Revolution Technology CB161270 W Operation Manual

OPERATION MANUAL
AC Centrifugal Blowers
Thank you for purchasing Revolution Technology make blower.
Please read this operation manual carefully before
installing and using the blower, and always keep the
manual where it is readily accessible.
1. Precautions
1.1 Precautions for Installation
Do not use in a place where there is flammable gas and / or corrosive gas. Connect the ground wire
to the ground terminal inside the terminal box (if connected).
When installing the blower into your equipment, ensure that the motor lead wires are fixed and do
not move.
In addition, do not apply any pressure to these lead wires.
Installation must be performed by a qualified installer.
1.2 Precautions for Operation
Always turn off power to thermally protected blower before conducting checks or performing work
on the blower.
These types of blowers will restart automatically when blower temperature falls below a certain level.
The enclosure temperature of this blower can exceed 70C (depending on operating conditions.).
In case blower is accessible during operation, please attach the following warning label so that it
is clearly visible.
Do not touch the blower blades (impeller) when the blower is in operation.
2. Checking the P ackage Contents.
2.1 Checking the contents
Please make sure that the package contains all of the items listed below.
Blower ............................................................... 1 piece
Capacitor ........................................................... 1 piece (for single phase only )
2.2 Checking the model name
This manual covers the products specified below.
Please make sure that the model, voltage, are as you ordered by the nameplate.
CB161270 W, CB161270 X, CB161270 Y,
CB121255 W, CB121255 X, CB121255 Y,
CB100836 W, CB100836 X, Cb100836 Y,
CONTENTS:
1.Precautions .............................................. Page 1
2.Checking the Package Contents .............. Page 1
3.Connection Diagrams ............................. Page 2
4.Installation ................................................Page 2
5.Overheat Protection .................................Page 3
0
CB 161270 Z
CB 121255 Z
CB 100836 Z
TM
Warning Label
