Holdoor Wireless IP Camera User Manual
Preface:
Dear customer,
Thank you for choosing to purchase and use our IP camera products. This series of IP monitoring
product is the integrated IP network camera which has been designed for network video
surveillance. The series includes a network bullet camera, a network IR bullet camera, and a
network dome camera. High performance, monolithic SOC chip is utilized as a media processor
which integrates video capture, compression, and transmission.
Standard H.264 main profile encoding algorithm ensures clear and smooth video transmission.
An embedded web server allows user to view real-time footage and remotely control the camera
via IE web browser. This series of IP camera is well-suited for home and small business, as well as
any situation which needs to apply remote network transmission and remote network control.
It's easy to install and operate.
Product Versions:
The content in this manual may be different from the product version you are using. If you meet
any problems which can't be solved according to this manual, please contact our technical
support or product supplier.
The content in this manual will be updated when necessary. Our company reserves the right to
update without notice.
Intended Reader:
This manual is intended for the following personnel: System planner
Onsite tech-support and maintenance personnel
Administrator for system installation, configuration and maintenance
Users for business operation on product functions
Terms in this Manual:
IP Camera, or IPC in this manual, means network camera including network bullet camera,
network dome camera, and network IR camera.
Click: Click with left button of mouse.
Double-click: Rapidly click the left mouse button twice.
Right-click: Click with the right button of mouse.
The [ ] symbol indicates the windows name, menu name, or data table; such as [Download
Address].
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DWB-10131 and is the answer not in the manual?

Questions and answers

Summary of Contents for Holdoor DWB-10131

  • Page 1: P2P Wireless Ip Camera User Manual

    Holdoor Holdoor Wireless IP Camera User Manual Preface: Dear customer, Thank you for choosing to purchase and use our IP camera products. This series of IP monitoring product is the integrated IP network camera which has been designed for network video surveillance.

  • Page 2: Table Of Contents

    Contents Holdoor P2P Wireless IP Camera User Manual ..................1 1 Product Introduction ......................3 1.1 Brief Introduction ......................3 1.2 Main Features ......................3 1.3 Installation Statement ....................3 1.4 Network IP Camera Connection ..................4 1 Install ..........................4 2 Log In ..........................

  • Page 3: Product Introduction

    Holdoor 1 Product Introduction 1.1 Brief Introduction This camera combines a traditional analog camera image sensor with a digital, IP based video stream. The software is built off of an efficient Linux system with all code stored in flash memory.

  • Page 4: Network Ip Camera Connection

    1: Connect the IP Camera to an open port in your router using a network LAN cable. 2: Connect the included power adapter to the IP Camera so that the camera powers on. 3: Go to www.holdoor.cn/ipcdisc and download the program called IP Camera Search Tool.

  • Page 5: Log In

    Figure 2-1 Security Level Setting Install ActiveX and plugins: 1 Go to www.holdoor.cn/ipcdisc and download the OCX 2 Or type the network camera IP address (with port number) in the IE browser address bar, and press [Enter] to bring up a dialog box , fill in user name ‘’admin’’, password ‘’none’’ (please input nothing)to open the IE Client.

  • Page 6: Network Configuration

    Holdoor 2.2 Network Configuration In order to login and view your camera from Internet Explorer, you will need to first find out the IP Address Segment, Default Gateway, and Subnet Mask of your computer. To find out the IP Address Segment, Default Gateway, and Subnet Mask, you will need to open the command prompt from a Windows PC that is connected to the same router that your IP Camera(s) will be connected to.

  • Page 7: Login

    Holdoor In the Networking tab of the IPC Config menu, you will need to change the settings of the camera to match your router settings: In the IP field, type in the same IP address that appeared as the IPv4 Address on your ipconfig results, but label the last three digits to a larger value such as 125.

  • Page 8: Preview

    Holdoor Please type the port number such as 192.168.1.125:81 Or double click the IP in the Search tool. The Default Login Values are the Following: User Name: admin Password: ‘’none’’ (type it nothing) When prompted by Internet Explorer to install add-ons, click [Yes] to install all add-ons.
  • Page 9 Holdoor Figure 3-1 Real-time Preview Interface In the real-time preview interface, the user can control the video channel, record a short video, take a snapshot, full-screen preview, image color, orientation, and PTZ control (if applicable). [Single] Click the icon and there is only one channel on the window.
  • Page 10 Holdoor [Nine] Click the icon and there are 9 channels on the window. [Record] Click the channel and then click the icon choose “record” check to start recording. Remove “record” check to stop recording. The video is kept in file catalogue set by video capture.

