Summary of Contents for Retreat WHITSUNDAY

Page 2 Whitsunday User Manual Thank you for purchasing a Retreat Whitsunday Caravan and welcome to the Retreat Family. We know when you take delivery of your new caravan there might be a few things you might have forgotten from the handover.
Page 3: Table Of Contents
Whitsunday User Manual TABLE OF CONTENTS Coupling, Trailer Plugs Gas Bayonet, Stabiliser Legs Jacking Points, Water Supply Rear View Camera, Awning Operation Switches Switches in the Kitchen, Sound Setup Additional Switches Brakesafe System, Battery Charger - Monitor Solar Controller TV Operation...
Page 4: Coupling, Trailer Plugs
50mm Ball YOUR TRAILER PLUGS The Retreat Whitsunday is fitted with a 12 Pin Plug that operates your Brakes, Lights Fridge etc as well as an Anderson Plug designed to charge your caravans batteries whilst towing and also a reverse camera lead that connects to your car to view via your supplied monitor.
Page 5: Gas Bayonet, Stabiliser Legs
Gas Bayonet / Stabiliser Legs Whitsunday User Manual GAS BAYONET The Retreat Whitsunday is fitted with a Gas Bayonet which can be located on the door side of your caravan underneath the tunnel boot access door (attached to the chassis)
Page 6: Jacking Points, Water Supply
USING YOUR WATER SUPPLY The Retreat Whitsunday is fitted with water filler inlet and mains filler inlet Both items are located on the rear offside of the caravan. To use the water filler inlet simply just insert a hose in to the filler and your tanks will continue to fill.
Page 7: Rear View Camera, Awning Operation
Whitsunday User Manual REAR VIEW CAMERA (Camera and Monitor pictured below) The Retreat Whitsunday is fitted with a Rear View Camera. This camera will be wired thru the caravan and have a connection plug at the end of your wiring loom.
Page 8: Switches
Whitsunday User Manual Switches SWITCHES OF IMPORTANCE UPON ENTRY Our Vans in most case have two main set ups, the below two setups are what will be in your Whitsunday caravan. 5 switch setup 1 – 12 volt Isolation Switch 2 –...
Page 9: Switches In The Kitchen, Sound Setup
12vlt pump *see Hot water service Manual SOUND SETUP All Retreat Caravans have a Multi Media Player as a Sound / Entertainment Unit. This unit has the capability to play music via USB, AUX and Bluetooth. This unit will also Play DVD.
Page 10: Additional Switches
Additional Switches ADDITIONAL SWITCHES Your Fridge Isolation Switch The Whitsunday comes standard with a 190lt 3 way fridge that has its own isolation switch. When you are using your caravan turn this switch on, this will give your fridge power.
Page 11: Brakesafe System, Battery Charger - Monitor
Black Switch #1 to be left “on” During Travel to ensure Brakesafe is Operating BATTERY CHARGER–MONITOR All Retreat Whitsunday Models are fitted with a 25amp charger. This will also come with a Remote Monitor as pictured above. The Remote Monitor will be located in the Overhead Cupboard and will enable the customer to alter the Charge Rate as well as see the current voltage in the batteries.
Page 12: Solar Controller
No front boot models Retreat does recommend altering the settings on the unit for best results Retreat recommend the Load is left on as well as the Black isolation switch is left on at all times for best use.
Page 13: Tv Operation
TV Operation Whitsunday User Manual TV OPERATION – (TV SOURCE DTV) To ensure your television viewing has no issue please follow these instructions Ensure your 12vlt charger is plugged in to avoid TV running out of power Ensure your grey aerial...
Page 14: Dvd Operation
Whitsunday User Manual DVD Operation DVD OPERATION – (TV SOURCE DVD) To ensure your DVD viewing has no issue please follow these instructions Ensure your 12vlt charger is plugged in to avoid TV running out of power Ensure your booster...
Page 15 TV Operation Whitsunday User Manual EXTERNAL TV CONNECTION If you would like to watch TV outside please do the Following: Bring your TV Outside with the Supplied Base installed Fold Down your Outside Table Place the TV on the Outside Table...
Page 16: Hot Water Service, 12Vlt Circuit Breaker
Red Arrow Refers to the Washing Machine Power Lead and Inlet 12VLT CIRCUIT BREAKER Our Whitsunday Models have a self resetting 12vlt circuit breaker, the below items are on the attributed to the left hand number of the particular Circuit 1 –...
Page 17: Ensuite Caravan Toilet Operation
Ensuite Caravan Toilet Operation Whitsunday User Manual ENSUITE CARAVAN TOILET OPERATION Light To Indicate Toilet Cartridge is Full Blue Button on Top of toilet Ensure the water pump is on and press the blue button to allow water into the toilet bowl. Please...
Page 18 Hook from Door to Wall WASHING MACHINE OPERATION All Retreat Whitsunday Models are fitted with a Top Load Washing Machine (Bunk Vans Middle Ensuite Layouts have a Front Loader). To ensure they work please connect the washing machine to the PowerPoint nearest to the washing machine and turn on.
Page 19: 190 Lt 3 Way Fridge , Microwave
218 LT Compressor Fridge / Microwave Whitsunday User Manual 190 LT 3 WAY FRIDGE All Whitsunday models come standard with a 190 Litre 3 Way (Gas, Elec, 12 volt Fridge) The Control Panel is between the 2 doors 240 requires to be plugged in to power...
Page 20: Air Conditioner , Water Filter Cartridge
*The Unit is Supplied with a remote for your convenience WATER FILTER CARTRIDGE All Whitsunday Models are fitted with Water Filter Tap and Cartridge. The Cartridge will need to be replaced every 12 months or 6,000 lt of use...
Page 21: Grill And Cooktop , Water Tempering Valve
Whitsunday User Manual Lift Oven Lid GRILL AND COOKTOP All Retreat Whitsunday Models are fitted with a Mini Grill that is Gas Operated as well as a Cooktop that has 3 Gas Burners and a 240 Powered Hot Plate #Please note that all gas appliances have a gas shut off valve located under the appliance –...
Page 22: Shower Rose Placement
Whitsunday User Manual Shower Rose Placement SHOWER ROSE PLACEMENT WHEN TRAVELLING All Whitsunday Models are fitted with a Flickmixer and Shower Rose in all Showers. We often are asked what’s the best way to Travel? Shower Head Shower Rose Cradle...
Page 23 Daydream User Manual Once again thank you for purchasing a RETREAT WHITSUNDAY CARAVAN We hope this user manual will provide you with great information whilst you see the many breath taking places Australia has to offer. May comfort follow you everywhere...
