LED T5 – INSTALLATION INSTRUCTIONS
Products covered by this instruction guide
•
LED F28T5HE
•
LED F54T5HO
The retrofit kit includes one (1) LED tube, one (1) installation instruction, and one (1) field-applied label.
The products are intended to be used in dry and damp locations only.
The T5 LED tubes are intended to retrofit surface mount, Type IC or non-IC recessed mount Listed fluorescent
luminaires that used maximum 6-straight tubular lamps with or without a diffuser, the minimum dimensions
of luminaires are tabulated below:
ELECTRICAL RATINGS:
Model Number
Voltage (V)
LBP5F13xxA
120-277V
LBP5F23xxA1
120-277V
LBP5F25xxA1
120-277V
Model Number
LBP5F13xxA
LBP5F23xxA1
LBP5F25xxA1
THIS PRODUCT MUST BE INSTALLED IN ACORDANCE WITH THE APPLICABLE INSTALLTION CODE BY A PERSON
FAMILIAR WITH THE CONSTRUCTION AND OPERATION OF THE PRODUCT AND THE HAZARDS INVOLVED.
WARNING – Risk of fire or electric shock. The electrical rating of these products are 120-277Vac or 277Vac as
"ELECTRICAL RATINGS" table above, the installer must determine whether they have 120-277Vac or 277Vac at
the luminaire before installation.
WARNING – Risk of fire or electric shock. LED Retrofit Kit installation requires knowledge of luminaires electrical
systems. If not qualified, do not attempt installation. Contact a qualified electrician.
1
NOTE: Specifications are subject to change without notice.
LED T5 – INSTALLATION INSTRUCTIONS
1
:
IMPORTANT SAFETY INSTRUCTIONS
DANGER – RISK OF SHOCK-DISCONNECT POWER BEFORE INSTALLATION
Input Ratings
Frequency (Hz)
50/60Hz
50/60Hz
50/60Hz
Minimum Lamp Compartment Dimensions
Lamp Compartment of
Luminaire (L x W x H)
2.1 x 1.5 x 0.3
3.1 x 1.5 x 0.3
4.0 x 1.5 x 0.3
Current (mA)
Wattage (W)
115mA
13W
205mA
23W
215mA
25W
Maximum Lamps in
Luminaire
6
6
6
Nominal
Length (FT)
4FT
4FT
4FT
Lamp Holder-to-Lamp
Holder Spacing (in)
1.38in
1.38in
1.38in
LIFEBULB | BYPASS T5
Advertisement
Table of Contents
Summary of Contents for LIFE BULB LED F28T5HE
- Page 1 LED T5 – INSTALLATION INSTRUCTIONS Products covered by this instruction guide • LED F28T5HE • LED F54T5HO IMPORTANT SAFETY INSTRUCTIONS DANGER – RISK OF SHOCK-DISCONNECT POWER BEFORE INSTALLATION The retrofit kit includes one (1) LED tube, one (1) installation instruction, and one (1) field-applied label. The products are intended to be used in dry and damp locations only. The T5 LED tubes are intended to retrofit surface mount, Type IC or non-IC recessed mount Listed fluorescent luminaires that used maximum 6-straight tubular lamps with or without a diffuser, the minimum dimensions of luminaires are tabulated below: ELECTRICAL RATINGS: Input Ratings Nominal Model Number Voltage (V) Frequency (Hz) Current (mA) Wattage (W) Length (FT) LBP5F13xxA 120-277V 50/60Hz 115mA 13W 4FT LBP5F23xxA1 120-277V 50/60Hz 205mA 23W 4FT LBP5F25xxA1 120-277V 50/60Hz 215mA 25W 4FT Minimum Lamp Compartment Dimensions Lamp Compartment of Maximum Lamps in...
- Page 2 LED T5 – INSTALLATION INSTRUCTIONS WARNING – Risk of fire or electric shock. Install this kit only in the luminaires that have the construction features and dimensions shown in the photographs and/or drawings and where the input rating of the retrofit kit does not exceed the input rating of the luminaire. Do not make or alter any open holes in an enclosure of wiring or electrical components during kit installation. WARNING – To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other sharp objects. WARNING – To avoid potential fire or shock hazard, do not use this retrofit kit in luminaires employing shunted bi-pin lamp holders. Note: Shunted lamp holders are found only in fluorescent luminaires with Instant-Start ballasts. Instant-start ballasts can be identified by the words “Instant Start” or “I.S.” marked on the ballast. This designation may be in the form of a statement pertaining to the ballast itself, or may be combined with the marking for the lamps with which the ballast is intended to be used, for example F40T12/IS. For more information, contact the LED luminaire retrofit kit manufacturer.
- Page 3 LED T5 – INSTALLATION INSTRUCTIONS Figure 1 STEP 4: Original circuit as shown in Figure 2. Cut lamp holder leads “1, 2, 3, 4”, then connect one lead from each lamp holder to branch circuit as follows, “Leads 1 and 4” connected to L; “Leads 2 and 3” connected to N as shown in Figure 3. Cut as far away from the lamp holders to allow for longer lengths of wire at both lamp holders. Note: Ballast must be retained in place. Figure 2 Figure 3 STEP 5: Attach the field applied label to the luminaire. Install ballast cover and diffuser (if applicable) back on the luminaire, and LED tube as shown in Figure 4. LED T5 – INSTALLATION INSTRUCTIONS LIFEBULB | BYPASS T5...
- Page 4 LED T5 – INSTALLATION INSTRUCTIONS Figure 4 STEP 6: Turn ON the AC power source, LIFEBULB tube will light up. SERVICE CONTACT: Archipelago Lighting, Inc. | Technical Support | (866) 912-3220 | technical@archipelagolighting.com LED T5 – INSTALLATION INSTRUCTIONS LIFEBULB | BYPASS T5...
