j.d.o.o., Year 2017/18. www.digipin13.hr...