  • Page 11: System Setting

    Holdoor 4 System Setting 4.1 Device basic information 4.1.1 Device information The camera’s ID information and state information are in this page. You can change language as Chinese or English. 4.1.2 Alias setting This is the name of the video channel, and it is displayed on the upper left of the image. The maximum number of characters for this field is 16.

  • Page 12: Local Record Path

    Holdoor 4.1.4 Local record path [Local record path] Set file path for local recording and capture. After the file path is selected, click the [Set up] button, and the configuration will take effect immediately. [Record file length] This setting controls the length of the video files recorded.

  • Page 13: Alarm Service Settings

    Holdoor 4.2 Alarm Service Settings 4.2.1 alarm service setting [Motion detect Alarm] Enable the time frame specified. If it is unchecked, the time frame is not active. If it is checked, the motion detection time frame will be followed. [Motion detect Sensitivity] The sensitivity of motion detection includes 10 levels: The smaller the value, the more sensitive [Send Alarm Notification by Mail] Set the appropriate action to take once motion is detected.

  • Page 14: Mail Service Setting

    Holdoor 4.2.2 Mail service setting It is the e-mail alert function which required linkage alarm to take effect. If the camera triggers the alarm after configuring the mailbox parameter, it will send the alarm message to email inbox. [Sender] it is the sender email address, please fill out the complete mailbox information, for example: test@gmail.com;...

  • Page 15: Alarm Log

    Holdoor When motion is detected, this feature is primarily to snap a picture to upload to the directory specified by the FTP server. It need to access network (LAN) to make the setting. [FTP SERVER] Fill in the current IP address of the FTP server.

  • Page 16: Base Network Settings

    Holdoor 4.3 Device Network Configuration 4.3.1 Base Network Settings Click “Base Network Settings”: appears below interface: [DHCP] If the router allows DHCP functionality, select DHCP to locate an un-used IP Address on the router. After the camera is configured and is able to be viewed online, it is recommended to keep DHCP disabled.

  • Page 17: Wireless Lan Settings

    Holdoor 4.3.2 Wireless Lan Settings Figure 4-6 IPC WI-FI network setting After enabling Wi-Fi, the camera will automatically search for wireless networks in the area. When the camera is searching for a wireless network you will see the following information listed: the name of the wireless router, signal intensity, and the encryption type.

  • Page 18: Ddns Configuration

    Holdoor 4.3.3 DDNS Configuration [DDNS SERVER] Select DDNS Server; [DDNS USER] Setting up DDNS username; [DDNS PASSWORD] Setting up DDNS Password; [DDNS DOMAIN NAME] Setting up DDNS Domain name; To refresh it, once set succeed, DDNS will prompt state; The device’s IP needs to be done on the router maps and mapping out the Net;...

  • Page 19: Ptz

    Holdoor 4.4 PTZ Click the “PTZ SETTINGS” , appears below interface: [Indicate light] Setting the LED to the state of turned on or off; [Ban Preset] The preset function failure when enabled; [Starts at the preset] 1~16 preset options, aligning the corresponding preset position when startup the device;...

  • Page 20: Device User Setting

    Holdoor 1. For example, add a second device: Click the “Second device”, and then select the current local area network (in the same segment) exist in the device, the information will be automatically obtained by the device, as shown in the following figure: 4.5.2 DEVICE USER SETTING...

  • Page 21: Maintenance

    Holdoor Can set max three users namely: visitor, operator and administrator [Visitor] can only view video and switch images; [OPERATOR] All other permissions in addition to enter the device parameter interface; [ADMINISTRATOR] With all the permissions settings, can perform all operations;...

  • Page 22: 5Return

    Holdoor 5Return Click “ ” to return to monitor interface. 6 FAQ 1. Why the search tool doesn’t search to camera after the network cable connected?  Confirm whether the cable of camera or power supply is loose connection. ...
  • Page 23 Holdoor 6. Can I add your wifi IPC to Blue iris? Yes the wifi IPC support ONVIF 2.0.4 and you can add them to Blue iris. But ‘’Holdoor’’ is a new brand and you could do it as manual setup.
  • Page 24 Holdoor Model DWB-10131 Image Sensor: 1/4" Progressive Scan CMOS Min. Illumination: 0.1Lux @ (F1.2, AGC ON) ,0 Lux with IR Shutter time: 1/25(1/30) s to 1/100,000 s Camera Day& Night: IR cut filter with auto switch Digital noise reduction: 3D DNR...

  • Page 25: Obtaining Technical Support

    Firmware and WEB UI file for doing upgrade. NOTE: Some old version cameras can’t be upgraded to the latest version, that’s not only the software difference, but also the hardware difference. If you can’t make sure of it, please contact with our technical support team (tech@holdoor.cn) directly.
