Page 1: Table Of Contents
Specifications Parts List Warranty Stand Alone 5” Monitor and Receiver P/N FG0176 MM0173 Revised 26AUG2014 Air-Care is a Division of D.P.L. Enterprises, Inc. 3868 E. Post Road, Las Vegas, NV 89120 (702) 454-5515, Fax (702) 454-5225 Website: www.air-care.com, E-mail: Info@Air-Care.com...
Page 2: Safety Precautions
Safety Precautions 1. CHARGE THE BATTERIES BEFORE FIRST USE! o The 12 Volt Smart charger is for the Transmitter/Battery Box. o The Monitor Receiver has its own charger (5 volt) 2. Read this manual carefully before using this system. 3. Avoid using the device in extremely cold, or hot or humid environment – it may damage the device.
Page 3: Parts Identification
Before remove items from shipping box inspect for damage. Report any damage immediately to your carrier. Inspect all of the packing material for small parts before discarding packaging material. Report any damage to Air-Care immediately. Any attempt at repairing damages may void the warranty. 1. 5” Monitor with built in Receiver and DVR.
Page 4: Quick Start Operating Instructions
Quick Start Operating Instructions 1. The VIS mini CAM and its accessories are in a Black Instrument Case while the Insertion Rods are in a 2” x 34” round PVC carrier (Quiver) with a screw on cap and handle. 2. The inspection can be viewed and recorded with either a Laptop PC using the USB adapter or the optional 5”...
Page 5: Controls And Screen Shots
Controls on the Optional 5” Monitor with Receiver and DVR. Recording videos or stills requires an optional micro SD card (Micro SD Card p/n COM0507 and SD adapter COM0509) _____________________________________________________________________ Screen Shot of PC with the USB Receiver and DVR installed and ready to record.
Page 6: Overview Of Features
Video Inspection Systems. The VIS mini CAM has the best image quality and lighting of any camera on the market for this purpose. The ultra wide angle lens and ultra-diffuse, super-bright, white LEDs render a clear, color picture of the interior of the duct from just below the camera to the top of the same duct as well as a clear view downstream of the camera.
Page 7: Detailed Operational Instructions
The camera, accessories, adapters, and chargers fit into a small lockable case, while the extension rods are stored in their Quiver, a 2” diameter x 34” long rigid tube with a screw on cap. The complete system is lightweight and easy to store and operate. Detailed Operating Instructions for Air Care mini CAM FG0175 •...
Page 8 o The 5” Monitor has it’s own battery, but can be used with the charger plugged into the wall if the battery has been run down. Recharge the battery as soon as it is convenient. To record the inspection, you will need a Micro-SD Card (Optional) (Micro SD Card p/n COM0507 and SD adapter .
Page 9 VIS mini CAM camera head to the brush hose or cable housing, and secure the wire to the housing with the Hook & Loop straps provided. o Since the vacuum hose or brush cable bends and twists, it is necessary to allow some slack in the camera wire to prevent it from being stretched and pulling the connectors apart or breaking the wire.
Page 10 • It is useful to keep the camera in one place for several seconds to clearly record interesting parts of the ducts or dust floating in the duct or blowing past the camera. Turning the camera over can give better views of some parts of a duct. Try to always turn the Rod CLOCKWISE.
Page 11: Specifications
Technical Specifications Camera Color CCD camera with sapphire glass lens Viewing angle Illumination 2 High Powered white LEDs Operating temperature F – 120 F (-6 C – 50 Cable 32 foot (10 m) cable sections with 4 pin Mini Connectors. Transmitter / Receiver Camera Transmitter: 2.4 GHz Ch.
Page 12: Parts List
Number Optional? VIS mini CAM, Video Inspection System with USB adapter FG0175 VIS mini CAM, Video Inspection System with 5” Monitor Receiver and DVR FG0176 VIS mini CAM, Video Inspection System w/5” monitor AND USB adapter FG0178 USB Receiver (2.4 GHZ) with drivers and software to record video and stills...
Page 13: Limited Warranty
The purchaser is responsible for the cost of shipping the equipment to Air-Care’s facility for evaluation. If found to be defective and covered by the terms of this warranty, Air-Care will pay FedEx ground shipping charges on the repaired or replaced item back to the purchaser’s location. Any additional expedited service charges for quicker shipping shall be born by the purchaser.
Page 14 Air-Care is a Division of D.P.L. Enterprises, Inc. 3868 E. Post Road, Las Vegas, NV 89120 (702) 454-5515, Fax (702) 454-5225 Website: www.air-care.com, E-mail: Info@Air-Care.com...
