Otai Fusion 256 User Manual

Management controller & gigabit gateway
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
always innovative
Wireless
Management Controller
Gigabit Gateway
Controller
User Manual
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Fusion 256 and is the answer not in the manual?

Questions and answers

Summary of Contents for Otai Fusion 256

  • Page 1 always innovative Wireless Management Controller Gigabit Gateway Controller User Manual...

  • Page 2: Table Of Contents

    always innovative Contents Product Properties ........................Key Features ......................Hardware Properties ......................Software Properties ......................Product Interface ........................LED Indicator ........................Reset button Getting Started ..................... Assigning IP Address & Login 04-05 Conf iguration Guide Step for Individual AP Conf iguration....................

  • Page 3: Product Properties

    • Congure multiple Access Point simultaneously with single template. • Fusion 256 is multifunction device. It act as smart Gigabit router, AP Address server, DHCP server and wireless LAN controller. • Support Wi-Fi Mac ltering, QoS, Trafc Shaping, VLAN Tagging, Multiple SSID are some of the advanced features of the device.

  • Page 4: Product Interface

    System Light Reset button When need to restore the Fusion 256 into factory default, with the device powered on, use a pin to press and hold the reset button until all LED becomes quick-ash from slow-ash. Then release the button and wait Fusion 256 to reboot to its factory default settings. After that, the default IP address of Fusion 256 is still 192.168.11.1, default username : admin &...
  • Page 5 Please set one of the below IP address for the host device (computer / laptop.) IP Address : 192.168.11.2 to 192.168.11.10 / Subnet : 255.255.255.0 Open any internet browser, Input http://192.168.11.1/ in the address bar and press “Enter” to login Fusion 256 Web management interface.

  • Page 6: Conf Iguration Guide

    Conf iguration Guide Controller Fusion 256 offers different options to Control / Manage / Program all Access Points in a network from one location. There are two methods of programing Access Point. • Individual AP Conf iguration. • Group AP / Bulk AP Conf iguration Step for Individual AP Conf iguration.

  • Page 7: To Change The Ip Address

    New window will appear. 4. Authentication : WPA2PSK Encryption : TKIP/AES 4. Apply to Save : otai@999 (change as desire) Changes. 3. To Change Wireless Channel of AP. 2. Select the Channel. Note : Please select 1,3,6, 1.

  • Page 8: To Create Group Template

    Group AP / Bulk AP Conf iguration With controller Fusion 256 we can even do bulk conguration of Access Points with one single template. 1. Program individual AP for their wireless channel. A) Please select individual AP from the list as shown on page no-6. After selecting AP please click on edit button.

  • Page 9: To Add Ap To Group

    always innovative 4. Add AP to Group. Click on Device Group to see Created Group. 2. Click on “ ” Icon New window will appear. 3. Click on Add AP New window will appear. 4. Select the list of AP 5.

  • Page 10: Gateway / Router Functionality

    Gateway / Router functionality Fusion 256 is an intelligent device which also act as high speed Gateway and save another device in the network. As a Gateway Fusion 256 offers 1xGigabit LAN/WAN port and 4xGigabit LAN ports for further network connectivity.

  • Page 11: Wan Setting

    PPPOE(ADSL) service provider. Static IP Set IP and DNS information for WAN interface manual. PPTP WAN interface obtains IP and DNS information via PPTP mode. Status & Management Setting 1. Basic info Fusion 256 rmware version, hardware version, system uptime.

  • Page 12: Lan / Wan Status

    It will show Fusion 256 LAN IP, DHCP server status and MAC address. 2. WAN Status It will show Fusion 256 WAN status, Connect Type, WAN IP, Subnet Mask, Gateway IP, DNS and MAC info. 2. IP/Port Filtering By selecting IP Port Filtering option the router will allow or reject the data forwarding according to the ltering rule.

  • Page 13: Url Filtering

    always innovative 2. URL Filtering By selecting URL Filtering option the router will restrict to access the URL address mention in list. 2. Port Forwarding This option will allow to forward data from one Port to another Port. Rule Type : Set up rule type, which have specic port number.

  • Page 14: Smart Qos

    2. Smart QoS By enable or disable QoS option, we can set the uploading and downloading limit. 2. User Management The default username : admin / password : otai (you can change username and password as desire) 2. Upgrade Firmware Noted : Upgrading wrong rmware may cause system...

  • Page 15: Network Diagram

    always innovative Network Diagram Up to 200 Access Point Broadband Gateway / Router + WLAN Controller PoE Switch DC IN Up-Link Server Link AD Power 12-48V Uplink Laptop Wall AP Ceiling AP MIMO 300Mbps MIMO 300Mbps...

  • Page 16: More Than 200 Access Point

    1. Fusion 256 is smart cost effective and comprehensive device for small and medium business houses which requires 200-250 Access Point. 2. Multiple of Fusion 256 can be placed in one network to achieved higher number of Access Points in one network. In such cases Fusion 256 will act as LAN switch with WAN port disable.
