Dogmatek Arctic Wolf Quick User Manual

Square Switches:

Save
Saves
save in position 3... Max 8.
Recall
Recalls
settings 4.... Wait 2sec for change. Return RATE to 0 to exit recall
Shift
Sets the amount of phase shift stages in use. 4, 6 or 12. 12 is heaps of phase
depth, 4 is not so much depth. In any Stereo mode only 6 is selectable.
Shape
Select the control waveform (LFO), ∆ Triangle, ᴨ Square, ∩ Sine, ..Random
or ᴓManual (rate knob sweeps phase like a filter).
Config
M/D:
the phaser and you get 2 outputs with the same signal. You could hook up
two signal chains. Great for Gat!
M/S:
Mono in Stereo Out. This means your one input (either input 1 or 2)
feeds 2 separate 6 stage phasers.
Each output (1 and 2) is out of phase with the other so you get cool stereo
effects when you hook up 2 amps. Great for Gat or keys!
S/S:
Stereo in Stereo Out. This makes the phaser into 2 separate 6stage
phasers.
Input1 feeds through to output1, input2 feeds through to output2. Both are out
of phase for great stereo panning. Great for keyboards or post production!
P/T:
Phase/Tremolo. This turns the phaser into a pseudo tremolo and a
phaser.
Input 1 is a 6 stage phaser, input 2 is a pseudo tremolo. The 2 pulse out of
phase. Great for Gat! Feed output 1 into input 2 to use both at the same time!
Multiply
This sets the tap multiply function. 1 = 1:1, 3 = 3:1 and so on. Tap slow then
speed it up by selecting a higher number. Great for double time or multiples of
your songs tempo
Arctic Wolf quick user guide
the current settings. Press once to save in position 1, press 3 times to
saved settings. Press once to recall settings 1, press 4 times to recall
Defaults to Mono in Dual out. This means one input (either jack) feeds
